QuickSpecs
System Details
System Board
Network Interface
Power Supply
Processor
Chipset
Super I/O
Front Side Bus
Frequency
Memory
Clock Generator
Integrated Graphics
Audio
LOM
Storage
Expansion Slots
BIOS
Industrial Standard
Rear Side I/O Ports
On Board I/O Interfaces1 x Front panel connector, Switch, LED (ON/Flash/OFF)
Board Size
Additional Features
Integrated Realtek
RTL8103EL 10/100 Fast
Ethernet Controller
65 Watt Power Adapter
90 to 140VAC, or 180 to 264VAC operating voltage range
100 to 127VAC, or 200 to 240VAC rated voltage range
50-60 Hz rated line frequency
47-63 Hz operating line frequency range
DA - 13687 Worldwide QuickSpecs — Version 2 — 6.23.2010
Intel Atom Pineview D410
Intel I/O Controller Hub NM10
Intel I/O ITE 8758E1
667MHz
DDR2 S0-DIMM
2 x DIMM slots
SLG84516BTTR
Intel Graphics Media Accelerator (GMA)
Realtek ALC887 HD Audio compatible codec with two channel audio 3D
audio
Realtek RTL8103EL 10/100 Fast Ethernet controller
Two Serial ATA interfaces (hard drive and optical drive)
1 x PCI ex 1 slot

SPI EEPROM

USB 2.0
4 x USB 2.0 ports
1 x RJ-45 10/100 port
1 x D-sub 15 pin analog VGA port
3 x audio ports
1 x Fan headers for chassis, with voltage/fan speed control
1 x header to support 2 USB 2.0 ports at front side
1 x header to support 2 front (Headphone/Mic) audio ports
1 x header to support USB media reader
PCB Size: 9.6 x 9.6 in (24.38 x 24.38 cm)
Bootable without keyboard, mouse or monitor
Keyboard/mouse/USB wake up
Support S3, S4 and S5
ACPI status
Hardware monitor capability
Hardware Highlights
Features
Compaq 100eu SFF PC (EMEA only)
PCIe x1 interface
10-Mbps and 100-Mbps operation
Crossover detection and auto-correction
Wake-on-Lan and remote Wake-up (Wake-
on-LAN supported from S3, S4
