    Online-store car audio and autogoods Winauto Contents ENGLISH CD/MP3/WMA/AAC Operating Instructions (CDE-174BT/CDE-173BT only) Playback ...............13 WARNING Repeat Play ..............13 WARNING ............6 M.I.X. (Random Play) ..........13 CAUTION ............6 Searching for CD Text..........13 PRECAUTIONS ..........6 Folder/File Name Search (concerning MP3/WMA/AAC) ......14 Getting Started Folder Name Search mode........14...
  • Page 5 Setting the AUX SETUP mode........22 Calling...............27 Setting the AUX NAME mode ........22 Playing MP3/WMA/AAC Data (PLAY MODE) Redialing a Number In Outgoing History..27 (CDE-174BT/CDE-173BT only)........22 Dialing a Number In Incoming History....27 Demonstration............22 Dialing a Number In Incoming Missed Call Display Setting............22 History ................27...
  • Page 6 Contents ENGLISH Information In Case of Difficulty..........33 Basic................33 Radio................. 33 CD (CDE-174BT/CDE-173BT only) ....33 MP3/WMA/AAC ............ 33 Audio ................ 33 iPod ................33 Indication for CD Player (CDE-174BT/CDE-173BT only) ......33 Indication for USB Memory ......34 Indication for iPod Mode........

  • Page 7: Operating Instructions

    If you have problems, do not attempt to repair the unit yourself. USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND. Return it to your Alpine dealer or the nearest Alpine Service Station (Check with your dealer if you are not sure.) Failure to do so may for servicing.
  • Page 8 Using New Disc such accessories can cause the disc to be out of standard specifications and may create operational problems. We recommend not using these accessories on discs played in Alpine Outside Bumps CD players.
  • Page 9 Alpine accepts no responsibility for lost data, etc., even if data, applications. An independent licence for such use is required. For etc., is lost while using this product.

  • Page 10: Getting Started

    • When detaching the front panel, do not apply excessive force as it may • Power Cable ................1 result in malfunction. • Microphone ................1 • USB extension cable (CDE-174BT only) ........1 Attaching • Mounting Sleeve ..............1 • Carrying Case................1 Insert the right side of the front panel into the main unit.

  • Page 11: Initial System Start-Up

    Press SOURCE to select TUNER mode. Controllable with Remote Control Press BAND repeatedly until the desired radio band is This unit can be controlled with an optional Alpine remote control. displayed. For details, consult your Alpine dealer. Point the optional remote F1 (FM1) ...

  • Page 12: Presetting Stations Automatically

    Online-store car audio and autogoods Winauto • If you store a station in a preset memory which already has a station, the current station will be cleared and replaced with the new station. Presetting Stations Automatically Rotary encoder  /ENTER Press BAND repeatedly until the desired radio band is displayed.

  • Page 13: Receiving Rds Regional (Local) Stations

    Online-store car audio and autogoods Winauto When the traffic information broadcast is over, the unit will Receiving RDS Regional (Local) Stations automatically set in the standby mode. Notes • If you do not want to listen to the traffic information being received, Press and hold AUDIOSETUP for at least 2 seconds to lightly press BANDTA to skip that traffic information message.

  • Page 14: Cd/Mp3/Wma/Aac (Cde-174Bt/Cde-173Bt Only)

    • The playback time may not be correctly displayed when a VBR CD/MP3/WMA/AAC (Variable Bit Rate) recorded file is played back. • During CD/MP3/WMA/AAC playback, press r, and then you can quickly return to the hierarchy level selected last time in the search (CDE-174BT/CDE-173BT mode. only) Repeat Play Press z 4.

  • Page 15: Folder/File Name Search (Concerning Mp3/Wma/Aac)

    Online-store car audio and autogoods Winauto Folder/File Name Search Search Position Memory (concerning MP3/WMA/AAC) During playback, you can quickly return to the last-selected hierarchy level in the search mode. Folder and file names may be searched and displayed during playback. Press r.

  • Page 16: Terminology

    Online-store car audio and autogoods Winauto ID3 tags/WMA tags Terminology This device supports ID3 tag v1 and v2, and WMA tag. If tag data is in an MP3/WMA/AAC file, this device can display the title (track title), artist name, and album name ID3 tag/WMA tag data. Bit rate This device can only display single-byte alphanumeric characters (up to This is the “sound”...

  • Page 17: Sound Setting

    Online-store car audio and autogoods Winauto Audio Setup Sound Setting You can flexibly customize the unit to suit your own preference and usage. From the AUDIO SETUP menu, Audio Setting can be modified. Rotary encoder  /ENTER Use steps 1 to 5 to select one of the setting modes to modify. See the applicable section below for details about the selected setting item.

