- Page 1 Hickory Industries, Inc. Owner's Operating Manual Hickory Rotisseries Models: N/45WDG , 45WDG PLUS ® 4900 Westside Avenue, North Bergen, New Jersey 07047 N/45 Series Manual12/00 Page 1 of 38 Tel: [201] 223-0050 Fax: [201] 223-0950...
-
Page 2: Table Of Contents
I. INITAL STEPS 1. Placing the Machine 2. Assembling the Machine 3. Electrical Connection 4. Gas Connection 5. Venting 1.0 Installation Instructions General Information Description of the Data Plate Machine Drawings and Dimensions Conversion and Adjustment Instructions Adjustments and Verification for use with Natural Gas Natural Gas Flow Table (Consumption) 1.7.1 Volumetric Method to Verify the High Flame Setting, Mathematical Orifice Diameters, Primary Air Intake Settings, and Pressure Regulators... - Page 3 II. OPERATING INSTRUCTIONS Start Up Shut Down Working with the Rotisserie Cooking Times Spitting Chickens A. Using Angle Spits B. Using Regular Spits Loading and Unloading Spits Checking Chickens for Doneness Cooking other Products Cleaning Maintenance III. CRITICAL CONTROL STEPS FOR PREPARATION AND COOKING OF BARBECUE CHICKENS IV.
-
Page 4: Placing The Machine
I. INITIAL STEPS 1. Placing the Machine Barbecue products are often bought on impulse. The continuous style rotisserie models have been designed for maximum viewing by both the customers as well as the operator. The unit usually has a front glass surface and should be placed where it will get the best and most exposure. Wherever the unit is placed, remember that the operator will need continual access through the glass doors. -
Page 5: Description Of The Data Plate
Before installing or using this equipment, read these instructions! 4900 Westside Avenue, North Bergen, New Jersey 07047 HICKORY INDUSTRIES, INC. COMMERCIAL COOKING APPLIANCES 0 7 0 4 7 SERIAL NO. 60 CYCLE AC CURRENT 1/3 HP SINGLE PHASE 1725 RPM BURNERS 60,000 GAS INPUT PER BURNER 5.5"... -
Page 6: Machine Drawings And Dimensions
Hickory Industries, Inc. 1.3 Machine Drawings and Dimensions 4900 Westside Avenue, North Bergen, New Jersey 07047 N/45 Series Manual12/00 Page 6 of 38 Tel: [201] 223-0050 Fax: [201] 223-0950... -
Page 7: Conversion And Adjustment Instructions
Conversion and Adjustment Instructions Before converting or adjusting the machine, it is imperative that the manual gas cock be turned to the "off" position. The electrical power to the machines should also be turned off. When converting from one type of gas to another, the main gas orifice (or injector), the pilot burner orifice (or injector), and the primary air adjustment must be changed according to the table on page 9. -
Page 8: Volumetric Method To Verify The High Flame Setting, Mathematical
Natural Gas Flow Table Heating Value in Natural Propane Butane 1.7.1 Volumetric Method to Verify the High Flame Setting, Mathematical WARNING! No other gas equipment can be in operation during this procedure. Calculation of flow rate E in ft E = Flow rate in ft FP = High Flame Power setting in BTU/hr Heating value in BTU/ft Thus, for natural gas:... -
Page 9: Orifice Diameters, Primary Air Intake Settings, And Pressure Regulators
Orifice Diameters, Primary Air Intake Settings, and Pressure Regulators Gas / Pressure Main Orifice inches W.C. Ø in drill size Natural / 5.5" 5 holes @#55 Propane / 11" 2 holes @#55 Butane / 11" 2 holes@#55 4900 Westside Avenue, North Bergen, New Jersey 07047 Tel: [201] 223-0050 Fax: [201] 223-0950 Hickory Industries, Inc. -
Page 10: Changing The Main Gas Orifice
Changing Gas Orifices 1.9.1 Changing the Main Gas Orifice The venturi tubes and manifold valves are on the same side as the spit handles. On each venturi, loosen the lock nuts (7/8" wrench) and then move the nut and the air intake cap all the way to the top of the nipple. With a 3/4"... - Page 11 1.9.2 Changing the Pilot Orifice To reach the pilot burner, open the sliding glass doors, the sliding or hinged metal door, remove all spits, as well as all ceramics. Before removing, mark the position of the support bracket on the side wall. Loosen the pilot burner assembly by removing the two screws which attach each pilot burner (support bracket) to the main body of the machine.
