Summary of Contents for Scott MX930

  • Page 1 MX930 1.8” DIGITAL MP3 PLAYER User’s Manual...
  • Page 2 PRECAUTIONS Note: Please recharge this player before using it! 1. Please use the player properly in case of explosion, fire, electric shock, etc. 2. Do not repair the player by yourself, or it will cause damage. 3. Do avoid getting the player wet or drop it in water. 4.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS PRCAUTIONS TABLE OF CONTENTS BOX CONTENTS FEATURES LOCATION OF CONTROLS BATTERY CHARGE BASIC OPERATIONS MUSIC PLAYBACK FILE MANAGEMENT VOICE RECORDING PHOTO VIEWER FM RADIO AND RECORDING SETUP VIDEO PLAYBACK EBOOK READING MAINTENANCE TROUBLESHOOTING TECHNICAL SPECIFICATIONS GB-2...
  • Page 4: Box Contents

    BOX CONTENTS Instruction Quick Start AC/USB MP3 Player USB Cable Earphones Guide installation adapter FEATURES The player supports MP3 and WMA music file formats, including WMA files with DRM (Digital Rights Management) function. Support USB 2.0 capability, much faster than USB 1.1, to enable faster communication with your PC.
  • Page 5: Location Of Controls

    LOCATION OF CONTROLS 】: Play/Pause/Confirm button 1.【 6. OLED display 】: Forward/Volume up button 2.【 HOLD/POWER: Power 】: Backward/Volume down button 3.【 on/off/Lock/Unlock knob 4.【M】: Menu button 8. Earphone jack 5.【R/V】: Record/Volume button 9. MICROPHONE/RESET button 10. USB port GB-4...
  • Page 6: Battery Charge

    BATTERY CHARGE This product is equipped with a rechargeable Li-polymer battery. 1. Connect the player to a PC with the USB cable or the supplied AC/USB adapter (that connected to an AC outlet with 100-240V ~ 50/60Hz) to charge the battery. 2.
  • Page 7: Music Playback

    To Play/Pause the music, press the button. 】buttons. To select the next or previous file, press the【 To turn off the player, Slide the HOLD/POWER knob downward and hold it Note: Please reset the player by pressing the RESET button with a sharp point while failing to turn the player on or hanging up in power ON mode.
  • Page 8 】buttons to select the music files and press the 1. Press the【 button to playback. 2. You can delete the music file or add it to the “My List” (stored in the “Play List”) by pressing the button. Use the 【+/-】 buttons to select “Add to list" or “Delete” and press the button to confirm.
  • Page 9 4. Download the music files to the player. 4.1) Click the command “Select Music” or “Select Music Directory” to input music files with “.mp3” or “.wma” formats, one by one or the whole directory. 4.2) Click the command ”Download Music” to download selected music into the player and create/refresh the music classification database.
  • Page 10 classification database. NOTE: 1. The program “ClassifyMusic_V1.5” AP can only classify the music files within the player; 2. The detailed introduction to the Classify Music AP refers to the instruction and installation CD →”ClassifyMusic_V1.5”→“Music_Classification_AP” Word file. Play List You can find the Play List (My List, *pla, *m3u, *wpl), open one of the Play List and select the music file. Then you can press the button to playback it or press the R/V button to delete the file from the play list or permanently from the player.
  • Page 11 3D sound effect can be turned On or Off. Slide Show You can select the interval of the slide show: Off, 5 Seconds, 10 Seconds, 15 Seconds, 30 Seconds or 60 Seconds. You can use slide show maker in the instruction and installation CD disk to make slide show files for the player chip.
  • Page 12 1) “Image File Name” – Show all image input files. 2) “Preview Window” – Show an image file or the effects of the slide show. 3) “Mode” Selection – Four modes: Normal, Shutter (Left to Right), Shutter (Top to Bottom), Circle. 4) “Load Image”...
  • Page 13: File Management

    8) “Delete” – Delete selected image files in the image file name list. 9) “Up” – Move the selected image file up in the image file name list. 10) “Down” – Move the selected image file down in the image file name list. AP Slide Show operation 1) Open the file “SlideShow”...
  • Page 14: Voice Recording

    】buttons to select “Yes” or “No”. Then, press the menu, and press the【 button to confirm. VOICE RECORDING In the main menu, press the 【 】 buttons to select “Voice” and enter by pressing the button. 】buttons to select the recorded file, and press the 1.
  • Page 15: Fm Radio And Recording

    FM RADIO AND RECORDING In the main menu, press the 【 】buttons to select “FM” and enter by pressing the button. FM Radio Note: To receive radio reception, the earphones must be connected to the player since the neck strap serves as an FM antenna.
  • Page 16 MSC mode: Mass Storage Class is used so that the player can serve as a removable disk. MTP mode: Mass Transfer Protocol is used for the DRM function. DRM 10 What is DRM? DRM stands for Digital Rights Management, a technology used to protect digital products from copyright infringement.
  • Page 17 6. Click “OK” to start synchronization. The following window will appear on your PC screen: GB-16...
  • Page 18 7. Select manual synchronization or automatic synchronization according to your requirements, then click “Finish”. The following screen will appear: GB-17...
  • Page 19 8. Add the songs that you want to synchronize to the list. GB-18...
  • Page 20 GB-19...
  • Page 21 9. Click “Start Sync” to start synchronization. 10. After synchronization is complete, the synchronized audio files will be displayed. GB-20...
  • Page 22: Video Playback

    Power Auto off: The player can be turned off automatically in “5min”, “10min”, “30min” or disable this function - “OFF”. Always on while playing: You can set it always on while playing. Language Select the OSD language: English, French, German, Italian, Spanish or Portuguese. Display 】buttons to adjust the settings.
  • Page 23 1.Click “Input Video” to select the video file you wish to convert. 2.Select the “Advanced Setting” to set the “Output Video Quality” (High Quality, Normal Quality, Medium Quality, Low Quality). 3.Set “Output Frame Size” to be 160x128. 4.The default “Output Audio Quality” is “Good” that cannot be changed. GB-22...
  • Page 24 5.You can replace the video clip audio track with an audio file of your own choice. Click “Input Music” and choose a music file to replace the original video clip audio track. 6. You can convert a segment of the video clip rather than the whole clip. Drag the scroll bar to select the starting or finishing time and confirm by clicking the arrowhead on left of the corresponding time.
  • Page 25: Ebook Reading

    7. You can preview the clip by clicking “MTV Preview” and select “Start Preview”. 8. Click “Output Video” to select the location that the video file will be saved. Click “Start Conversion” to convert the video file to MTV format. Play MTV Video files In the main menu, press the 【...
  • Page 26: Maintenance

    Note: the E-BOOK function can only browse .TXT files. MAINTENANCE Care and maintenance To clean the casing, wipe off dust and stains with a soft cloth moistened with a mild soap and water solution only. Do not use benzene, thinner or similar chemicals to clean the casing. If at any time in the future you should need to dispose of this product, please note that waste electrical products should not be disposed of with household waste.
  • Page 27 Video USB type 2.0 (High speed) Screen display 1.8” OLED 262k two colors Power supply Rechargeable Li-Polymer battery AC/USB adapter Input: AC 100-240V ~ 50/60Hz, Output: DC 5V 0.5A Play time: Music 8 hours (display off) Video 3 hours Maximum recording duration 20hours (Normal quality)for 4 GB built-in flash memory ≥85dB S/N ratio...
