GOLDEN STATE INSTRUMENT GS-3200 CVIR Specifications

GOLDEN STATE INSTRUMENT CO.
This new camera uses P.O.D. (Precision OSD DSP)
technology. This technology enables the user to precisely
fine tune all the camera functions according to the
application. No matter what the conditions are, you will
be able to achieve optimum picture quality. With a High
480 TVL of color resolution gives this camera superior
image quality unmatched by others. The 3 axis mount
makes this a very versatile camera that can be placed on
ceilings or walls with very little effort.
Features:

1/3" SONY Super HAD CCD

High 480 TVL Color Resolution

Super BLC (Back Light Compensation)

2.8-11mm Auto-Iris Varifocal Lens

30 IR LED's (60-80ft Illumination)

Very low smear, 6dB better than average

Built-in new 20 bit DSP (Digital Signal Processing)
Specifications:
Signal System
Image Sensor
Series
Effective Pixels
Scanning System
Scanning Frequency (V)
Resolution
Min. Illumination
Light Compensation
S/N Ratio
Shutter Speed
Video Output
Sync System
Voltage
Power Consumption
Dimensions
Weight
Operating Temperature
3002 Dow Ave Suite 228
Tustin, CA 92780 USA
Infrared LED Dome Camera
NTSC
1/3" SONY Super HAD
P.O.D.
768(H) x 494(V)
2:1 Interlace
59.94Hz
High 480 TVL
0.3 LUX (LED Off) | 0 LUX (LED On)
BLC (Back Light Compensation)
More than 50dB (AGC OFF)
1/60 ~ 1/1000,000 sec.
1.0 Vp-p (75Ω)
Internal
12VDC
100 mA (LED's OFF) | 350mA (LED's ON)
4.5" Diameter 3.5" Height
0.5 lbs
-10°C to 50°C
www.goldenstateinst.com
GS-3200 CVIR
Indoor Dome X-Y-Z Axis Mount
2.8-11mm Auto-Iris Varifocal Lens
480 TVL Day/Night Color Camera

Indoor Dome

X-Y-Z, 3 Axis Mount

12VDC

OSD (On Screen Display) Menu Controls

Turbo AGC (Automatic Gain Control)

Video Test Jack

Sharpness and Mirror Functions
WARNING:
Do Not Point Camera Directly
into the sun.
Do Not cut video or power
wires
Observe Correct Voltage and
Polarity
Failure to Observe Warnings
May Void Warranty
