SUPER MODULAR MULTI SYSTEM AIR CONDITIONER
Owner's Manual
For wireless remote controller
For commercial use
Pour usage commercial
Nur für gewerbliche Nutzung
Per uso commerciale
Para uso comercial
Para uso comercial
Voor commercieel gebruik
Για εμπoρική ρήδη
Для коммерческого использования
Ticari amaçlý kullaným için

Indoor Unit

Model name:
Console Type
MML-AP0074NH-E, MML-AP0074NH-TR
MML-AP0094NH-E, MML-AP0094NH-TR
MML-AP0124NH-E, MML-AP0124NH-TR
MML-AP0154NH-E, MML-AP0154NH-TR
MML-AP0184NH-E, MML-AP0184NH-TR
Owner's Manual
Manuel du Proprietaire
Betriebsanleitung
Manuale del Proprietario
Manual del Propietario
Manual do Utilizador
Gebruiksaanwijzing
Εγ ειρίδιo Xρήσης
Руководство Пользователя
Kullanım Kılavuzu
1
English
23
Français
Deutsch
45
Italiano
67
Español
89
Português
111
Nederlands
133
155
Ελληνικά
177
Русский
199
Türkçe
221

Advertisement

Table of Contents
loading

Related Manuals for Toshiba MML-AP0074NH-E

Summary of Contents for Toshiba MML-AP0074NH-E

  • Page 1: Indoor Unit

    Español Manual del Propietario Ticari amaçlý kullaným için Português Manual do Utilizador Nederlands Gebruiksaanwijzing Εγ ειρίδιo Xρήσης Ελληνικά Indoor Unit Руководство Пользователя Русский Model name: Kullanım Kılavuzu Türkçe Console Type MML-AP0074NH-E, MML-AP0074NH-TR MML-AP0094NH-E, MML-AP0094NH-TR MML-AP0124NH-E, MML-AP0124NH-TR MML-AP0154NH-E, MML-AP0154NH-TR MML-AP0184NH-E, MML-AP0184NH-TR...

  • Page 3: Table Of Contents

    Owner’s Manual Original instructions Thank you very much for purchasing TOSHIBA Air Conditioner. Please read this owner’s manual carefully before using your Air Conditioner. • Be sure to obtain the “Owner’s manual” and “Installation manual” from constructor (or dealer). Request to constructor or dealer •...
  • Page 4 Toshiba Carrier Corporation or, alternatively, he or she has been instructed in such matters by an individual or individuals who have been trained and is thus thoroughly acquainted with the knowledge related to this work.

  • Page 5: Warning Indications On The Air Conditioner Unit

    Owner’s Manual Warning Indications on the Air Conditioner Unit Warning indication Description WARNING WARNING ELECTRICAL SHOCK HAZARD Disconnect all remote electric ELECTRICAL SHOCK HAZARD power supplies before servicing. Disconnect all remote electric power supplies before servicing. WARNING WARNING Moving parts. Do not operate unit with grille Moving parts.

  • Page 6: Precautions For Safety

    Owner’s Manual PRECAUTIONS FOR SAFETY The manufacturer shall not assume any liability for the damage caused by not observing the description of this manual. WARNING General • Carefully read Owner’s Manual before starting the air conditioner. There are many important things to keep in mind for daily operation.
  • Page 7 Owner’s Manual CAUTION CAUTIONS ABOUT INSTALLATION • Certainly lay the drain hose for perfect draining. Wrong drainage may cause fl ooding in the house and getting furniture wet. • Make sure to connect the air conditioner to an exclusive power supply of the rated voltage; otherwise, the unit may break down or cause a fi...
  • Page 8 Owner’s Manual Information on the Transportation, Handling and Storage of the Carton Examples of indication on the carton Symbol Description Symbol Description Keep dry Handle with care Fragile Do not drop Stacking height 8 cartons (9 cartons can be stacked Do not lay down in this case) This side up...

  • Page 9: Accessories

    Owner’s Manual ACCESSORIES Remote controller Remote controller holder Batteries (two) PARTS NAME Indoor unit TIMER SET MODE TIME SAVE VENT FILTER RESET TEST SWING/FIX UNIT LOUVER Upper air outlet grille Main operation part Air inlet grille Lower air outlet grille Front panel Remote controller (wireless) Remote controller (wired, sold separately)

  • Page 10: Names And Functions Of Indicators And Controls On Indoor Unit

    Owner’s Manual Names and functions of indicators and CAUTION controls on indoor unit • Disagreement in operation mode If you select AUTOMATIC OPERATION in a model Display panel with no auto-changeover (cooling/heating) control setting or if you select HEAT in a Cool Only model, an alarm sound (pi, pi) from the air conditioner due to disagreement in operation mode.

