- Page 1 REFRIGERATOR- FREEZER ZK 56/48 R ZK 56/48 RAL INSTRUCTION BOOKLET 2222 057-13...
-
Page 2: Important Safety Information
Repairs carried out by inexperienced persons may cause injury or During Use serious malfunctioning. Refer to your local Zanussi Service Force Centre and always insist ¥ This appliance is designed for domestic use only, on genuine spare parts. -
Page 3: Table Of Contents
CONTENTS Instructions for the User Instructions for the Installer Important Safety Information Technical Specification Description of the appliance Installation Operation Positioning Before use Rear Spacers Setting the temperature The freezer compartment Electrical Connection Freezing fresh food Door Reversal Frozen food storage Thawing Ice cube tray holder Fresh food refrigeration... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE A- Thermostat control for fridge and freezer compartments B- Dairy compartment C- Storage shelf D- Bottle storage shelf E- Freezer calendar F- Wire shelves G- Cool Check H- Glass shelf I- Salad drawers J- Pizza box drawer K- Freezing fresh food compartment L- Freezing/Storage compartments... -
Page 5: Operation
OPERATION Before using Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Setting the temperature The temperature inside the refrigerator is regulated D710 by a thermostat with 6 temperature positions and... -
Page 6: Thawing
polythene bags to exclude as much air as possible. Warning Milk bottles: these should have a cap and should be stored in the bottle rack on the door. Do not put carbonated liquids, (fizzy drinks etc.), in the freezer compartment. Normal Operating Sounds Water ices, if consumed immediately after removal from the freezer, can cause low temperature skin... -
Page 7: Positioning The Door Shelves
Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be adjusted in height. To do this proceed as shown in the diagram. PR260 PR263 Positioning the inner shelves The walls of the refrigerator are equipped with runners so that shelves can be positioned as desired. -
Page 8: Use And Features Òcrispõn Freshó Filter
The filters and the glass cover can be washed gently in warm soapy water, they should not be put in the dishwasher. Replacement filters can be purchased as a spare part from your local Zanussi Service Centre. D711 Cool Check Guide The guide consists of a temperature sensitive strip sealed in a shelf trim. -
Page 9: Health And Safety Guidelines
Hints and Tips ¥ The guide is only suitable for use in the model supplied. ¥ The guide will not operate in the freezer compartment. ¥ When cleaning the shelf take care not to immerse in water, and wipe away any spills. HEALTH AND SAFETY GUIDELINES Because of consumer demand, preservatives refrigerator door. -
Page 10: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried Changing the light bulb out, DISCONNECT the appliance from the ELECTRICITY supply. Should the interior light fail to work, first switch off the appliance and disconnect from the electricity supply, then replace the bulb as follows;... - Page 11 Freezer When the frost has reached a thickness of up to 4mm it can be removed using the ice scraper provided with the appliance. During this operation it is not necessary to disconnect the appliance from the mains and remove the food. Never use metal tools for this operation.
-
Page 12: Something Not Working
SOMETHING NOT WORKING Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Before contacting your local Service Force Centre, check the following points: Symptom Solution No power to the appliance... -
Page 13: Service And Spare Parts
The model and serial number of the appliance (found on the rating plate) The purchase date CUSTOMER CARE DEPARTMENT For general enquiries concerning your Zanussi appliance or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone as follows:- Customer Care Department... -
Page 14: Guarantee Conditions
Standard guarantee conditions We, Zanussi, undertake that if within 12 months of the date of the purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 15: Technical Specification
TECHNICAL SPECIFICATIONS DIMENSIONS Height 171.5 Width 54.5 cm Depth POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOTAL POWER ABSORBED 150 W AVERAGE DAILY UNITS ELECTRICITY * 1.31 kWh GROSS CAPACITY Fridge 167 l Freezer 110 l NET CAPACITY Fridge 165 l Freezer... -
Page 16: Installation
INSTALLATION Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. -
Page 17: Electrical Connection
A replacement cover/carrier must be obtained from WARNING: THIS APPLIANCE MUST BE your local Zanussi Service Force Centre whose EARTHED. address is listed in the Customer Care Booklet which The manufacturer declines any liability should accompanies your instruction manual. -
Page 18: Door Reversal
Door reversal directions 1. Disconnect from the electricity supply. 2. Remove all loose items, including food, store food in a cool place. 3. Gently lay the fridge/freezer on its back with the top held away from the floor by 5-8 cm (2-3 inches) of packing;...