-
Page 12: Checking The Connected Gas Pressure (Nominal Pressure)
1.10 Checking the Connected Gas Pressure (Nominal Pressure) Close the gas cock where the gas line is connected to the machine and attach a manometer to the tap (allen screw) on the gas cock. With the manometer connected, open the gas cock, ignite all burners, and set the manifold valves to "on"... -
Page 13: Testing Or Checking For Safety
A routine maintenance should be carried out at least once a year. Contact your local, certified service company for maintenance. Problem Burners do No gas flow. not ignite. Gas container too cold especially with butane. Water in gas freezes in gas regulator. Pilot burner Thermocouple tip is not ignites. -
Page 14: Description Of The Electrical Connection
When first installing, after repairing, or after cleaning the units, it is important to make sure that all components are properly in place. There should be a total of 9, evenly spaced ceramic bricks sitting above each main pipe burner. The ceramics must be sitting directly on the burners. - Page 15 Glass Track, Bottom 410 2 Glass Trolley 45 Handle 45 150 2 Lamp Par, 120 V 155 2 Motor, 1/3 HP - 120V 157 2 Motor Worm Steel 158 33 Oil Lite Bushing 159 6 Pillow Block Bearing 5/8" 414 2...
- Page 16 1.16 Parts List for N / 45WDG (Contd.) Item Qty. Description 417 9 Spit Regular Complete (with screws) 179 2/spit Roll Pin 1/8" Stainless 190 9 Spit Regular, without collar 191 9 Spit Collar 192 9 Spit Gear 419 9 Spit Handle, 6"...
- Page 17 Hickory Industries, Inc. 4900 Westside Avenue, North Bergen, New Jersey 07047 N/45 Series Manual12/00 Page 17 of 38 Tel: [201] 223-0050 Fax: [201] 223-0950...
- Page 18 Hickory Industries, Inc. 4900 Westside Avenue, North Bergen, New Jersey 07047 N/45 Series Manual12/00 Page 18 of 38 Tel: [201] 223-0050 Fax: [201] 223-0950...
- Page 19 Hickory Industries, Inc. 4900 Westside Avenue, North Bergen, New Jersey 07047 N/45 Series Manual12/00 Page 19 of 38 Tel: [201] 223-0050 Fax: [201] 223-0950...
-
Page 20: Operating Instructions
II. Operating Instructions 1.0 Start Up Switch the exhaust hood to on. Open the gas cock at the rear of the machine. Turn the knob on the manifold valve to the "pilot" position. While pressing the "flow index" button down, place a match, or other type of ignition method, to the pilot burner until it is lit. -
Page 21: Working With The Rotisserie
3.0 Working with the Rotisserie A. Cooking Temperature The desired temperature in the rotisserie can only be set with the manifold valve knob. Setting "on" is for the high flame setting and represents about 540°F. The grilling temperature can be reduced by turning the knob counter clock-wise (CCW), towards the "pilot"... -
Page 22: Cooking Times
4.0 Cooking Times Product Cooking Time Chicken 45 - 60 minutes Turkey 120 - 170 minutes Ribs 20 - 45 minutes Beef Roast 45 minutes (to 104°F) Pork Loin 45 minutes (to 135 °F) Salmon 20 - 30 minutes Duck 120 minutes Vegetables 20 minutes... -
Page 23: Spitting Chickens
5.0 Spitting Chickens Hickory Industries, Inc. A. Using Angle Spits Figure 1. Chickens Ties When using a “V” or angle spit, it is very important to tie or truss the product being cooked. This prevents the product from moving around the spit and also prevents damage by preventing the legs and wings from flopping. - Page 24 Hickory Industries, Inc. Figure 4. Trussing Legs While pulling on the tie, loop the strings over the legs of the chicken. Figure 5. Trussed Legs Make sure that both legs are securely held by the tie. Figure 6. Trussed wings Make sure that both wings are securely held by the tie against the breast of the chicken.