  • Page 18: Adjusting The Parametric Equalizer Curve (3Band Eq)

    Online-store car audio and autogoods Winauto Press r to return to the previous step. Adjusting the Parametric Equalizer Curve  Setting the Mid Bandwidth (WIDTH (Q)) (3BAND EQ) Turn the Rotary encoder to select the desired Mid You can modify the Equalizer settings to create a response curve more bandwidth.

  • Page 19: Setting The Source Volume Level

    SYS 2: −14 dB ~ +14 dB Subwoofer level change is different from the main volume setting. For example, even at low volume settings, the subwoofer is still * CDE-174BT/CDE-173BT only. audible. Adjusting the High Pass Filter External Device The High Pass Filter on this unit can be adjusted to suit your personal taste.

  • Page 20: Setting The Mx Level

    FREQUENCY  SONG NAME  ARTIST NAME   RADIO TEXT  FREQUENCY PTY (Programme Type) The display in CD mode (CDE-174BT/CDE-173BT only): TRACK NO./ELAPSED TIME  TEXT (DISC NAME)   TRACK NO./ELAPSED TIME TEXT (TRACK NAME) The display in MP3/WMA/AAC mode: FILE NO./ELAPSED TIME ...

  • Page 21: About "Text

    Avoid to “Playing MP3/WMA/AAC Data (PLAY MODE) making connections to the AUX Input and USB Input terminals at the (CDE-174BT/CDE-173BT only)” on page 22. *5 Refer to “Setting the MX Level” on page 19. same time (CDE-173BT/UTE-72BT only).

  • Page 22: Setup

    *2 Refer to “BLUETOOTH SETUP” on page 24. *3 Not displayed when the current source is AUXILIARY. *4 Displayed only when AUX SETUP is set to ON. *5 CDE-174BT/CDE-173BT only. *6 Refer to “Turning AF (Alternative Frequencies) ON/OFF” on page 11.

  • Page 23: General Setting

    ENGLISH (Initial setting) / RUSSIAN / GERMAN / FRENCH / SPANISH / ITALIAN / DUTCH Changing Lighting Colour Note (CDE-174BT/CDE-173BT only) • The Owner’s Manual only describes the setup menu display when ENGLISH is set. You can change the lighting colour of the buttons of this unit.

  • Page 24: Scroll Type Setting

    • When you search this unit using the BLUETOOTH compatible phone,  Further setting items: PLAYLISTS / ARTISTS /ALBUMS / the unit name is displayed as “Alpine CD Receiver” (CDE-174BT/ AUDIOBOOKS / PODCASTS / GENRES / COMPOSERS / SONGS / CDE-173BT only)/“Alpine Digital Media Receiver”...

  • Page 25: How To Connect To A Bluetooth Compatible Device (Pairing)

    Turn the Rotary encoder to change the settings. Using your BLUETOOTH compatible device, select the “Alpine CD Receiver” (CDE-174BT/CDE-173BT only)/ Press and hold AUDIOSETUP for at least 2 seconds. “Alpine Digital Media Receiver” (UTE-72BT only) for The SETUP mode is cancelled. pairing. Notes Turn the Rotary encoder to change the head unit display •...

  • Page 26: Setting The Visible Mode

    Online-store car audio and autogoods Winauto Notes TYPE5: Weakens both noise reduction and echo-cancel • If the connection is successfully changed, “CONNECTED” is displayed for 2 seconds and the  indicator lights up, then the display returns to Notes the SETUP screen. •...

  • Page 27: Setting The Received Calls Automatically (Auto Answer)

    For information to update your BLUETOOTH firmware, please visit your local Alpine web site or choose your country from Alpine Europe Voice Control Operation top page (http://www.alpine-europe.com). When a Smartphone equipped with voice recognition function is paired ...

  • Page 28: Calling

    Online-store car audio and autogoods Winauto Notes Redialing a Number In Outgoing History • You can perform this operation only when a Voice recognition Previously dialled telephone numbers (Maximum 20 items) are stored in compatible mobile phone is connected. If the mobile phone is not dialled calls history.

  • Page 29: Call Waiting Function

    Online-store car audio and autogoods Winauto Turn the Rotary encoder to select the second letter (e.g. I), Notes and then press . • If the name has several numbers registered in the phone book, press ENTER after selecting the name. Turn the Rotary encoder to The letter selection list is displayed.

  • Page 30: Bluetooth Audio Operation

    • This unit plays back files in USB Memory with the same controls and Tag information can be displayed. modes used for playback of CDs containing MP3/WMA/AAC. For details, refer to “CD/MP3/WMA/AAC (CDE-174BT/CDE-173BT Press VIEW during a song playing and pausing. only)” on page 13.

  • Page 31: Ipod/Iphone (Optional)

    Online-store car audio and autogoods Winauto • For clarity in identifying your model of iPod, please see Apple’s own iPod/iPhone (optional) document “Identifying iPod models” at http://support.apple.com/kb/HT1353 • This unit does not support video playback from iPod/iPhone, even using a video-compatible cable. SOURCE/ ...

