Installation Manual
Hickory Rotisseries
Models: N/5.5 G
Machine Type
Total Power Rating
Burner / Spits
Gas Category
Fittings
Ignition
Delivery Date:
4900 Westside Avenue, North Bergen, New Jersey 07047
Tel: [201] 223-0050 Fax: [201] 223-0950
Hickory Industries, Inc.
N / 5. 5 G
20,000 Btu
1 Burners with 5 Spits
Natural Gas, LPG
1 Infra-Red Gas Generators
1 Electronic Ignitor
Final Inspection:
USA
N/5.5 Installation 8/5/97
Page 1 of 18
Advertisement
Table of Contents
Related Manuals for Hickory N/5.5 G
Summary of Contents for Hickory N/5.5 G
- Page 1 Hickory Industries, Inc. Installation Manual Hickory Rotisseries Models: N/5.5 G Machine Type N / 5. 5 G Total Power Rating 20,000 Btu Burner / Spits 1 Burners with 5 Spits Gas Category Natural Gas, LPG Fittings 1 Infra-Red Gas Generators...
-
Page 2: Table Of Contents
Hickory Industries, Inc. Table of Contents 1.0 Installation Instructions General Information Description of the Data Plate Machine Drawings and Dimensions Conversion and Adjustment Instructions Adjustments and Verification for use with Natural Gas Natural Gas Flow Table (Consumption) 1.6.1 Volumetric Method to Verify the Flame Setting, Mathematical... -
Page 3: Installation Instructions
Hickory Industries, Inc. 1.0 Installation Instructions When installing these units, it is important to comply with the most recently established rules and regulations as deemed pertinent by the local and national electrical, gas, ventilation, sanitation, and fire codes. These units are classified by Underwriters Laboratories, Inc. -
Page 4: General Information
Hickory Industries, Inc. General Information The Operating Instructions are to be given to the operator of the rotisserie. All unit operators are to be familiar with the functions of the rotisserie. The Operating Instructions should be kept in a location close to the rotisserie. It should be easily recognizeable and easily accessible. -
Page 5: Machine Drawings And Dimensions
Hickory Industries, Inc. Machine Drawings and Dimensions The following drawing of the Front View, Side View, and Top View indicate where the dimensions are taken and should be used to plan the installation of the units. N/ 5.5 G Top View... -
Page 6: Conversion And Adjustment Instructions
(or injector) must be changed according to the table on page 8. In addition, the spring in the pressure regulator supplied with the unit must be changed so that it can operate at other gas pressures. Springs for the regulator can be ordered from Hickory Industries. -
Page 7: Natural Gas Flow Table (Consumption)
V = 0.32 ft /min. This is the natural gas needed in 1 hour by a N/5.5 G (1 burner) at full power. The time and the flow measurements should be taken at the gas (flow) meter with a chronometer (stop watch). -
Page 8: Orifice Diameters, Electronic Ignition Settings
Hickory Industries, Inc. Orifice Diameters, Electrode Gap Settings, and Air Intake Settings Type N/ 5.5 G Gas / Pressure Orifice Size Electronic Ignition inches W.C. Ø in drill size Electrode Gap Natural / 5.5" 1/8" Between rods 1/8" Between rods and Burner surface 1/8"... -
Page 9: Ignition Cycle
Hickory Industries, Inc. 1.10 Ignition Cycle In order to start the cooking cycle, the burners must be ignited. The ignition cycle will start only when the following procedure is followed: a. The "HEAT" switch is turned to "on". b. A cooking temperature must be set on the thermostat (i.e. 450°F). - Page 10 Hickory Industries, Inc. Ignition Wire Connection Grounding Prong Ignition / Sensing Prong Ignition Electrode If the distances between the prongs and/or the burner surface are too great, the unit may spark but not ignite the burner. When adjusting the prongs, make sure to support the base of the prong with one pair of pliers and adjust the tip of the prong with another pair.
-
Page 11: Checking The Connected Gas Pressure (Nominal Pressure)
Hickory Industries, Inc. 1.11 Checking the Connected Gas Pressure (Nominal Pressure) Close the gas cock where the gas line is connected to the machine and attach a manometer to the tap (allen screw) on the gas cock. With the manometer connected, open the gas cock and ignite the burner. -
Page 12: Reasons For Problems And Solutions
Hickory Industries, Inc. 1.12.1 Reasons for problems and solutions Problem Cause Solution Electrode Rotisserie not "on". Make sure that the HEAT switch is on. does not spark. Thermostat must be set (i.e. 550°F) and the cooking timer must be operational (cook cycle). -
Page 13: Spit Drive Mechanism
Hickory Industries, Inc. 1.13 Spit Drive Mechanism This unit is equipped with a planetary motion spit drive system. This means that each spit is turning upon its axis at the same time that they turn about the center shaft. When the motor switch is turned to on, the disks and the spits will begin to turn. -
Page 14: Testing And Checking For Safety
Hickory Industries, Inc. NOTE: If fat or carbon have built up on the center shaft, it may not be possible to move the alumium disks! With the disks away from the sides, all components of the drive mechanism should be thoroughly cleaned. -
Page 15: Electrical Diagram
Hickory Industries, Inc. 1.16 Electrical Diagram 4900 Westside Avenue, North Bergen, New Jersey 07047 N/5.5 Installation 8/5/97 Tel: [201] 223-0050 Fax: [201] 223-0950 Page 15 of 18... -
Page 16: G Parts List
Hickory Industries, Inc. 1.17 Parts List for 5.5 G Item Qty. Description Material Length Size Manufacturer Shaft 5/8 (Removable Drums - Center) 5/8" Hickory Shaft Locking Slide Hickory Drive Bearing Holder (Left - with brass bearing) Steel (Chromed) Hickory Drive Bearing Holder (Right - with teflon bearing) Steel (Chromed) - Page 17 Contact Section 242 (terminal) Buchanan Contact Section 250 (end-piece) Buchanan *All components are inventories and sold through Hickory Industries and their distributors and dealers. 4900 Westside Avenue, North Bergen, New Jersey 07047 N/5.5 Installation 8/5/97 Tel: [201] 223-0050 Fax: [201] 223-0950...
-
Page 18: Exploded View Diagrams
Hickory Industries, Inc. 1.18 Exploded View Diagrams 4900 Westside Avenue, North Bergen, New Jersey 07047 N/5.5 Installation 8/5/97 Tel: [201] 223-0050 Fax: [201] 223-0950 Page 18 of 18...
