Owner's Manual

Lincoln MKT

Litho in U.S.A.

EE9J 19A321 AA

Table of Contents

Summary of Contents for Lincoln MKT 2014

Page 1 2 0 1 4 M K T O w n e r ’ s M a n u a l lincolnowner.com lincolncanada.com January 2014 Second Printing Owner’s Manual Lincoln MKT Litho in U.S.A. EE9J 19A321 AA...
Page 2: Table Of Contents
Table of Contents Introduction Child Safety Child seat positioning ........20 Booster seats .
Page 3 Table of Contents System status.........75 Remote start, MyKey .
Page 4: Table Of Contents
Table of Contents Windows and Mirrors Power windows ........107 Exterior mirrors .
Page 5 Table of Contents Auxiliary Power Points Storage Compartments Center console ........172 Overhead console .
Page 6: Table Of Contents
Table of Contents Cruise Control Using cruise control ........218 Using Adaptive Cruise Control.
Page 7 Table of Contents Roadside Emergencies Getting roadside assistance ......268 Hazard warning flashers ....... .269 Fuel cut-off switch .
Page 8: Table Of Contents
Table of Contents Vehicle Care Cleaning products........321 Cleaning the exterior .
Page 9 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2013 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013...
Page 10: Introduction
Introduction ABOUT THIS MANUAL Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it.
Page 11 Introduction SYMBOL GLOSSARY WARNING: You risk death or serious injury to yourself and others if you do not follow the instruction highlighted by the warning symbol. These are some of the symbols you may see on your vehicle. Symbol Description Symbol Description Symbol...
Page 12 Introduction Symbol Description Symbol Description Symbol Description Fuel pump Fuse Hazard reset compartment warning flasher Heated rear Interior Jack window luggage compartment release Lighting Low tire Maintain control pressure correct fluid warning level Panic alarm Parking aid Parking system brake system Power Power Power...
Page 13 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
Page 14 EDR. Ford Motor Company and Ford of Canada do not access event data recorder...
Page 15 If you do not want Ford or its vendors to receive this information, do not activate the service. For more information, see Traffic, Directions and Information, Terms and Conditions.
Page 16 Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, see the terms and conditions of the Ford Warranty.
Page 17 Introduction Special Instructions For your added safety, your vehicle is fitted with sophisticated electronic controls. WARNING: Please read the Supplementary Restraints System chapter. Failure to follow the specific warnings and instructions could result in personal injury. WARNING: Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger airbag.
Page 18 Introduction EXPORT UNIQUE (NON–UNITED STATES/CANADA) VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the features and options that are described in this owner’s manual. A market unique supplement may be supplied that complements this book.
Page 19: Child Safety
NHTSA and other safety organizations, or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consulting your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in your vehicle.
Page 20 Child Safety Recommendations for Safety Restraints for Children Recommended Child size, height, weight, or age restraint type Small Children who have outgrown or no Use a children longer properly fit in a child safety belt-positioning seat (generally children who are less booster seat.
Page 21: Child Seat Positioning
Child Safety CHILD SEAT POSITIONING WARNING: Airbags can kill or injure a child in a child seat. Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the vehicle seat upon which the child seat is installed all the way back.
Page 22 Child Safety WARNING: Never place, or allow a child to place, the shoulder belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash. WARNING: To avoid risk of injury, do not leave children or pets unattended in your vehicle.
Page 23: Booster Seats
Child Safety BOOSTER SEATS WARNING: Never place, or allow a child to place, the shoulder belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash.
Page 24 Child Safety Types of Booster Seats • Backless booster seats If your backless booster seat has a removable shield, remove the shield. If a vehicle seating position has a low seat back or no head restraint, a backless booster seat may place your child’s head (as measured at the tops of the ears) above the top of the seat.
Page 25 Child Safety Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 26: Installing Child Seats
Child Safety INSTALLING CHILD SEATS Child Seats Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat) for infants, toddlers or children weighing 40 pounds (18 kilograms) or less (generally age four or younger). Using Lap and Shoulder Belts WARNING: Airbags can kill or injure a child in a child seat.
Page 27 Child Safety • Keep the buckle release button pointing up and away from the safety seat, with the tongue between the child seat and the release button, to prevent accidental unbuckling. • Place the vehicle seat upon which the child seat will be installed in the upright position.
Page 28 Child Safety 2. After positioning the child safety seat in the proper seating position, do the following: • Standard safety belt: pull down on the shoulder belt and then grasp the shoulder belt and lap belt together behind the belt tongue.
Page 29 Child Safety 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 30 Child Safety • Inflatable safety belt: grasp the lap portion of the inflatable safety belt and pull upward until all of the belt is pulled out. Note: Unlike the standard safety belt, the inflatable safety belt’s unique lap portion locks the child seat for installation. The ability for the shoulder portion of the belt to move freely is normal, even after the lap belt has been put into the automatic locking mode.
Page 31 1 inch (2.5 centimeters) of movement for proper installation. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed. In Canada, check with your local St. John Ambulance office for referral to a Child Passenger Safety Technician.
Page 32 Child Safety Using Lower Anchors and Tethers for CHildren (LATCH) WARNING: Never attach two child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death.
Page 33 Child Safety • Second row bench seats and third-row passenger side • Second row bench seat (livery) The LATCH anchors are located at the rear section of the rear seat between the cushion and seat back below the symbols as shown. Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments.
Page 34 Child Safety Using Inboard Lower Anchors From the Outboard Seating Positions (Center Seating Use) WARNING: The standardized spacing for LATCH lower anchors is 11 inches (280 millimeters) center to center. Do not use LATCH lower anchors for the center seating position unless the child seat manufacturer’s instructions permit and specify using anchors spaced at least as far apart as those in this vehicle.
