I/O Ports

The illustration below shows a side view of the built-in I/O ports
on the motherboard.
COMPONENTS
CPU Fan connector
Two 240-pin DDR2 SDRAM sockets
Two 184-pin DDR SDRAM sockets
Standard 24-Pin ATX Power connector
IDE connector
Chasis cooling fan connector
Serial ATA connectors
Clear CMOS jumper
IDE RAID connectors (optional)
Standard 4-Pin ATX Power connector
Front Panel Switch/LED header
Floppy Disk Drive connector
Infrared header
Front Panel USB headers
Speaker header
32-bit PCI slots
Auxliary cooling fan connector
SPDIF out header
Analog Audio Input header
Front Panel Audio header
AGPro slot *See page 25 for details
PCI Express x1 slots
PCI Express x16 graphics card slot
Northbridge cooling fan connenctor