  • Page 11: Parts Name Of Remote Controller

    Owner’s Manual PARTS NAME OF REMOTE CONTROLLER Wireless remote controller and its You can also manually select the desired fan speed from among fi ve settings. functions (LOW , LOW , MED , HIGH (A receiving beep is heard.) Auto louver button (SWING) Press this button to swing the louver.
  • Page 12 Owner’s Manual Names and functions of indications on (COMFORT SLEEP) display wireless remote controller Indicated during the OFF timer operation that automatically adjusts the room temperature and the fan speed. Each time you press the COMFORT Display SLEEP button, the display changes in the sequence All indications, except for clock time indication, are of 1h, 3h, 5h, and 9h.

  • Page 13: Adjusting Clock

    Owner’s Manual Clock adjusting ADJUSTING CLOCK Setting the clock Before you start operating the air conditioner, set the clock of the remote controller using the procedures given in this section. The clock panel on the remote controller will indicate the time regardless of whether the air conditioner is in use or not.

  • Page 14: Limited Operation By Group Control

    Owner’s Manual LIMITED OPERATION BY GROUP CONTROL NOTE Group control: Operate air conditioners in more than one system in same time. Header indoor unit: The representative unit during group control. Receive commands from wired remote controller and transmit the commands to follower units. (Header indoor unit is indoor unit that receives START/STOP signal from the wireless remote control.) Follower indoor unit: Indoor units other than the Header unit are called follower unit.

  • Page 15: Handling The Remote Controller

    Owner’s Manual HANDLING THE REMOTE CONTROLLER Remote controller holder CAUTION Installing the remote controller holder • The air conditioner will not operate if curtains, doors or other materials block the signals from the • Before you actually install the remote controller holder remote controller to the indoor unit.

  • Page 16: Dry Operation

    Owner’s Manual Dry operation Automatic operation (auto changeover) This function is available only for use in combination with Start a heat recovery model outdoor unit. If this function is used with another model of outdoor unit, “A” (Auto) appears on the remote controller but the automatic operation is disabled.

  • Page 17: Timer Operation

    Owner’s Manual Timer operation Once you select the timer operation mode, the settings are saved in the remote controller. Use the wired remote controller for timer setting if it is Thereafter, the air conditioner will start operating under also in use. the same conditions when you simply press the ON/OFF button of the remote controller.

  • Page 18: Quiet Operation

    Owner’s Manual Every day combined timer (setting both ON CAUTION and OFF timer simultaneously and activate every day.) • The Hi-POWER mode cannot be activated in the This feature is useful when you want to use combined DRY and FAN ONLY operation and when the timer at the same time every day.

  • Page 19: Preset Operation

    Owner’s Manual Preset Operation CAUTION Set your preferred operation mode for future use. The COMFORT SLEEP mode is not enabled in the The setting is memorized by the unit for future operation DRY or FAN ONLY operation. (except airfl ow direction). NOTE •...
  • Page 20 Owner’s Manual Adjusting airfl ow direction To automatically swing the airfl ow direction Perform this function when the air conditioner is in • Adjust the airfl ow direction properly. Otherwise, it operation. might cause discomfort and make the room temperature uneven. •...

  • Page 21: Hints For Economical Operation

    Owner’s Manual Adjust the horizontal airfl ow Preparation • Take hold of the lever on the horizontal airfl ow louver and move them to adjust the airfl ow direction as required. • You can adjust the airfl ow at the left, and right locations of the louver.

  • Page 22: Temporary Operation

    Owner’s Manual TEMPORARY OPERATION TEMPORARY operation This function is used to operate the unit temporarily in case you misplace the wireless remote controller or its batteries are exhausted. • Push the button once (less than 3 seconds) to start the air conditioner. •...
  • Page 23 Owner’s Manual Cleaning the air fi lter Cleaning the air inlet grille Clean the air fi lters every 2 weeks. 1. Remove the air inlet grille by release the rope from the If the air fi lters are covered with dust, the performance of hook.

  • Page 24: Specifications

    MML-AP0154NH-E MML-AP0154NH-TR MML-AP0184NH-E MML-AP0184NH-TR * Under 70 dBA Declaration of Conformity Manufacturer: TOSHIBA CARRIER (THAILAND) CO., LTD. 144/9 Moo 5, Bangkadi Industrial Park, Tivanon Road, Amphur Muang, Pathumthani 12000, Thailand Authorized Representative/ Nick Ball TCF holder: Toshiba EMEA Engineering Director TOSHIBA CARRIER UK LTD.
