American Standard Shower Systems 1660.502 Specification Sheet

Model #
Description/Features
1660.525
"TREVI" PERSONAL SHOWER
Self Cleaning Patented Design: Flexible ring
with spray holes prevents lime scale build up.
Spray Pattern: Variable spray adjusts from a
conventional spray to an aerated flow to a
massage action.
Lightweight, Ergonomic Design: For a
sure grip even with wet, soapy hands.
Flow Restrictor: 2.5 gpm/9.5L/min.
1660.550
3 FUNCTION RAIN HAND SHOWER
• 4-3/4" Face diameter
• Easy clean surface
• Adjusts from Gentle Rain to Hard Rain to Massage
• 2.5 gpm/9.5L/min. flow restrictor
3 FUNCTION MODERN HANDSHOWER
1660.510
• Variable spray adjusts from a conventional
spray to a gentle aerated flow to a
massage action
• Easy to clean spray face
1660.500
"SOFT" PERSONAL SHOWER
Spray Pattern: Variable spray adjusts from a
conventional spray to a champagne flow.
Simple Spray Pattern Adjustment: Spray
patterns can be changed with a flick of the thumb.
A true one-handed operation.
Lightweight, Ergonomic Design: For a sure grip
even with wet, soapy hands.
Flow Restrictor: 2.5 gpm/9.5 L/min.
1660.502
WATER-SAVING "SOFT" PERSONAL SHOWER
Water-Saving: Saves up to 40% in water usage.
Spray Pattern: Variable spray adjusts from a
conventional spray to a champagne flow.
Simple Spray Pattern Adjustment: Spray
patterns can be changed with a flick of the thumb.
A true one-handed operation.
Lightweight, Ergonomic Design: For a sure grip
even with wet, soapy hands.
Flow Restrictor: 1.5 gpm/5.7 L/min.
© 2008 AS America Inc.
HAND HELD PERSONAL SHOWERS
Finishes
.002 Polished Chrome
.068 Blackened Bronze (PVD)
.099 Polished Brass (PVD)
.295 Satin Nickel (PVD)
.002 Polished Chrome
.008 Polished Nickel
.068 Blackened Bronze (PVD)
.075 Stainless Steel (PVD)
.099 Polished Brass (PVD)
.295 Satin Nickel (PVD)
.002 Polished Chrome
.295 Satin Nickel (PVD)
.002 Polished Chrome
.068 Blackened Bronze (PVD)
.075 Stainless Steel (PVD)
.099 Polished Brass (PVD)
.295 Satin Nickel (PVD)
.002 Polished Chrome
.068 Blackened Bronze (PVD)
.075 Stainless Steel (PVD)
.099 Polished Brass (PVD)
.295 Satin Nickel (PVD)
F109
SHOWER SYSTEMS
Roughing-In
Dimensions
1/2" NPSM
42mm
(1-5/8)
250mm
(9-7/8)
1/2"
NPSM
1/2" NPSM
1/2" NPSM
57mm
(2-1/4)