Page 35 Child Safety Once the child safety seat has been installed using either the safety belt, the lower anchors of the LATCH system, or both, you can attach the top tether strap. The tether strap anchors in your vehicle are in the following positions (shown from top view): •...
Page 36 Child Safety Perform the following steps to install a child safety seat with tether anchors: Note: If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off your vehicle seat cushion when the child is seated in it.
Page 37 Child Safety 2. Locate the correct anchor for the selected rear seating position. • Second-row bucket (40/40) • Second-row bench (60/40) • Third-row seat Note: The cargo tie-downs at the rear edge of the floor are not tether anchors. 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 38 If the safety seat is not anchored properly, the risk of a child being injured in a crash greatly increases. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. 2014 MKT (mkt)
Page 39: Child Safety Locks
Child Safety CHILD SAFETY LOCKS The childproof locks are located on the rear edge of each rear door and must be set separately for each door. Setting the lock for one door will not automatically set the lock for both doors. •...
Page 40: Safety Belts
Safety Belts PRINCIPLES OF OPERATION WARNING: Always drive and ride with your seat back upright and the lap belt snug and low across the hips. WARNING: To reduce the risk of injury, make sure children sit where they can be properly restrained. WARNING: Never let a passenger hold a child on his or her lap while the vehicle is moving.
Page 41 Safety Belts WARNING: When possible, all children 12 years old and under should be properly restrained in a rear seating position. Failure to follow this could seriously increase the risk of injury or death. WARNING: Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather;...
Page 42: Fastening The Safety Belts
Safety Belts FASTENING THE SAFETY BELTS The front outboard and rear safety restraints in your vehicle are combination lap and shoulder belts. 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch.
Page 43 Safety Belts Pregnant women should always wear their safety belts. The lap belt portion of a combination lap and shoulder belt should be positioned low across the hips below the belly and worn as tight as comfort will allow. The shoulder belt should be positioned to cross the middle of the shoulder and the center of the chest.
Page 44 Safety Belts Safety Belt Locking Modes WARNING: After any vehicle crash, the safety belt system at all passenger seating positions must be checked by an authorized dealer to verify that the automatic locking retractor feature for child seats is still functioning properly. In addition, all safety belts should be checked for proper function.
Page 45 Safety Belts How to use the automatic locking mode Non-inflatable safety belts 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion of the belt and pull downward until the entire belt is pulled out. 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
Page 46: Safety Belt Height Adjustment
Safety Belts Safety Belt Extension Assembly WARNING: Do not use extensions to change the fit of the shoulder belt across the torso. WARNING: Do not use extensions with an inflatable safety belt. Safety belt extensions are vehicle-specific. See an authorized dealer to make sure you obtain the proper safety belt extension for your vehicle.
Page 47: Safety Belt-Minder
Safety Belts Conditions of Operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the on warning chime sounds 4-8 seconds. position... The driver’s safety belt is The safety belt warning light and buckled while the indicator warning chime turn off.
Page 48 Safety Belts If... Then... The driver’s and front The Belt-Minder feature will not passenger’s safety belts are activate. buckled before the ignition switch is turned to the on position or less than 1-2 minutes have elapsed since the ignition switch has been turned to on...
Page 49 Safety Belts Note: The driver and front passenger Belt-Minder are deactivated and activated independently. When deactivating or activating one seating position, do not buckle the other position as this will terminate the process. Read Steps 1 - 5 thoroughly before proceeding with the programming procedure.
Page 50: Rear Inflatable Safety Belt
Safety Belts REAR INFLATABLE SAFETY BELT (IF EQUIPPED) WARNING: Do not attempt to service, repair, or modify the rear inflatable safety belt as you could be seriously injured or killed. Note: The rear inflatable safety belts are compatible with most infant and child safety car seats and belt positioning booster seats when properly installed.
Page 51 Safety Belts • During a crash of sufficient force, the inflatable belt will inflate from inside the webbing. • The fully inflated belt’s increased diameter more effectively holds the occupant in the appropriate seating position, and spreads crash forces over more area of the body than regular safety belts.
Page 52: Child Restraint And Safety Belt Maintenance
Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a crash be replaced. However, if the crash was minor and an authorized dealer finds that the belts do not show damage and continue to operate properly, they do not need to be replaced.
Page 53: Personal Safety System
Personal Safety System PERSONAL SAFETY SYSTEM™ The Personal Safety System provides an improved overall level of frontal crash protection to front seat occupants and is designed to help further reduce the risk of airbag-related injuries. The system is able to analyze different occupant conditions and crash severity before activating the appropriate safety devices to help better protect a range of occupants in a variety of frontal crash situations.
Page 54: Supplementary Restraints System
Supplementary Restraints System PRINCIPLES OF OPERATION WARNING: Airbags do not inflate slowly or gently, and the risk of injury from a deploying airbag is the greatest close to the trim covering the airbag module. WARNING: All occupants of your vehicle, including the driver, should always properly wear their safety belts, even when an airbag supplemental restraint system is provided.
Page 55 Supplementary Restraints System WARNING: If the airbag has deployed, the airbag will not function again and must be replaced immediately. If the airbag is not replaced, the unrepaired area will increase the risk of injury in a crash. The airbags are a supplemental restraint system and are designed to work with the safety belts to help protect the driver and right front passenger from certain upper body injuries.
