GOLDEN STATE INSTRUMENT GS-500 SFVD Specifications

GOLDEN STATE INSTRUMENT CO.
This new camera combines two powerful technologies
and puts them on one camera. Our "Starforce"
technology provides great low light performance enabling
the camera to see in color in the dark with a minimum
illumination of 0.0001 LUX. With Sony's Super HAD II
CCD gives the camera unbeatable sensitivity. With an
Ultra High 600 TVL of color resolution gives this camera
superior image quality unmatched by others. The 3 axis
mount makes this a very versatile camera that can be
placed on ceilings or walls with very little effort.
Features:

1/3" SONY Super HAD II CCD

Ultra High 600 TVL Color Resolution

Super BLC (Back Light Compensation)

2.8-11mm Auto-Iris Varifocal Lens

Ultra Advanced DNR (Dynamic Noise Reduction)

Minimum Illumination 0.0001 LUX

Starforce DSP (Digital Signal Processor)
Specifications:
Signal System
Image Sensor
DSP (Digital Signal Processor
Effective Pixels
Scanning System
Scanning Frequency (V)
Resolution
Min. Illumination
Light Compensation
S/N Ratio
Shutter Speed
Video Output
Sync System
Voltage
Power Consumption
Dimensions
Weight
Operating Temperature
3002 Dow Ave Suite 228
Tustin, CA 92780 USA
Starforce Dome Camera
NTSC
1/3" SONY Super HAD II
Starforce
768(H) x 494(V)
525 Lines 2:1 Interlace
59.94Hz
Ultra High 600 TVL
0.0001 LUX
BLC (Back Light Compensation)
More than 67dB
1/60 ~ 1/1000,000 sec.
1.0 Vp-p (75Ω)
Internal / Line Lock
Dual Voltage 12VDC/24VAC
180 mA
4.65" Diameter 3.54" Height
3.38 lbs
-4°F to 122°F
www.goldenstateinst.com
GS-500 SFVD
Vandal Dome X-Y-Z Axis Mount
2.8-11mm Auto-Iris Varifocal Lens
600 TVL Color Camera

Vandal Proof Dome

X-Y-Z, 3 Axis Mount

Dual Voltage 12VDC / 24 VAC

OSD (On Screen Display) Menu Controls

Turbo AGC (Automatic Gain Control)

Video Test Jack

Sharpness and Mirror Functions
WARNING:
Do Not Point Camera Directly
into the sun.
Do Not cut video or power
wires
Observe Correct Voltage and
Polarity
Failure to Observe Warnings
May Void Warranty
