Shakespeare Electronic Style DS-3005 User Manual

18" portable satellite antenna

ELECTRONICS AND FIBERGLASS DIVISION

18" Portable Satellite Antenna

Style DS-3005

ANTENNA/MOUNT MADE IN U.S.A.

UNPACKING

After unpacking the system, verify that you have 25 feet

of coax. If you do not, please contact Shakespeare at

(803) 276-5504. SAVE THE CARTON. This carton is

designed to be reused to protect your system when

not in use.

ELECTRONICS AND FIBERGLASS DIVISION

Shakespeare Electronic Products Group

6111 Shakespeare Rd., Columbia, SC 29223

Table of Contents

Do you have a question about the Style DS-3005 and is the answer not in the manual?

Page 1 If you do not, please contact Shakespeare at (803) 276-5504. SAVE THE CARTON. This carton is designed to be reused to protect your system when not in use. ® ELECTRONICS AND FIBERGLASS DIVISION Shakespeare Electronic Products Group 6111 Shakespeare Rd., Columbia, SC 29223...
Page 2 OPERATION NOTE: If you have the unit sitting on a tailgate or on other metal items, it is recommended that you remove the compass from the base and stand away STEP 1. Connect coax from LNBF to receiver. (15' min.) to find the correct azimuth. Compass is attached to base with velcro.
Page 3 RETURNING ANTENNA TO TRAVEL POSITION STEP 1. Turn receiver and TV OFF. STEP 2. Disconnect coax from receiver. STEP 3. Loosen clamp knobs and put antenna in travel position. See Figure 2. STEP 5. Coil coax under base. See Figure 3. FIGURE 2 NOTE: The carton the system came in is designed to be reused.
Page 4 ANTENNA EXPLODED PARTS VIEW Below is the exploded parts view for the 18"/26" portable satellite system. If you require a replacement part, call Shakespeare at (803) 276-5504. 2745309 46 cm Reflector (4) 2160361 5/16-18 x 5/8" Flat Head Bolt 2753065 25' Coax 2160353 (4) 2160230...
