HP ProLiant Smart Array 256MB Quickspecs page 30

NOTE: Memory configurations listed do not apply to "Factory Integrated Models".
Standard Memory
2 GB PC2-5300 Fully Buffered DIMMs (DDR2-667) (2 x 1 GB)
Upgrading Memory and Memory Interleaving
When upgrading memory, DIMMs 1A and 2A must match. DIMMs 3B and 4B, DIMMs 5C and 6C, and DIMMs 7D and 8D
must match and must be installed as a pair. When DIMMs 1A and 2A are populated the system is automatically configured
for 2:1 interleaving. When all 4 banks are populated the system is automatically configured for 4:1 interleaving. When four,
six, or eight DIMMs are populated with identical DIMMs the system is automatically configured for bank interleaving.
Standard Memory Plus Optional Memory
Up to 26 GB memory is available with the standard memory and the optional installation of PC2-5300 Fully Buffered DIMMs
(DDR2-667) memory kits.
Standard Memory Replaced with Optional Memory
Up to 32 GB of memory is available with the removal of the standard memory and the optional installation of PC2-5300
Fully Buffered DIMMs (DDR2-667) memory kits.
NOTE: Chart does not represent all possible configurations.
Memory
Standard 2 GB
Optional 26 GB
Maximum 32 GB
NOTE: In the online spare configuration, the ROM automatically configures the last populated bank as the spare memory.
If only banks A and B are populated, bank B is the spare bank. If banks A, B, and C are populated, bank C is the spare
bank, Online spare memory is configured through RBSU.
NOTE: Mirrored Memory uses mirrored banks to provide a high level of memory redundancy. Customer chooses to
implement or not: User selectable via BIOS and default is off.
Following are memory options available from HP:
1 GB FBD PC2-5300 2 x 512 MB Kit
2 GB FBD PC2-5300 2 x 1 GB Kit
2 GB FBD PC2-5300 2 x 1 GB LP Kit
4 GB FBD PC2-5300 2 x 2 GB Kit
4 GB FBD PC2-5300 2 x 2 GB LP Kit
8 GB FBD PC2-5300 2 x 4 GB Kit
8 GB FBD PC2-5300 2 x 4 GB LP Kit
NOTE: Memory Option Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient
Features, please visit: http://h18004.www1.hp.com/products/servers/platforms/energyefficient/
In Advanced ECC mode, FBDIMMs must be populated as specified in the following table:
Configuration
1
2
3
4
1 2
1 GB 1 GB Empty
1 GB 1 GB 4 GB
4 GB 4 GB 4 GB
Bank A
1A and 3A
X
X
X
X
DA - 12477 Worldwide QuickSpecs — Version 36 — 2/29/2008
Slot
3 4 5
Empty Empty
4 GB 4 GB
4 GB 4 GB
Bank B
5B and 7B
-
X
X
X
6 7
Empty Empty
4 GB 4 GB
4 GB 4 GB
Bank C
2C and 4C 6D and 8D
-
-
X
X
8
Empty
4 GB
4 GB
397409-B21
397411-B21
461826-B21
397413-B21
461828-B21
397415-B21
466440-B21
Bank D
-
-
-
X
Page 30
