Summary of Contents for Zanussi ZK 60/30 RM
- Page 1 REFRIGERATOR- FREEZER ZK 60/30 RM INSTRUCTION BOOKLET 2222 003-91...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or usng this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings of these warnings contact the Customer Care Department. Prior to installation ¥... -
Page 3: Table Of Contents
CONTENTS Instructions for the user Instructions for the installer Important Safety Information Technical specification Description of the appliance Installation Operation Positioning Before use Rear Spacers Control panel Starting your appliance Electrical Connection Setting the temperature Door Reversal Ambient Temperature Switch The freezer compartment Freezing fresh food Frozen food storage... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE F A S T F R E E Z A- Thermostat B- Interior light C- Dairy compartment D- Can storage shelves E- Bottle storage shelf F - Freezer calender G- Frozen food storage H - Freezing fresh food I- Salad crispers J- Glass shelf with CrispÕn fresh filter K- Cool Check Temperature Guide... -
Page 5: Operation
OPERATION Before using Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Control panel C. -
Page 6: Frozen Food Storage
In any 24 hours you can freeze up to 10 kg. Defrosted cooked food must never be refrozen. Place food to be frozen in the upper drawer of the Making ice cubes freezer as this is the coldest part. The appliance is provided with two plastic ice cube Frozen food storage trays. -
Page 7: Cold Accumulator
Cold accumulator The freezer contains one cold accumulator. Place the cold accumulator in the FAST FREEZE compartment see the diagram. The cold accumulator increases storage times in the event of a power cut or breakdown. Removal of this unit wll increase the capacity of the fast freezing compartment but will reduce storage times in the event of a power cut or breakdown. -
Page 8: Movable Shelves
Movable shelves The walls of the refrigerator have runners so that shelves can be positioned as desired. For better use of space, the front half-shelves can lie over the rear ones. D338 Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be adjusted in height. -
Page 9: Cool Check Guide
Cool Check Guide The guide consists of a temperature sensitive strip sealed in a shelf trim. When the fridge is operating at the safe temperature to store food the guide will appear black. If the temperature rises above this level the guide will show the words TOO WARM. -
Page 10: Hints And Tips
HINTS AND TIPS Energy Saving Advice Normal Operating Sounds ¥ You may hear faint gurgling or bubbling sounds ¥ Do not install the appliance close to sources of when the refrigerant is pumped through the coils heat, such as a boiler or radiator. or tubing at the rear, and to the cooling ¥... -
Page 11: Maintenance And Cleaning
The filters and the glass cover can be washed gently in warm soapy water, they should not be put in the dishwasher. Replacement filters can be purchased as a spare part from your local Zanussi Service Centre. CONDENSER DEFROST TRAY... -
Page 12: Defrosting
Defrosting Refrigerator The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via a pipe, into a tray located at the back of the appliance above the compressor, where it evaporates. Important To avoid defrost water overflowing into the fridge, periodically clean the water discharge hole in the centre of the V shaped drip collector at the back of the refrigerator compartment behind the salad... -
Page 13: Something Not Working
SOMETHING NOT WORKING Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Before contacting your local Service Force Centre, check the following points: Symptom Solution No power to the appliance... -
Page 14: Service And Spare Parts
The model and serial number of the appliance (found on the rating plate) The purchase date CUSTOMER CARE DEPARTMENT For general enquiries concerning your Zanussi appliance or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone as follows:- Customer Care Department... -
Page 15: Guarantee Conditions
Standard guarantee conditions We, Zanussi, undertake that if within 12 months of the date of the purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 16: Technical Specification
TECHNICAL SPECIFICATIONS DIMENSIONS Height Width 59.5 cm Depth POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOTAL POWER ABSORBED 100 W AVERAGE DAILY UNITS ELECTRICITY * 1.0 kWh GROSS CAPACITY Fridge 174 l Freezer 88 l NET CAPACITY Fridge 170 l Freezer... -
Page 17: Installation
INSTALLATION Important IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. -
Page 18: Electrical Connection
A replacement cover/carrier must be obtained from WARNING: THIS APPLIANCE MUST BE your local Zanussi Service Force Centre whose EARTHED. address is listed in the Customer Care Booklet which The manufacturer declines any liability should accompanies your instruction manual. -
Page 19: Door Reversal
Door reversal directions 1. Disconnect from the electricity supply. 2. Gently lay the fridge/freezer on its back with the top held away from the floor by 5-8 cm (2-3 inches) of packing; 3. Remove the ventilation grill (D). 4. Remove the plug (F) from the ventilation grill (D) and replace it on the opposite side. - Page 20 This file has been downloaded from: www.UsersManualGuide.com User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes.. Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide, manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product, documentation manual, user maintenance, brochure, user reference, pdf manual...
