  • Page 1 Code 505087 AXMINSTER Trade SERIES T-2000CK 1hp Cyclone Extractor...

  • Page 2: Declaration Of Conformity

    Meta International Co., Ltd No. 38-46, Ya Tan Road., Ta Ya Hsiang. Taichung Hisien, Taiwan, R.O.C. Low Voltage Directive: 2006/95/EC EN 60204-1: 2006+A1: 2009 Model Number: T-2000CK (DUST COLLECTOR) The symbols below advise that you follow Warning the correct safety procedures when using this machine.

  • Page 3: What's Included

    What’s Included Quantity Item Model Number T-2000CK 1 No 1hp Cyclone Extractor (Code: 505087) Part Part 1 No Motor Assembly 4 No Bin Castor Wheels 3 No Upper Leg Square Tubes 3 No Castor Wheels 3 No Lower Leg Square Tubes...
  • Page 4 What’s Included...
  • Page 5 What’s Included...

  • Page 6: Specific Safety For Dust Extractors

    General Instruction for 230V Machines Good Working Practices/Safety or around a sharp edge. If the work you are carrying The following suggestions will enable you to observe out is liable to generate flying grit, dust or chips, wear good working practices, keep yourself and fellow workers the appropriate safety clothing, goggles, gloves, masks safe and maintain your tools and equipment in good etc.

  • Page 7: Specification

    NOTE: ALWAYS USE MANUFACTURERS WASTE bAGS WITH THIS MACHINE! Specification Model T-2000CK Rating Trade Power 0.75 kW (230V, 1ph) Air Flow 1,100m³/hr...
  • Page 8 Assembly Instructions Having unpacked the boxes, put all components where Step 2 Locate the three leg bracket connectors (5) and they are readily to hand. Locate the motor assemby (1), the lower leg square tubes (3), slide one of the connectors the upper and lower leg square tubes (2-3), cross support down into one of the leg tubes (3) and line up the lower brackets (4), leg connectors (5), angle brackets (6), 5/16"...
  • Page 9 Assembly Instructions Step 4 Locate the angle brackets (6), place the bracket flat against the upper square tube (2), line up the pre-drilled holes and secure with two button head bolts (f ), see fig 07. Repeat on the process for the opposite side and carry on for the remaining legs.
  • Page 10 Assembly Instructions Fig 14-15 You will require the bin (9), bin castor wheels (21), bin lever clamps with Phillips screws and nuts (23), bin handle (17), 1/4" domed nuts (c), 1/4" Phillips screws (g), dust bag (20), flexible hose (8) and large jubilee clips (k). Step 10 Turn the bin (9) on its side and screw on the four castor wheels (21) into the threaded holes to the base of the bin and tighten the nuts using the supplied spanner...
  • Page 11 Assembly Instructions Step 12 Turn the cyclone assembly upright on its wheels, Step 14 Locate the dust bag (20), open the bag and place it inside the bin (9), see fig 25. (Make sure the bag is tucked over the edge of the bin) WARNING! THE MACHINE IS HEAVY YOU ARE ADVISED TO SEEK HELP! Fig 25...
  • Page 12 Assembly Instructions You will require the steel ducting (12), steel ducting seal Step 18 Locate shaker paddle hande (15), loosen the grub (18), 5/16" button head Hex bolts (e), 5/16" button head screw to the side of the machined aperture using the Hex bolt (f ), air filter cartridge (14) and shaker paddle supplied Hex key (l), slide the handle (15) onto the shaker handle (15).
  • Page 13 (16), see fig 40. Fig 40 If the extractor fails to start up or any other strang noises apart from vibraction sounds, contact the “Technical Sales” for support. Phone: 03332 406406 Email: technical@axminster.co.uk...

  • Page 14: Overview Description

    Overview Description NVR switch assembly Motor Assembly Inlet Moulding Upper Leg Square Tube Air Filter Cartridge Lower Leg Square Tube Shaker Paddle Handle Cross Support Bracket Manometer Extraction Drum Bin Handle Flexible Hose Dust Bag Securing Clip Dust Bag Bin Cover Bin Castor Wheel Extraction Funnel Castor Wheel...
  • Page 15 Overview Description NVR switch assembly with (O) indicating (OFF) and (I) indicating (ON). For emergencies “SLAP” the shroud Bin lever clamp (23), pull up the handle to release bin. down to “STOP” the machine. Inlet moulding (13), with lid Shaker handle lever (15), move this handle from side to side to remove dust build up from inside the air filter (14).
  • Page 16 Operating and Adjustments Levelling the Extractor Fig 43 If you find the extractor castors (22), is not in contact with the floor you can adjust them by loosening the locking nut beneath the castors pivot assembly then rotate each castor in turn, in or out until correct then retighten the locking nut to secure the castors (22) in position, see fig Fig 42 indicating mark...

  • Page 17: Maintenance

    Maintenance or fraying is occurring, replace the bag. WARNING! bEFORE CARRYING OUT ANY MAINTENANCE DISCONNECT THE CYCLONE • Check the motor for dust, sawdust, shavings etc, ExTRACTOR FROM THE MAINS SUPPLY build up. If this has occurred, clean with a vacuum cleaner.
  • Page 18 Weekly LEV System Maintenance Log REMOVE AND CLEAN FILTERS REMOVE AND CLEAN FILTERS...
  • Page 19 Weekly LEV System Maintenance Log REMOVE AND CLEAN FILTERS REMOVE AND CLEAN FILTERS Nearly 14 months it is now a legal requirement to have your system tested and certified...
  • Page 20 LEV Testing Why should I bother with LEV? The law says you must control the risks from these substances (the Control of Substances Hazardous to Health (COSHH) Regulations). Installing LEV may help you to do this. For more information about other ways of eliminating or reducing airborne contamination at work look, at HSE’s COSHH website, hse.gov.uk/coshh.

  • Page 21: Parts Drawing/List

    Parts Drawing/List...
  • Page 22 Parts Drawing/List Description Specification Q’TY Hose Clamp 1-1/2” Flange Nut 1/4” 1/4” Spring Washer 1/4” Lock Nut Steel Clamp Dia. 370 Power Cord W/ Plug 5/16” Square Pad PC Board Leg Connecting Bracket Drum Lid Round Clamp Dia. 347 Round Collector Outlet Connector Motor Packing...
  • Page 23 Parts Drawing/List Lock Nut PE Bag Big(101) PE Bag Small Phil. HD Screw 1/4” x 5/8” Phil. HD Screw M5 x 10mm Phil. HD Screw M6 x 10mm Flange Screw 1/4” x 1/2” Button HD Screw 1/4” x 1/2” Phil. HD Screw M6 x 12 Hex Bolt 1/4”...

  • Page 24: Wiring Diagram

    Wiring Diagram...
  • Page 25 Notes...
  • Page 26 Normal wear and tear; misuse, abuse and neglect are excluded and the machine should not have been engineering machines, Axminster Air compressors and Air Tools, and bench top grinders - no modified in any way. Please do not attempt to service the product without first contacting us; we are registration necessary just proof of purchase.
