Emerson CF773BS00 Owner's Manual

42” ceiling fan brushed steel,oil rubbed bronze,satin white
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
READ AND SAVE THESE INSTRUCTIONS
42" Ceiling Fan Owner's Manual
CF773BS00 -
CF773ORB00 -
CF773SW00 -
Questions, problems, missing parts: Before returning to the store call
Part No. F40BP74820000
Revision: 131125
MONTEREY II
Model Numbers
Brushed Steel
Satin White
Net Weight:
Emerson Electric Customer Service
8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545
www.emersonfans.com
Oil Rubbed Bronze
18.1
Lbs.
™
Form No. BP7482
E.T.L. Model No.: CF773

Advertisement

Table of Contents
loading

Related Manuals for Emerson CF773BS00

Summary of Contents for Emerson CF773BS00

  • Page 1 Oil Rubbed Bronze CF773SW00 - Satin White 18.1 Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 Part No. F40BP74820000 Form No. BP7482 www.emersonfans.com Revision: 131125...

  • Page 2: Table Of Contents

    Emerson Electric Co. Substitution of parts or accessories not Additional Safety Instructions for Installation designated for use with this product by Emerson could result in personal injury or property damage. 1. To avoid possible shock, be sure electricity is turned...

  • Page 3: Unpacking Instructions

    Emerson Electric Co. Substitution of parts or Hanger Ball/Downrod Assembly accessories not designated for use with this product by Emerson Electric Co. could result in personal injury Switch Housing Assembly or property damage. Switch Housing Cover Plate 1.

  • Page 4: Electrical Requirements

    1. Unpacking Instructions (continued) This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Installed Wire Length Wire Size A.W.G. Tools Needed for Assembly Up to 50 ft. One Phillips head screwdriver One stepladder 50-100 ft.

  • Page 5: Ceiling Fan Assembly

    3. Ceiling Fan Assembly 1. Remove the hanger ball by loosening the setscrew in the hanger ball until the ball falls freely down the HANGER BALL downrod (Figure 1). Remove the pin from the downrod, then remove the hanger ball. Retain the pin and hanger ball for reinstallation in Step 5.
  • Page 6 3. Ceiling Fan Assembly (continued) 7. Mount blade flange to fan blade using three #10-32 x .25" SLOTTED #10-32 x .25” slotted Phillips washers head screws PHILLIPS WASHER HEAD (Figure 5). BLADE SCREW (3) 8. Repeat this procedure for the remaining four blades and flanges.

  • Page 7: Energy Efficient Use Of Ceiling Fans

    8 - 9 feet above the floor for optimal occupied space. Remember to adjust your thermostat airflow. Consult your Emerson Retailer for optional when using your ceiling fan - additional energy and mounting accessories.

  • Page 8: How To Hang Your Ceiling Fan

    5. How to Hang Your Ceiling Fan WARNING CEILING The fan must be hung with at least 7' of clearance from floor to blades (Figure 10). WARNING AT LEAST The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. outlet box listed as “Acceptable for Fan Support of 22.7 kg.

  • Page 9: How To Wire Your Ceiling Fan

    NOTE: CEILING COVER grounded for safe operation. OMITTED FOR CLARITY. Figure 13 NOTE: If you are using an Emerson Light Fixture with your fan, see Light Fixture Owner’s Manual for wiring. CEILING COVER...

  • Page 10: Using Your Ceiling Fan

    Emerson Electric Co. Substitution of parts or WARNING accessories not designated for use with this product by Emerson Electric Co. could result in personal injury The use of any other control not specifically approved or property damage. for this fan could result in fire, shock and personal injury.

  • Page 11: Trouble Shooting

    10. Trouble Shooting WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. 1.

  • Page 12: Repair Parts

    11. Repair Parts E.T.L. Model No.: CF773...
  • Page 13 11. Repair Parts Listing Model Numbers Description CF773BS00 CF773ORB00 CF773SW00 Hanger Ball Assembly, 761655-17 761655-32 761655-92 Consisting of: Hanger Bracket — — — Hanger Ball — — — Downrod, 4.5” — — — Parts Bag Containing: 764388-CHRM 764388-BLOX 764388-CHRM Wire Connector (3) —...
  • Page 14 Notes E.T.L. Model No.: CF773...

  • Page 15: Ceiling Fan Limited Warranty

    What We Will Do To Correct Problems: If during the one (1) year warranty period the motor or any component or accessory of your Emerson Ceiling Fan is defective in materials or workmanship, or if during the expected lifetime of the Emerson Ceiling Fan (when used in accordance with the User Manual or other instructions) the motor is defective in materials or workmanship, you must contact Emerson during the applicable warranty period.
  • Page 16 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 www.emersonfans.com Retain this manual for future use.
