Intel
82540EM GbE
Ethernet Controller
ATI RageXL Controller
4-pin 12V. ATX Power Connector
32bit/33MHz PCI Slot x1
System Fan Connector 2
64bit/33MHz PCI Slot x3
64bit/33MHz (3.3V) PCI Slot x1
(AX4S Plus-U supports ZCR Function)
Front Panel Connector
Adaptec AIC-7901X Ultra 320
SCSI Controller (AX4S Plus-U only)
68pin SCSI connector(AX4S Plus-U only)
Flash ROM BIOS
JP15 Boot Block Select Jumper
Buzzer
AOpen reserves the right to revise all the specifications and information contained in this documentation, which is subject to change without notice.
SPP/EPP/ECP Parallel Port
PS/2 Mouse
Connector
RJ45 LAN
Jack
PS/2 Keyboard
COM 1 Port
Connector
CPU2
CPU1
CPU 2
1 GbE
Ethernet
Port
COM 2 Port
USB1.1
VGA Port
Port
System Fan Connector 3
184-pin DIMMx4 supports ECC DDR200
/ 266 maximum up to 4GB
478-pin CPU Socket
®
FSB400/533MHz Intel
P4 CPU
Supported
Server Works GC-SL Chipset
North Bridge:Server Works GC-SL
CPU Fan Connector with H/W
Monitoring
System Fan Connector 1
JP14 CMOS Clear Jumper
South Bridge: Server Works CSB6
ATX Power Connector
USB Connector
FDD Connector
IDE Connector x 2
Advertisement
Table of Contents
Related Manuals for AOpen AX4S-U
Summary of Contents for AOpen AX4S-U
- Page 1 ATX Power Connector Flash ROM BIOS USB Connector JP15 Boot Block Select Jumper FDD Connector IDE Connector x 2 AOpen reserves the right to revise all the specifications and information contained in this documentation, which is subject to change without notice.
-
Page 2: Installing Cpu
1. Installing CPU Pull up the CPU socket lever and up to CPU socket lever 90-degree angle. Locate Pin 1 in the socket and look for a (golden) cut edge on the CPU upper interface. Everything you need to boot Match Pin 1 and cut edge. -
Page 3: Connecting Ide And Floppy Cables
3. Connecting IDE and Floppy Cables 5. Setting CPU Voltage & Frequency Connect 34-pin floppy cable and 40-pin, 80-wire IDE cable to floppy connector FDC and Setting CPU Core Voltage IDE connector. Be careful of the pin1 orientation. Wrong orientation may cause system This motherboard supports CPU VID function. -
Page 4: Connecting Atx Power Connector
6. Install DIMM Modules 8. Connecting Front Panel Connector Attaching such as power switch, reset switch, HDD LED connector, etc.… to This motherboard has four 184-pin DIMM sockets that allow you to install PC200/266 corresponding pins. Registered memory up to 4.0GB. DIMM 1 DIMM 2 Reset Switch... - Page 5 10. PC99 Color Coded Back Panel 12. Support 1Gbps LAN onboard The Intel 82540EM integrates Intel’s fourth-generation Gigabit MAC design with fully The onboard I/O devices are PS/2 Keyboard, PS/2 Mouse, COM1, VGA, Printer and integrated, physical-layer circuitry to provide a standard IEEE 802.3 Ethernet interface for USB1.1.
-
Page 6: Part Number And Serial Number
14. Support the 2 USB1.1 Channel 16. Part Number and Serial Number This motherboard provides two USB channels to link USB devices, such as mouse, The Part Number and Serial number are printed on bar code label. You can find this keyboard, modem, printer, etc. - Page 7 Online Manual: Please check the manual carefully and make sure the jumper settings and installation procedure are correct. If you encounter any trouble to boot you system, follow the http://english.aopen.com.tw/tech/download/manual/default.htm procedures accordingly to resolve the problem. Test Report: We recommend choosing board/card/device from the Start compatibility test reports for assembling your PC.
- Page 8 Dear Customer, Thanks for choosing AOpen products. To provide the best and fastest service to our customer is our first priority. However, we receive numerous emails and phone-calls worldwide everyday, it is very hard for us to serve everyone on time.