- Page 25 Hickory Industries, Inc. Figure 7. Pop-up Thermometer The only way to tell if a chicken is done is take the intermal temperature. Since it can be difficult to probe the chickens while they are in the rotisserie, we recommend the use of pop-up thermometer. These inexpensive items should be place in the thickest part of the chicken, which is the breast.
- Page 26 Hickory Industries, Inc. Figure 10. Using the Angle Spit Insert the bottom (handle) of the spit into the Spit Holder. Figure 11. Spitting a Chicken Spit the chicken through the cavity. The chicken should be inserted through the “head” (or at least where the head used to be) first.
- Page 27 Hickory Industries, Inc. Figure 13. Incorrectly Spitted Chicken This picture shows a chicken with the legs improp- erly placed. Note how the chicken seems to hang to one side. When spitted this way, the chickens will tend to “bounce” up and down causing the chicken to break-up.
-
Page 28: Using Regular Spits
Hickory Industries, Inc. B. Using Regular Spits Figure 15. Inserting Single Bottom Skewer Attach a single skewer with a thumb screw at least 1/ 2" from the square end of the spit. The skewer must be on the round section of the spit. Figure 16. - Page 29 Hickory Industries, Inc. Figure 18. Inserting Chicken Take the chicken, with the drumsticks in the direction of the attached skewer, and slide the spit through the cavity of the chicken. Figure 19. Tucking the Legs The legs must be tucked between the skewer prongs and the center spit.
- Page 30 Hickory Industries, Inc. Figure 21. Locking Wings The wings must be locked or tucked in place. When using the models N/5.5 and N/10.10, the locking method (pictured here) is only recom- mended with birds up to 2¾ lbs! With larger birds, the wings must be tucked under the breast, with elastic ties or “wing tuckers”.
- Page 31 Hickory Industries, Inc. Figure 24. Inserting Double Skewers With the first chicken in place, insert a double skewer down the length of the spit into the shoulders of the first chicken. No thumb screw is required for the double skewers! WARNING! When driving the double skewer into the chicken, do not exert pressure from the end of the prongs! These are sharp and will...
- Page 32 Hickory Industries, Inc. Figure 13. Completing the Load Slide a single skewer with a thumb screw into place from the top, Figure 14. Tightening Final Skewer Compress the chickens by exerting pressure on this last skewer, and tighten the thumb screw securely. Figure 15.
-
Page 33: Loading And Unloading Spits
Hickory Industries, Inc. 6. Loading and Unloading Spits On the N/45G, you do not need to open the front sliding glass doors of the machine in order to load the spits! If your unit is equipped with hinged side doors, these must be opened in order to insert and/or remove the spits. -
Page 34: Checking Chickens For Doneness
Depending on the model being used, a 2 minutes to cook in a pre-heated oven when the thermostat is set for MAXIMUM. By using a stem type thermometer, the operator MUST determine the interior temperature of the chicken to test for doneness. - Page 35 Drain the greasy water from the drip pan and replenish with a solution of warm water and detergent. Using either a sponge or a cloth - wipe down the interior of the oven with the solution removing any grease/fat. Wipe dry the interior of the oven with a soft cloth.
- Page 36 Hickory Industries, Inc. 10. Maintenance Procedures for Continuous Cook Rotisseries The most effective maintenance procedure that you can perform will be the daily cleaning procedure. Monthly: To ensure that the burner is operating efficiently, remove the ceramics and use a paper clip to clean any debris from the burner openings.
- Page 37 Thoroughly wash and sanitize hands before touching switches and/or dials. Follow operating instructions for oven operation. Check product for doneness as per instruction manual. Follow unloading procedures. Use a designated surface for cooked product only. Insure that no cross contamination occurs with any surface previously used for raw product, including employee hands.
-
Page 38: Warranty
Hickory Industries, Inc. IV. WARRANTY HICKORY INDUSTRIES WILL WARRANTY ALL ROTISSERIES FOR ONE YEAR FROM THE DATE OF ORIGINAL INVOICE. WARRANTY INCLUDES ALL PARTS EXCEPT BULBS AND GLASS. WARRANTY CONDITION IS THAT ALL WARRANTY DOCUMENTS MUST BE SIGNED AND MUST BE RETURNED TO HICKORY BY THE USER AFTER RECEIPT OF THE ROTISSERIE.
