Aztech ADSL PCI Modem Easy Start page 4

Modem Card Easy Start
Data LED
Link LED
ADSL PCI Modem
1. The connection for the Telephone set is optional. The Phone jack
provides convenience to users who need to use the phone when
accessing the computer.
2. No external Micro-Filter is required as your ADSL PCI Modem has a
built-in Micro-Filter at the Phone jack.
4
PHONE jack - from Telephone Set
LINE jack - to Telephone Wall Socket
Telephone
extension cord
(ADSL Line)
Telephone set
Telephone
Wall Socket