Page 56: Driver And Passenger Airbags
Supplementary Restraints System DRIVER AND PASSENGER AIRBAGS WARNING: Never place your arm or any objects over an airbag module. Placing your arm over a deploying airbag can result in serious arm fractures or other injuries. Objects placed on or over the airbag inflation area may cause those objects to be propelled by the airbag into your face and torso causing serious injury.
Page 57 Supplementary Restraints System Proper Driver and Front Passenger Seating Adjustment WARNING: The National Highway Traffic Safety Administration recommends a minimum distance of at least 10 inches (25 centimeters) between an occupant’s chest and the driver airbag module. Failure to follow this could seriously increase the risk of injury or death.
Page 58: Front Passenger Sensing System
Supplementary Restraints System FRONT PASSENGER SENSING SYSTEM WARNING: Even with Advanced Restraints Systems, children 12 and under should be properly restrained in a rear seating position. Failure to follow this could seriously increase the risk of injury or death. WARNING: Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the decision of the front passenger sensing system, resulting in serious injury or death in a crash.
Page 59 Supplementary Restraints System The front passenger sensing system uses a passenger airbag status indicator which will illuminate indicating that the front passenger frontal airbag is either ON (enabled) or OFF (disabled). The indicator lamp is located in the center stack of the instrument panel.
Page 60 Supplementary Restraints System • Restart the vehicle and have the person remain in this position for about two minutes. This will allow the system to detect that person and enable the passenger’s frontal airbag. • If the indicator OFF lamp remains lit even after this, the person should be advised to ride in the rear seat.
Page 61 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this owner’s manual.
Page 62: Side Airbags
Supplementary Restraints System SIDE AIRBAGS WARNING: Do not place objects or mount equipment on or near the airbag cover, on the side of the seatbacks (of the front seats), or in front seat areas that may come into contact with a deploying airbag.
Page 63: Safety Canopy Curtain Airbags
Supplementary Restraints System The system consists of the following: • A tag on the seatback indicating that side airbags are found on your vehicle. • Side airbags located inside the seatback of the driver and front passenger seats. • Crash sensors and monitoring system with readiness indicator.
Page 64 Supplementary Restraints System WARNING: All occupants of your vehicle including the driver should always wear their safety belts even when an airbag supplemental restraint system and curtain airbag is provided. Failure to properly wear your safety belt could seriously increase the risk of injury or death.
Page 65: Crash Sensors And Airbag Indicator
Supplementary Restraints System • A flexible headliner which opens above the side doors to allow air curtain deployment. • Crash sensors and monitoring system with readiness indicator. See Crash Sensors and Airbag Indicator in this chapter. Children 12 years old and under should always be properly restrained in the rear seats.
Page 66: Airbag Disposal
Supplementary Restraints System A difficulty with the system is indicated by one or more of the following: • The readiness light will either flash or stay lit. • The readiness light will not illuminate immediately after the ignition is turned on. •...
Page 67: Keys And Remote Control
Keys and Remote Control GENERAL INFORMATION ON RADIO FREQUENCIES This device complies with part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 68: Remote Control
Keys and Remote Control REMOTE CONTROL Intelligent Access Key Your intelligent access keys operate the power locks and the remote start system. The key must be in your vehicle to activate the push-button start system. The intelligent access key also contains a removable mechanical key blade that you can use to unlock the driver door.
Page 69 Keys and Remote Control Intelligent Access Transmitter 1. Remove the backup key from the transmitter. 2. Twist a thin coin under the tab hidden behind the backup key head to remove the battery cover. Do not use the backup key to remove the cover or you could damage the intelligent access key.
Page 70 Keys and Remote Control Programming Memory to the Transmitter 1. Move the memory features to the desired positions using the associated controls. 2. Press and hold button 1 until a tone is heard to confirm setting. Continue to hold until a second tone is heard.
Page 71 Keys and Remote Control Remote Start WARNING: To avoid exhaust fumes, do not use remote start if your vehicle is parked indoors or areas that are not well ventilated. Note: Do not use remote start if your vehicle is low on fuel. The remote start button is on the transmitter.
Page 72 Keys and Remote Control Remote Starting the Vehicle Note: You must press each button within three seconds of each other. Your vehicle will not remote start and the horn will not sound if you do not follow this sequence. The label on your transmitter details the starting procedure.
Page 73: Replacing A Lost Key Or Remote Control
Keys and Remote Control Turning the Vehicle Off After Remote Starting Press the button once. The parking lamps will turn off. You may have to be closer to your vehicle than when starting due to ground reflection and the added noise of the running vehicle. You can disable or enable the remote start system through the information display.
Page 74: Mykey
MyKey PRINCIPLES OF OPERATION MyKey allows you to program keys with restricted driving modes to promote good driving habits. All but one of the keys programmed to the vehicle can be activated with these restricted modes. Any keys that have not been programmed are referred to as administrator keys or admin keys.
Page 75: Creating
MyKey • Vehicle speed minders of 45, 55 or 65 mph (75, 90 or 105 km/h). Once you select a speed, it will be shown in the display, followed by an audible tone when the preselected vehicle speed is exceeded. •...
Page 76: Clearing
MyKey 3. Use the arrow buttons to get to a configurable feature. 4. Press OK or > to make a selection. Note: You can clear or change your MyKey settings at any time during the same key cycle as you created the MyKey. Once you have switched the engine off, however, you will need an admin key to change or clear your MyKey settings.
Page 77: Remote Start, Mykey
USING MYKEY WITH REMOTE START SYSTEMS MyKey is not compatible with non-Ford-approved aftermarket remote start systems. If you choose to install a remote start system, please see your Ford authorized dealer for a Ford-approved remote start system. MYKEY TROUBLESHOOTING Condition Potential causes •...
