Page 1: Quick Installation Guide
Quick Installation Guide 19” LCD Screen Observation System with 16 Channel H.264 Compression DVR and 8 Color CCD Camera Kits... -
Page 2: Part 1 - Package Contents
Q-SEE QUICK INSTALLATION GUIDE PART 1 - PACKAGE CONTENTS: Pre-Installed QC40196 User’s 8 Cameras with Stands Hard Drive 19” LCD DVR Manual QSC1353W (3.6mm) Power Supply & Power Supply 8 -Way Splitter 4-BNC (M) – RCA (F) 8- RG59 Cables... - Page 3 Q-SEE QUICK INSTALLATION GUIDE PART 2 - DVR CAMERA AND POWER CONNECTIONS Please note that it is STRONGLY recommended to use a surge protector that is UL-1449 rated. Look for a clamping voltage of 330 or lower, a Joule rating of at least 400 and a response time of 10 nanoseconds or less.
- Page 4 Q-SEE QUICK INSTALLATION GUIDE Part 3 – DVR Controls: Front Panel 1. Boot Up/Shut Down Button 6. Go Down, Decrease Number, 10. Confirm, Go to Default 2. Power Light PTZ Control Menu 3. IR Remote Receiver 7. Go Left, Playback Control 11.
- Page 5 Q-SEE QUICK INSTALLATION GUIDE Part 4 – Accessing the DVR menus After the system boots up it will go into multiple window mode. Click Enter or left click with the mouse anywhere on the screen and you will bring up the login interface (shown as Pic 4.1) and enter the admin password which is admin by default under the admin login.
- Page 6 Q-SEE QUICK INSTALLATION GUIDE 2. Scheduled Recording: To record on a schedule you would go to the Main Menu, Manual Record and select the cameras on the Schedule line instead of the Manual line in the Manual Record screen shown in Pic 5.1, then go to the Main Menu, click on Settings, and select Schedule.
- Page 7 Q-SEE QUICK INSTALLATION GUIDE After setting up the schedule go to Main Menu, Setting, Detect and this will display the screen shown in Pic 5.7. Under Event Type select Motion Detect, Select your Channel, or All, and select the enable option to enable the camera for motion detection.
- Page 8 Q-SEE QUICK INSTALLATION GUIDE Highlighted dates on the calendar indicates that there are video files available on that day. You can double click on the day to view the file list. You can play back the files in 4 screen or 8 screen mode.
- Page 9 Q-SEE QUICK INSTALLATION GUIDE Questions or Comments? Contact Us: Mailing Address: Customer Service: DPS, Inc. Phone: 877-998-3440 x 538 8015 E. Crystal Dr. Email: cs@dpsi-usa.com Anaheim, CA 92807 Live Chat from our Website Website: Tech Support: http://www.q-see.com Phone: 877-998-3440 x 539 Fax: Email: ts@dpsi-usa.com...
