Motherboard User's Guide
915P chipset can only support 256-Mb, 512-Mb and 1-Gb
DDR technologies for x8 and x16 device, NOT support 128-Mb
DDR technology. That is, 256 MB Double Side Memory Module
& 128 MB Single Side Memory Module are NOT support.

Key Features

The key features of this motherboard include:
LGA775 Socket Processor Support
Supports the latest Intel Pentium 4/Celeron Series
processors with Hyper-Threading Technology
Supports up to 800 MHz Front-Side Bus
Hyper-Threading technology enables the operating system
into thinking it's hooked up to two processors, allowing two
threads to be run in parallel, both on separate 'logical'
processors within the same physical processor.
Chipset
There are Intel 915P Northbridge and Intel I/O Controller
Hub 6 (ICH6) in the chipsets in accordance with an innovative
and scalable architecture with proven reliability and performance.
Supports one PCI Express x16 for Graphics Interface
Supports 256-Mb, 512-Mb and 1-Gb DDR/DDR2 technolo-
gies for x8 and x16 devices
Compliant with Serial ATA 1.0a specification.
Integrated USB 2.0 Host Controller supporting up to eight
USB 2.0 ports; integrated LAN controller supporting 10/
100Mb/s Ethernet; integrated IDE controller supports Ultra
ATA100/66/33
Compliant with Azalia specification supporting 8 Channels
of audio outputs
Compliant with PCI 2.3 specificaiton
2