Page 78 MyKey Condition Potential causes • Purchase a new key from your authorized I lost the only admin key. dealer. • Program a spare key. See SecuriLock in the I lost a key. Security. • An admin fob is present at engine start. No MyKey functions •...
Page 79: Locks
Locks LOCKING AND UNLOCKING You can use the power door lock control or the remote control to lock and unlock your vehicle. Power Door Locks The power door lock control is located on the driver and front passenger door panels. A.
Page 80 Locks Note: If any door or the luggage compartment is open, or if the hood is open on vehicles with an anti-theft alarm or remote start, the horn sounds twice and the lamps will not flash. Activating intelligent access You must have the intelligent access key within 3 feet (1 meter) of your vehicle.
Page 81 Locks You can override the smart unlock feature and intentionally lock the intelligent access key inside your vehicle. To do this, lock your vehicle after you have closed all the doors by: • using the keyless entry keypad • pressing the lock button on another intelligent access key •...
Page 82 Locks Enabling or Disabling Note: You can enable or disable the autolock and autounlock features independently of each other. You can enable or disable these features: • through an authorized dealer • using the information display. Illuminated Entry The interior lamps and select exterior lamps illuminate when you use the intelligent access key or the keyless entry keypad to unlock your vehicle.
Page 83 Locks LIFTGATE WARNING: It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a crash, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 84 Locks A chime will sound three times as the liftgate begins to power close. A single chime indicates a problem with the close request, caused by: • the ignition is on and the transmission is not in P (Park); • or the battery voltage is below the minimum operating voltage; •...
Page 85 Locks Obstacle Detection When closing: The system will reverse to full open when it detects an obstacle. A chime will sound three times as the liftgate begins to reopen. Remove the obstacle to close the liftgate can be closed under power. Note: Entering the vehicle while the liftgate is closing can cause the vehicle to bounce and activate obstacle detection.
Page 86: Securicode™ Keyless Entry Keypad
Locks Note: Do not leave the liftgate open while driving. This could damage the liftgate and its components. The liftgate area is only intended for cargo, not passengers. To open the liftgate: Press the button located on the surface above the license plate.
Page 87 Locks The keypad can be operated with the factory-set 5-digit entry code; this code is located on the owner’s wallet card in the glove box and is available from your authorized dealer. You can also create up to three of your own 5-digit personal entry codes.
Page 88 Locks Anti-Scan Feature The keypad will go into an anti-scan mode if you enter the wrong code seven times (35 consecutive button presses). This mode disables the keypad for one minute and the keypad lamp will flash. The anti-scan feature will turn off after: •...
Page 89: Security
Security SECURILOCK® PASSIVE ANTI-THEFT SYSTEM Note: The system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Metallic objects, electronic devices or a second coded key on the same key chain may cause vehicle starting issues if they are too close to the key when starting your vehicle.
Page 90 Security Programming a Spare Intelligent Access Key Note: A maximum of four intelligent access keys can be programmed to your vehicle. You must take your vehicle and all access keys to your authorized dealer to be erased and reprogrammed if you would like to replace a previously programmed access key with a new access key, or if you already have four access keys programmed to your vehicle.
Page 91: Anti-Theft Alarm
Security 8. Verify that the remote entry functions operate (press lock then unlock, making sure you end in unlock) and that your vehicle starts with new intelligent access key. ANTI-THEFT ALARM The system will warn you of unauthorized entry to your vehicle. The turn signal lamps will flash and sound the horn up to a total of 10 times when: •...
Page 92: Steering Wheel
Steering Wheel ADJUSTING THE STEERING WHEEL WARNING: Do not adjust the steering wheel when your vehicle is moving. Note: Make sure that you are sitting in the correct position. Refer to Sitting in the Correct Position in the Seats chapter. Use the control on the side of the steering column to adjust the position.
Page 93: Steering Wheel Controls
Steering Wheel To reset the steering column to its normal stopping position: 1. Press the steering column control again after encountering the new stopping position. 2. Continue pressing the control until it reaches the end of the column position. A new stopping position will be set. The steering column will stop just short of the end of the column position the next time it is tilted or telescoped.
Page 94 Steering Wheel CRUISE CONTROL Type 1 Type 2 CNCL See the Cruise Control chapter for information on this feature. 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 95 Steering Wheel INFORMATION DISPLAY CONTROL See the Information Displays chapter for more information. Cluster Display Control Features Use this control to adjust the right side of the cluster display. Navigate through the screen and press OK to select. See the MyLincoln Touch chapter.
Page 96: Pedals
Pedals ADJUSTABLE PEDALS (IF EQUIPPED) WARNING: Never adjust the accelerator and brake pedal with feet on the pedals while the vehicle is moving. The control is located on the left side of the steering column. Press and hold the appropriate control to move the pedals. A.
Page 97: Wipers And Washers
Wipers and Washers WINDSHIELD WIPERS Note: Fully defrost the windshield before switching on the windshield wipers. Note: Make sure you switch off the windshield wipers before entering a car wash. Note: Clean the windshield and wiper blades if they begin to leave streaks or smears.
Page 98: Windshield Washers
Wipers and Washers WINDSHIELD WASHERS Note: Do not operate the wipers on a dry windshield. This may scratch the glass, damage the wiper blades or cause the wiper motor to burn out. Always use the windshield washer before wiping a dry windshield. Note: Do not operate the washer when the washer reservoir is empty.