  • Page 32: Searching For A Desired Song

    Online-store car audio and autogoods Winauto • While in the search mode, if you press and hold r for 2 seconds, or no Searching for a desired Song operation is performed for 60 seconds, the search mode is cancelled. • In the search mode, pressing r will return to the previous mode. •...

  • Page 33: Select Playlist/Artist/Album/Genre/Composer

    Online-store car audio and autogoods Winauto Example 1: Shuffle ALL: Shuffle ALL plays all songs in the iPod/iPhone randomly. Any one Suppose the song you are searching for is located at around the song does not play back again until all songs have been played back. middle (50%) of your library: press button 4 to jump to the 50th song and turn the Rotary encoder to find the desired song.

  • Page 34: In Case Of Difficulty

    – Remove the disc by following these steps: • A CD is already in the CD player. Press the  button again for at least 2 seconds. – Eject the CD and remove it. If the disc still does not eject, consult your Alpine dealer.

  • Page 35: Indication For Usb Memory

    (refer to “Initial System Start-Up” on page 10) and press  again. – Turn the ignition key off, and then set to ON again. If the disc still cannot be ejected, consult your Alpine dealer. – Check the display by reconnecting between the USB Memory and this unit.

  • Page 36: Bluetooth Mode

    Online-store car audio and autogoods Winauto • Power surge error Excessive voltage/current is supplied to the iPod/iPhone. – Try another iPod/iPhone, if available. – Turn the power off. – Turn the ignition key off, and then set to ON again. BLUETOOTH mode •...

  • Page 37: Specifications

    50 W × 4 Maximum Pre-Output Voltage 2 V/10 k ohms Bass ±14 dB at 60 Hz ±14 dB at 1 kHz Treble ±14 dB at 10 kHz CDE-174BT/CDE-173BT: Weight 1.194 kg (2 lbs. 10 oz) UTE-72BT: Weight 0.854 kg (1lbs. 14 oz)

  • Page 38: Installation And Connections

    CDE-174BT/CDE-173BT/UTE-72BT to the fuse box, make sure Swallowing them may result in serious injury. If swallowed, consult the fuse for the intended circuit of the CDE-174BT/CDE-173BT/ a physician immediately. UTE-72BT has the appropriate amperage. Failure to do so may result in damage to the unit and/or the vehicle.

  • Page 39: Installation

    Mounting Bracket When your vehicle has the Bracket, mount the long hex bolt onto the rear panel of the CDE-174BT/CDE-173BT/ UTE-72BT and put the Rubber Cap on the hex bolt. If your vehicle does not have the Mounting Support, reinforce the head unit with the metal mounting strap (not supplied).

  • Page 40: Ipod/Iphone Connection (Optional)

    USB Connection Terminal USB Memory * The illustration is for CDE-173BT. (sold separately) When connect to Rear USB Connector (CDE-174BT only) Connect the USB cable to the Rear USB connector of the unit. Interface cable for iPod USB Memory Cable (sold...

  • Page 41: When Connect To Rear Usb Connector (Cde-174Bt Only)

    Online-store car audio and autogoods Winauto When connect to Rear USB Connector (CDE-174BT only) Connect USB Memory Connect the USB cable to the USB connector of the unit. USB Memory This unit (sold separately) Cable (supplied) USB Connector Remove USB Memory Pull out USB Memory squarely from the USB cable.

  • Page 42: Connections

    Online-store car audio and autogoods Winauto Connections CDE-174BT only To USB memory/iPod/iPhone REMOTE TURN-ON (Blue/White) To amplifier To power antenna (Red) IGNITION To the instrument cluster illumination lead (Black) Ignition Key (Blue) POWER ANT (Orange) DIMMER Battery (Yellow) BATTERY Speakers...
  • Page 43 (+) 12V only when the ignition is turned on or in the accessory position. from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.  Ground Lead (Black) •...

  • Page 44: Declaration Of Conformity

    Online-store car audio and autogoods Winauto Declaration of Conformity We, the undersigned, Alpine Electronics (Europe) GmbH Authorized representative in Europe Wilhelm-Wagenfeld-Strasse 1-3, D-80807, Munich Address, City Germany Country certify and declare under our sole responsibility that the following apparatus :...
  • Page 45 Online-store car audio and autogoods Winauto Declaration of Conformity We, the undersigned, Alpine Electronics (Europe) GmbH Authorized representative in Europe Wilhelm-Wagenfeld-Strasse 1-3, D-80807, Munich Address, City Germany Country certify and declare under our sole responsibility that the following apparatus :...
  • Page 46 Online-store car audio and autogoods Winauto Declaration of Conformity We, the undersigned, Alpine Electronics (Europe) GmbH Authorized representative in Europe Wilhelm-Wagenfeld-Strasse 1-3, D-80807, Munich Address, City Germany Country certify and declare under our sole responsibility that the following apparatus :...
