- Page 1 REFRIGERATOR FRIGORÍFICO ZKC 54 L INSTRUCTION BOOKLET MANUAL DE INSTRUÇÕES 2222 256-06/2...
-
Page 2: General Safety
Always ensure that there is adequate This product should be serviced by an authorised ventilation as a failure to do this will result in ZANUSSI Service Centre, and only genuine spare possible food loss. See installation instructions. parts should be used. - Page 3 CONSERVATION Environment Protection This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. Avoid damaging the cooling unit, especially at the rear near the heat exchanger.
-
Page 4: Table Of Contents
CONTENTS Description of the appliance Installation Positioning Before using Location Door reversibility Fitting a decorative door panel The electrical connections Technical specification Operation Setting the temperature Health and safety guidelines Fresh food refrigeration Cool check temperature guide Starting the appliance Everyday use of the cool check temperature guide Defrosting... -
Page 5: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE A - Dairy compartment B - Shelf with egg tray C - Bottle storage shelf D - Salad drawers E - Glass shelf (for storing meat) F - Cool check temperature guide G - Storage shelves H - Thermostat control... -
Page 6: Installation
INSTALLATION Before using Warning Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to IF YOU ARE DISCARDING AN OLD APPLIANCE 0.5 litre of water). Do not use soap or detergent as the THAT HAS A LOCK OR CATCH ON THE DOOR, smell may linger. -
Page 7: Location
Location Fig. 1 This appliance is designed to be built-in to a space having the dimensions given in Fig. 1. 100-170 D506 The height of the appliance can be altered if required Fig. 2 by means of adjustable feet situated at its base (Fig. -
Page 8: Door Reversibility
Door reversibility Fig. 3 Remove the two screws which fix the upper hinge to the door. Carefully lean the appliance on its back and remove the plastic insert (Fig. 3). Remove the two screws which fix the lower hinge to the door. -
Page 9: Fitting A Decorative Door Panel
Fitting a decorative door panel Important: The components needed to fit the decorative panel have been pre-fitted on the appliance. The brackets are secured to the panel by means of the 7 Ø 3.5x13 screws supplied. Before starting to fit the panel, remove the large top bracket by unscrewing the screws and adjusting pins pre-fitted on the appliance door. - Page 10 Insert the adjusting pins (B-Fig. 7) into their locations Fig. 7 in the door and screw them in. D532 Fig. 8 Hook the decorative panel onto the top part of the door, inserting the pins (B) (on the door) into the elongated holes (1) (in the top bracket fitted to the panel) (Fig.
- Page 11 Once the door has ben correctly aligned, tighten the Fig. 11 holding nuts on the fixing brackets and attach the appliance to the adjacent units and the bottom of the work surface (Fig. 11). D517 If the appliance has been fitted into a space 820 mm Fig.
-
Page 12: The Electrical Connections
A replacement cover/carrier must be obtained from this safety measure not be observed. your local Zanussi Service Force Centre whose address is listed in the Customer Care Booklet which If the plug that is fitted to your appliance is not accompanies your instruction manual. -
Page 13: Technical Specification
TECHNICAL SPECIFICATIONS POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOTAL POWER ABSORBED 110 W AVERAGE DAILY UNITS ELECTRICITY* 0.80 kWh GROSS CAPACITY 155 l NET CAPACITY 153 l * This figure is based on standard test results in accordance with European Standard EN153. Actual consumption will depend on how the appliance is used and where it is located. -
Page 14: Operation
OPERATION Setting the temperature The temperature inside the refrigerator is regulated by a thermostat with 6 temperature positions and one «OFF» ( O ) position. Position 1 = minimum coldness Position 6 = maximum coldness Turn the thermostat dial to the required position; the intermediate position is usually the most suitable (3- The thermostat setting can vary as the temperature inside the refrigerator compartment depends on the... -
Page 15: Health And Safety Guidelines
HEALTH AND SAFETY GUIDELINES Because of consumer demand, preservatives have Remove suspect food from your refrigerator and been removed from many pre-prepared foods. This clean the interior with a solution of bicarbonate of together with the changes in shopping habits to a soda in warm water (5ml to 0.5 litre of water). -
Page 16: Fresh Food Refrigeration
Fresh food refrigeration To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if it has a strong flavour. Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation through them. -
Page 17: Cool Check Temperature Guide
fluctuation may safe temperatures for all food types. The guide occur. A Zanussi fridge is designed to cope with any consists of a temperature sensitive strip sealed in the changes in temperature but under certain conditions shelf trim. -
Page 18: Defrosting
Defrosting The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via a pipe, into a bowl located at the base of the back of the appliance, where it evaporates. Fig. 17 Important To prevent the water overflowing and dripping onto the food inside, periodically clean the defrost water drain hole in the middle of the refrigerator compartment channel (Fig. -
Page 19: Maintenance And Cleaning
Unscrew the bulb and replace it with a new 15 watt bulb (available from your nearest Zanussi Service Centre). Replace the light cover by sliding it into its original position and replacing the screw. -
Page 20: What Happens If Something Goes Wrong
If, after the above checks, there is still a fault, call your local Zanussi Service Centre, whose address can be found in the accompanying Customer Care Booklet, and can also be found in your local telephone directory under «Z». -
Page 21: Guarantee Conditions
We, Zanussi Ltd., undertake that if, within twentyfour bags. months of the date of the purchase, this ZANUSSI appliance or any part thereof is proved to be defective Costs incurred for calls to put right machines...