Page 99: Lighting
Lighting LIGHTING CONTROL A. Off B. Parking lamps, instrument panel lamps, license plate lamps and tail lamps C. Headlamps High Beams • Push the lever toward the instrument panel to activate. • Push the lever toward the instrument panel again or pull the lever towards you to deactivate.
Page 100: Autolamps
Lighting AUTOLAMPS WARNING: In severe weather conditions, it may be necessary to switch your headlamps on manually. Note: If the vehicle is equipped with autolamps, it will have the windshield wiper rainlamp feature. When the windshield wipers are turned to low- or high-speed wiping during daylight, and the headlamp control is in the autolamp position, the exterior lamps will turn on after a brief delay and will remain on until the wipers are turned off.
Page 101: Headlamp Exit Delay
Lighting HEADLAMP EXIT DELAY You can set the delay time to keep the headlamps on for up to three minutes after the ignition is turned off. Follow the steps below to change the delay time (Steps 1 through 6 must be done within 10 seconds): 1.
Page 102: Automatic High Beam Control
Lighting AUTOMATIC HIGH BEAM CONTROL (IF EQUIPPED) The system will automatically turn on your high beams if it is dark enough and no other traffic is present. When it detects an approaching vehicle’s headlights, a preceding vehicle’s tail lamps or street lighting, the system will turn off the high beams (low beams remain on) before they distract other drivers.
Page 103 Lighting The high beams will switch off if: • An approaching vehicle’s headlights or a preceding vehicle’s tail lamps are detected. • The vehicle speed falls below 19 mph (30 km/h). • The ambient light level is high enough that high beams are not needed.
Page 104: Front Fog Lamps
Lighting FRONT FOG LAMPS The fog lamps can be turned on when the lighting control is pulled toward you and in the headlamps, parking lamps or autolamps positions. The fog lamps will not operate when the high beams are active. ADAPTIVE HEADLAMPS The headlamp beams move in the same direction as the steering wheel which provides more visibility when driving around curves.
Page 105: Turn Signal Control
Lighting The system will only work with the lighting control switch in the autolamp position. Note: There is a delay of two to five seconds before the adaptive headlamp system will operate when the vehicle is driven. Note: The system is only active at speeds above 3 mph (5 km/h).
Page 106: Interior Lamps
Lighting INTERIOR LAMPS Front row map lamps The map lamps are located on the overhead console. Press the lens on either side of each map lamp to turn on the lamps. The map lamps also light when: • Any door is opened. •...
Page 107 Lighting Second row vanity mirror dome lamps (Livery only) The vanity mirror dome lamps are located in the headliner behind the front seats. The lamps light when: • Any door is opened. • The instrument panel dimmer button is pressed until the courtesy lamp comes on.
Page 108: Windows And Mirrors
Windows and Mirrors POWER WINDOWS WARNING: Do not leave children unattended in your vehicle and do not let children play with the power windows. They may seriously injure themselves. WARNING: When closing the power windows, you should verify they are free of obstructions and make sure that children and pets are not in the proximity of the window openings.
Page 109 Windows and Mirrors Opening the Windows Press and hold the unlock button on the remote control to begin opening the windows and venting the moonroof. The power sunscreen will also open. Press the lock or unlock button on the remote control to stop motion. Closing the Windows WARNING: Before operating power windows, you should verify that they are free of obstructions and ensure that children and...
Page 110: Exterior Mirrors
Windows and Mirrors Window Lock Press the control to lock or unlock the rear window controls. Accessory Delay You can use the window switches for several minutes after you switch the ignition off, or until you open either front door. EXTERIOR MIRRORS Power Exterior Mirrors WARNING: Do not adjust the mirror while your vehicle is in...
Page 111 Windows and Mirrors Foldaway Exterior Mirrors Push the mirror toward the door window glass. Make sure that you fully engage the mirror in its support when returning it to its original position. Heated Exterior Mirror Note: Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass that has frozen in place.
Page 112: Interior Mirrors
Windows and Mirrors The image of the approaching vehicle is small and near the inboard edge of the main mirror when it is at a distance. The image becomes larger and begins to move outboard across the main mirror as the vehicle approaches (A).
Page 113: Sun Visors
Windows and Mirrors Auto-Dimming Mirror Note: Do not block the sensors on the front and back of the mirror. Mirror performance may be affected. A rear center passenger or raised rear center head restraint may also block light from reaching the sensor. The mirror will dim automatically to reduce glare when bright lights are detected from behind your vehicle.
Page 114: Moonroof
Windows and Mirrors Illuminated Visor Vanity Mirror Lift the cover to switch on the lamp. PANORAMIC VISTA ROOF® AND POWER SUNSHADES (IF EQUIPPED) WARNING: Do not let children play with the moonroof and power sunshade or leave children unattended in the vehicle. They may seriously hurt themselves.
Page 115 Windows and Mirrors Opening the Sunshade and Moonroof Note: The moonroof will only open after sunshades are completely open. Press and release the control to open the sunshade. The front and rear sunshades open simultaneously. Press and release the control to open the moonroof. The moonroof will stop short of the fully opened position.
Page 116: Instrument Cluster
Instrument Cluster GAUGES Cluster shown in standard measure – metric clusters similar. A. Information display. See Information displays for more information. B. Speedometer C. Infotainment display. See MyLincoln Touch ™ for more information. WARNING LAMPS AND INDICATORS There indicators can alert you to a vehicle condition that may become serious enough to cause expensive repairs.
Page 117 Instrument Cluster Adaptive cruise control (if equipped) (RTT) The speed control system indicator light changes color to indicate what mode the system is in: • On (white light): Illuminates when the adaptive cruise control system is turned on. Turns off when the speed control system is turned off. •...
