GE GSM2130 Owner's Manual

GE GSM2130 Owner's Manual

Ge dishwashers owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Instructions
Control Panel . . . . . . . . . . . . . .8
Control Settings . . . . . . . . . .8-9
Dial Cycles . . . . . . . . . . . . . . . . 10
Dishwasher Racks . . . . . .13, 14
Optional Accessories . . . . . .17
Using the Dishwasher . .11, 12
Care and Cleaning
for Service . . . . . . . . . . . . .18-23
Customer Service
Product Registration . . . . . . .29
www.geappliances.com
GE Appliances
. . . . . . .4-7
. . . . .15, 16
Owner's Manual
GSM2110
GSM2130
165D4700P212 49-5886 07-00 JR

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the GSM2130 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GE GSM2130

Summary of Contents for GE GSM2130

  • Page 1: Table Of Contents

    GE Appliances Safety Information ..4–7 Owner’s Manual Operating Instructions GSM2110 Control Panel ....8 GSM2130 Control Settings ..8–9 Dial Cycles .
  • Page 2 GE & You, A Service Partnership. Important! Two easy ways to register your appliance! Through the internet at www.geappliances.com Complete and mail the enclosed Product Registration Card Write the model and serial numbers here. You can find them on the tub wall just inside the door.

  • Page 3: If You Need Service

    If you do need service, you can relax knowing help is only a phone call away. A list of toll-free customer service numbers is included in the back ® section. Or you can always call the GE Answer Center at 800.626.2000, 24 hours a day, 7 days a week.

  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire, explosion, electric shock, or to prevent property damage, personal injury, or loss of life. WATER HEATER SAFETY Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or...
  • Page 5 Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can receive one by calling us toll-free at the GE Answer Center ® , 800.626.2000. Connect to a grounded...
  • Page 6 IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! DO NOT… Do not tamper with controls. Do not allow children to play inside, on or with this Do not abuse, sit on, or stand appliance or any discarded on the door or dish rack of appliance.

  • Page 7: Safety Information

    Automatic Dishwashing or staining of dishwasher Detergent has been approved may result. for use in all GE dishwashers. Do not touch the heating Locate sharp items so that element during or they are not likely to damage immediately after use.

  • Page 8: Control Panel

    About the dishwasher control panel. You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance may vary from your model. HOT START START OPTION SHORT WASH ENERGY OPTIONS CYCLES POTS NORMAL HEATED DRY &...
  • Page 9 Energy Options HEATED DRY Turns the drying heater on for fast drying. This cycle will extend the time to your wash cycle. RINSE ONLY. Available on all wash cycles except Add approximately 31 minutes to the cycle. HEATED DRY Shuts off the drying heat options. Dishes air dry naturally and energy is saved.

  • Page 10: Dial Cycles

    About the dial cycles. Short Wash HOT START START For quickly washing loads of everyday dishes with OPTION SHORT WASH medium soils that have not dried on. Select the NORMAL WASH cycle and any options. Be sure the door is unlatched. PLATE WARMER (HEATED DRY ON) RINSE ONLY...
  • Page 11 Using the dishwasher. Check the Water Temperature The entering water must be at least 120°F. and not more than 150°F., for effective cleaning and to prevent dish damage. Check the water temperature with a candy or meat thermometer. Turn on the hot water faucet nearest the dishwasher, place the thermometer in a glass and let the water run continuously into the glass until the temperature stops rising.

  • Page 12: Proper Use Of Detergent

    Proper Use of Detergent Use only detergent specifically made for use in dishwashers. Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers. Keep your detergent fresh and dry. Don’t put powder detergent into the dispenser until you’re ready to wash dishes.

  • Page 13: Loading The Dishwasher Racks

    Loading the dishwasher racks. For best dishwashing results, follow these loading guidelines. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack The upper rack is for glasses, cups and saucers. Cups and glasses fit best along the sides. This is also a secure place for dishwasher-safe plastics.
  • Page 14 Loading the dishwasher racks. Lower Rack When loading the lower rack, do not load large platters or trays in the front right corner. They may prevent detergent from circulating during the wash cycle. The lower rack is best used for plates, saucers and cookware.

  • Page 15: Caring For The Dishwasher

    Caring for the dishwasher. To clean the control panel use a lightly dampened cloth then dry thoroughly. To clean the exterior use a good appliance polish wax. Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher. Protect Against Freezing If your dishwasher is left in an unheated place during the winter, ask a service technician to:...
  • Page 16 Caring for the dishwasher. Does Your Dishwasher Have an Air Gap? Two types of air gaps An air gap protects your dishwasher against water backing up into it if a drain clogs. The air gap is not a part of the dishwasher. It is not covered by your warranty.

  • Page 17: Optional Accessories

    About optional accessories. You can change the door and lower access panel appearance of your dishwasher by ordering one of these optional accessories: Color Panels 1/4” Wood Panel Trim Kit 3/4” Trimless Panel Kit These accessories are available at extra cost (VISA, MasterCard or Discover cards accepted) by calling 800-626-2002.

  • Page 18: For Service

    Before you call for service… Troubleshooting Tips Review the charts on the following pages first and you may not need to call for service. Problem Possible Causes What To Do Replace fuse or reset Dishwasher won’t run Fuse is blown, or the •...
  • Page 19 Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers. To remove suds from the • tub, open the dishwasher and let suds evaporate. Add 1 gallon of cold water to the tub.

  • Page 20: For Service

    Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers. Use of the RINSE ONLY Some tomato-based • cycle (on some models) foods can stain after adding the dish to the load can decrease the level of staining.
  • Page 21 Problem Possible Causes What To Do ® Use Jet-Dry rinse agent to Spots and filming Extremely hard water • remove spots and prevent on glasses and Low inlet water new film build-up. flatware temperature To remove stubborn spots • Overloading the and pre-existing film from dishwasher glassware:...

  • Page 22: Before You Call

    Wear rubber gloves. Do not use any type of cleanser other than dishwasher detergent because it may cause foaming or sudsing. Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers.
  • Page 23 Problem Possible Causes What To Do Turn the Dial to OFF Detergent cup lid Dial is not in the OFF • and slide the door latch to won’t latch position the left. Reposition the dishes. Detergent left in Dishes are blocking the •...
  • Page 24 Notes...
  • Page 26 Notes...
  • Page 28 Notes...
  • Page 29 You can rest easy, knowing that all your valuable household products are protected against expensive repairs. 800-626-2224 Place your confidence in GE and call us in the U.S. toll-free at for more information. *All brands covered, up to 20 years old, in the continental U.S.
  • Page 30 Our service number is information, call the a safety modification. 800 GE CARES GE Answer Center ® (800-432-2737). 800.626.2000. Model Number Serial Number Important: If you did not get a registration card with your product, detach and return the form below to ensure that your product is registered, or register online at www.geappliances.com.

  • Page 31: Warranty

    One Year materials or workmanship. During this full one-year From the date of the warranty, GE will also provide, free of charge, all labor original purchase and in-home service to replace the defective part. Any part of the Water Distribution System which fails due Second Year to a defect in materials or workmanship.

  • Page 32: Service Telephone Numbers

    Expert GE repair service is only a phone call away. Special Needs Service 800.626.2000 TDD 800-TDD-GEAC (800-833-4322) GE offers, free of charge, a brochure to assist in planning a barrier- free kitchen for persons with limited mobility. Service Contracts 800-626-2224 Purchase a GE service contract while your warranty is still in effect and you’ll receive a substantial discount.

This manual is also suitable for:

Gsm2110
