Motherboard User's Guide
Serial ATA
Four Serial ATA Connectors
Transfer rate exceeding best ATA (~150 MB/s) with
scalability to higher rates
Low pin count for both host and devices
Azalia Audio Codec
Compliant with Azalia specification, supporting 8 channel
DACs with SNR 100dB
Compabilities: 192/96/48/44.1 KHz with 24/20/16 bits
8 Smart Jack I/O port support
Extensive jack detection via RNM (resistors network
method) that can be used to monitor the plugging status of
each jack
Digital S/PDIF OUT & IN support
Onboard I/O Ports
The motherboard has a full set of I/O ports and connectors:
Two PS/2 ports for mouse and keyboard
One serial port
One parallel port
One LAN port (optional)
Four back-panel USB2.0 ports
Audio jacks for microphone, line-in and 8-ch line-out
Fast Ethernet LAN (optional)
Onboard Gigabit LAN:
− Integrated 10/100/1000 transceiver
−
Auto-Negotiation with Next page capability
−
Supports Full Duplex flow control (IEEE 802.3x), and
IEEE 802.1Q VLAN tagging
− Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE
802.3ab
Onboard 10/100Mbps Ethernet LAN:
− − − − − 10 Mb/s and 100 Mb/s operation
4