Page 118 Instrument Cluster Brake system warning light To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the on position when the engine is not running, or in a position between on and start, or by applying the parking brake when the ignition is turned to the on position.
Page 119 Instrument Cluster Fog lamps Illuminates when the fog lamps are turned on. Overdrive cancel and grade assist (if equipped) (RTT) Illuminates when grade assist is turned on. Heads up display (if equipped) A red beam of lights will illuminate on the windshield in certain instances when using adaptive cruise control and/or the collision warning system.
Page 120 Instrument Cluster Park lamps Illuminates when the park lamps are on. Powertrain malfunction/reduced power (RTT) Illuminates when a powertrain or an AWD fault has been detected. Contact your authorized dealer as soon as possible. Safety belt Reminds you to fasten your safety belt. A Belt-Minder® chime will also sound to remind you to fasten your safety belt.
Page 121: Audible Warnings And Indicators
Instrument Cluster Speed control (if equipped) (RTT) The speed control system indicator light changes color to indicate what mode the system is in: • On (white light): Illuminates when the speed control system is turned on. Turns off when the speed control system is turned off. •...
Page 122: Information Displays
Information Displays GENERAL INFORMATION WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 123 Information Displays Display Mode Use the up/down arrow buttons to choose between the following display options. Display mode Display mode Option 1 Option 2 Option 3 XXX mi (km) to empty Bar tachometer Round tachometer Engine coolant temp gauge Fuel gauge Always Always Always...
Page 124 Information Displays • Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the level indicator will be in the normal range. If the engine coolant temperature exceeds the normal range, stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 125 Information Displays • Inst. Fuel Economy: This display shows a visual graph of your instantaneous fuel economy. • XX. Min Fuel History: This display shows a bar chart of your fuel history. Driver Assist In this mode, you can configure different driver setting choices. Note: Some items are optional and may not appear.
Page 126 Information Displays Settings Vehicle Handling in D Sport / Normal / Comfort Drive Control Handling in S Sport / Normal Auto Engine Off — check enabled / uncheck disabled Normal / Towing Calculation Easy Entry/Exit — check enabled / uncheck disabled Lighting Adaptive Head Traffic Set Up...
Page 127 Information Displays Settings (cont’d) *MyKey Mykey Status MyKeys / Admin Keys Create Hold OK to Create MyKey MyKey 911 Assist Always On / User Selectable Traction Always On / User Selectable Control Max Speed Choose desired speed or off Speed Minder Choose desired speed or off Volume On / Off Limiter...
Page 128: Information Messages
Information Displays INFORMATION MESSAGES Note: Depending on the vehicle options equipped with your vehicle, not all of the messages will display or be available. Certain messages may be abbreviated or shortened depending upon which cluster type you have. Press the OK button to acknowledge and remove some messages from the information display.
Page 129 Information Displays Alarm/Security Action / Description Messages Vehicle Alarm To Stop Displayed when the perimeter alarm system is Alarm, Start Vehicle. armed and the vehicle is entered using the key on the driver’s side door. In order to prevent the perimeter alarm system from triggering, the ignition must be turned to start or on before the 12 second chime expires.
Page 130 Information Displays Battery and Action / Description Charging System Messages Check Charging Displayed when the charging system needs System servicing. If the warning stays on or continues to come on, contact your authorized dealer as soon as possible. Turn Power Off to Displayed when the battery management Save Battery system determines that:...
Page 131 Information Displays BLIS® Messages Action / Description Cross Traffic System Displayed when a fault with the cross traffic Fault alert system has occurred. Contact your authorized dealer as soon as possible. Vehicle Coming Displayed when the blind spot information From X system with cross traffic alert (CTA) system is operating and senses a vehicle.
Page 132 Information Displays Collision Warning Action / Description System Messages Collision Warning Displayed when there is a system malfunction Malfunction with the collision warning system. The system will be disabled. Contact your authorized dealer as soon as possible. Door Messages Action / Description X Door Ajar Displayed when a door is not completely closed.
Page 133 Information Displays Keys and Intelligent Action / Description Access Messages No Key Detected Displayed if the intelligent access key is not detected by the system in the following three scenarios: •When the start/stop button is pressed in an attempt to either start the engine or cycle through the ignition states.
Page 134 Information Displays Lane Keeping Action / Description System Messages Lane keeping Sys. The system has malfunctioned. Contact your Malfunction Service authorized dealer as soon as possible. required Front Camera The system has detected a condition that has Temporarily Not caused the system to be temporarily Available unavailable.
Page 135 Information Displays Maintenance Action / Description Messages Service Power Steering The power steering system has detected a condition within the power steering system that requires service immediately. See your authorized dealer. Power Steering Assist The power steering system has disabled power Fault steering assist due to a system error.
Page 136 Information Displays Park Aid Messages Action / Description Check Park Aid Displayed when the transmission is in R (Reverse) and the park aid is disabled. Check Front Park Aid Displayed when the transmission is in D (Drive) and the front park aid is disabled. Check Rear Park Aid Displayed when the transmission is in R (Reverse) and the park aid is disabled.
Page 137 Information Displays Tire Messages Action / Description LOW Tire Pressure Displays when one or more tires on your vehicle have low tire pressure. Tire Pressure Monitor Displays when the tire pressure monitoring Fault system is malfunctioning. If the warning stays on or continues to come on, contact your authorized dealer.
Page 138: Climate Control
Climate Control DUAL AUTOMATIC TEMPERATURE CONTROL SYSTEM DUAL TEMP AUTO Note: You can switch temperature units between Fahrenheit and Celsius. See Settings in the MyLincoln Touch chapter. A. MyTemp: Allows you to quickly adjust to a frequently used setting with a single touch. Press + and - to increase and decrease the temperature.
Page 139 Climate Control Note: Recirculated air engages automatically when you select MAX A/C. You can turn it on manually in any airflow mode except defrost. E. MAX A/C: Distributes recirculated air through the instrument panel vents to cool the vehicle. This position is more economical and efficient than normal air conditioning.
Page 140: Auxiliary Passenger Climate Control
Climate Control REAR PASSENGER CLIMATE CONTROL (IF EQUIPPED) Depending on your vehicle equipment, you may not have all the features shown below. AUTO AUTO REARLOCK A. Fan control: Turn to increase or decrease the fan speed or choose the following: •...
Page 141 Climate Control Cooled seat control (if equipped): Press to switch the cooled seats off and on. See Heated and cooled seats in the Seats chapter for more information. F. AUTO:Press to activate automatic control of the airflow direction in the rear of the vehicle. The system automatically determines the airflow distribution in order to reach and maintain the desired temperature.
Page 142: Rear Window Defroster
Climate Control To aid in side window defogging and demisting in cold or humid weather: 1. Select defrost or floor/defrost (on the MyLincoln Touch climate controls). To maximize performance select defrost. 2. Select A/C. 3. Adjust the temperature control to maintain comfort. 4.
Page 143 Climate Control The particulate air filtration system reduces the concentration of airborne particles, such as dust, spores and pollen, in the air supplied to the interior of your vehicle. The particulate filtration system gives the following benefits to customers: • Improves the customer’s driving comfort by reducing particle concentration.
Page 144: Seats
Seats SITTING IN THE CORRECT POSITION WARNING: Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the decision of the passenger sensing system, resulting in serious injury or death in a crash. Always sit upright against your seat back, with your feet on the floor.
Page 145: Head Restraints
Seats • Bend your legs slightly so that you can press the pedals fully. • Position the shoulder strap of the safety belt over the center of your shoulder and position the lap strap tightly across your hips. Make sure that your driving position is comfortable and that you can maintain full control of your vehicle.
Page 146 Seats Second row center seat head restraint (if equipped) The head restraints consist of: A. Energy absorbing head restraint B. Steel stems C. Guide sleeve adjust and release button D. Guide sleeve unlock and remove button • Raise: Pull up on the head restraint (A). •...
Page 147 Seats To reinstall the non-adjustable head restraint, do the following: • Remove: Pull up the head restraint until it reaches the highest adjustment position and then press and hold the guide sleeve unlock and remove buttons, then pull up on the head restraint. •...
Page 148: Power Seats
Seats Note: Do not attempt to force the head restraint backward after it is tilted. Instead, continue tilting it forward until the head restraint releases to the upright position. POWER SEATS WARNING: Never adjust the driver’s seat or seat back when the vehicle is moving.
Page 149: Memory Function
Seats Power Lumbar (Limo/Livery) Four-Way Power Lumbar (If Equipped) The lumbar control is located on the side of the seat cushion. Press the front or rear of the control to adjust firmness or softness. Press the top or bottom of the control to raise or lower the height of the lumbar support.
Page 150 Seats Programming a memory position Note: You can program a memory position at any time. • To program position 1, move the memory features to the desired positions using the associated controls. Press and hold button 1 for at least two seconds. A chime will sound confirming that a memory position has been set.
Page 151: Heated Seats
Seats HEATED SEATS (IF EQUIPPED) WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater. The seat heater may cause burns even at low temperatures, especially if used for long periods of time.
Page 152: Heated And Ventilated Seats
Seats HEATED AND VENTILATED SEATS (IF EQUIPPED) Heated Seats WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater. The seat heater may cause burns even at low temperatures, especially if used for long periods of time.
Page 153 Seats Ventilated Seats The ventilated seats will only function when the engine is running. To operate the ventilated seats: Press the ventilated seat symbol to cycle through the various cooling settings and off. Cooler settings are indicated by more indicator lights. If the engine falls below 350 RPM while the ventilated seats are on, the feature will turn itself off.
Page 154: Rear Seats
Seats To install a filter: 1. First, position the filter in its housing making sure that the far forward end is all the way up in the housing. 2. Push in on the center of the outside edge of the filter and rotate up into the housing until it clips into position.
Page 155 Seats Moving the Seats Backward and Forward (Six-Passenger Vehicles Only) Lift the control to adjust the seat forward or backward. Using the Second-Row Power Lumbar Support (Six-Passenger Vehicles Only) The power lumbar control is located on the outboard side of the seat. Press the forward side of the control to adjust firmness.
Page 156 Seats Power Fold and Tumble Seat (If Equipped) WARNING: Make sure that the seat is unoccupied when folding it down. Folding the seat while occupied could result in occupant injury or damage to the seat. This feature is available for the right-hand seat on seven-passenger vehicles and on both sides for six-passenger vehicles.
Page 157 Seats Third Row Seats Accessing the Seat WARNING: Before returning the seat back to its original position, make sure that cargo or any objects are not trapped behind the seat back. After returning the seat back to its original position, pull on the seat back to make sure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or crash.
Page 158 Seats The seat back will fold flat. 2. Lift the handle all the way up until the seat releases from the floor. Rotate the seat forward, grabbing the bottom of the seat back as indicated, to allow access to the third row seat. Note: The seat back must be folded flat in order to release the floor latches.
Page 159 Seats 4. To return the seat back to the upright position • Lift the seat back toward the rear of the vehicle, and • Rotate the seat back until you hear a click, locking it in the upright position. Note: The seat back will not raise if the rear latch hooks are not properly engaged to the floor striker.
Page 160 Seats 3. To return the seat back to the upright position • Lift the seat back toward the rear of the vehicle, and • Rotate the seat back until you hear a click, locking it in the upright position. Note: The seat back will not raise if the rear latch hooks are not properly engaged to the floor striker.
Page 161 Seats Stowing the Third Row Seat 1. Remove all objects from the seat and stowage tub. Objects in the seat or stowage tub may cause serious damage to the seat upholstery and cause improper seat function. 2. From the rear of the vehicle, stow the head restraints by pulling the strap located on the middle of the seat back just below the head...
Page 162 Seats Unstowing the Third Row Seat WARNING: Make sure the seat is latched to vehicle floor by pushing and pulling on the seat. If not latched, the seat may cause injury during a sudden stop. Note: Make sure that there are no objects such as books, purses or brief cases on the load floor before unstowing the seat.
Page 163 Seats PowerFold® Third-row Seat (If Equipped) The third row seat features a power one-touch operation that allows you to adjust the left, right, or both seats into a NORMAL, STOW, FOLD, or TAILGATE position with just one touch of a button. The third row seat also includes obstacle detection that allows the seat to stop and reverse direction if it hits an obstacle so that the obstacle can be removed.
Page 164 Seats Note: Make sure that there are no objects such as books, purses or brief cases on the load floor before unstowing the seat. Failure to remove all objects from the top of the load floor prior to unstowing it may cause damage to the seat.
Page 165: Universal Garage Door Opener (If Equipped)
164 Universal Garage Door Opener (If Equipped) HOMELINK® WIRELESS CONTROL SYSTEM (IF EQUIPPED) WARNING: Make sure that the garage door and security device are free from obstruction when you are programming. Do not program the system with the vehicle in the garage. WARNING: Do not use the system with any garage door opener that does not have the safety stop and reverse feature as required by U.S.
Page 166 Universal Garage Door Opener (If Equipped) 165 Programming Note: Put a new battery in the hand-held transmitter. This will ensure quicker training and accurate transmission of the radio-frequency signal. 1. With your vehicle parked outside of the garage and your key in the ignition, turn the key so that the ignition is in the on position.
Page 167 166 Universal Garage Door Opener (If Equipped) After programming the HomeLink button, follow Steps 5 – 7 as listed below to program your garage door opener. Note: You may need a ladder to reach the unit and you may need to remove the cover or lamp lens on your garage door opener.
Page 168 Universal Garage Door Opener (If Equipped) 167 Programming HomeLink to a Genie Intellicode 2 garage door opener Note: The Genie Intellicode 2 transmitter must already be programmed to operate with the garage door opener. Programing the transmitters To program HomeLink to the transmitter you must first put the transmitter into programming mode.
Page 169 168 Universal Garage Door Opener (If Equipped) Programming HomeLink to the Genie Intellicode garage door opener motor Note: You may need a ladder to access the garage door opener motor. To program HomeLink to the garage door opener motor: 1. Press and hold the PROGRAM button on the garage door opener motor until both blue LED’s turn on.
Page 170: Auxiliary Power Points
Auxiliary Power Points AUXILIARY POWER POINTS WARNING: Do not plug optional electrical accessories into the cigarette lighter socket (if equipped). Improper use of the lighter can cause damage not covered by your warranty, and can result in fire or serious injury. Note: If used when the engine is not running, the battery will discharge.
Page 171 Auxiliary Power Points 110 Volt AC Power Point (If Equipped) WARNING: Do not keep electrical devices plugged in the power point whenever the device is not in use. Do not use any extension cord with the 110 volt AC power point, since it will defeat the safety protection design.
Page 172 Auxiliary Power Points The power point can switch to a fault mode when it is overloaded, overheated, or shorted. Unplug your device and turn the ignition off then on for overloading and shorting conditions. Let the system cool off, then turn the ignition off then on for an overheating condition.
Page 173: Storage Compartments
Storage Compartments CENTER CONSOLE Stow items in the cupholder carefully as items may become loose during hard braking, acceleration or collisions, including hot drinks which may spill. Available console features include: A. Cupholders B. Utility compartment with coin holder, SD card reader, USB ports and power point C.
Page 174 This feature will operate when the vehicle is on or in accessory mode. Limit the time of use when the vehicle is in accessory mode to avoid draining the vehicle’s battery. Ford recommends only using this feature when the engine is running.
Page 175: Overhead Console
Storage Compartments Cleaning and Maintenance Note: Condensation on the inside walls of the refrigerator is normal under certain conditions. This feature is maintenance free, but you can clean the inside of the unit and the cover with a mild soap and water solution when needed. OVERHEAD CONSOLE The appearance of the overhead console will vary according to your option package.
Page 176: Starting And Stopping The Engine
Starting and Stopping the Engine GENERAL INFORMATION WARNING: Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. WARNING: Do not park, idle, or drive your vehicle on dry grass or other dry ground cover.
Page 177 Starting and Stopping the Engine Ignition Modes ENGINE START STOP Off: Turns the ignition off. • Without applying the brake pedal, press and release the button once when the ignition is in the on mode, or when the engine is running but the vehicle is not in motion.
Page 178 Starting and Stopping the Engine Before starting the engine check the following: • Make sure all occupants have fastened their safety belts. • Make sure the headlamps and electrical accessories are off. • Make sure the parking brake is on. •...
Page 179 Starting and Stopping the Engine Failure to Start If you cannot start the engine after three attempts, wait 10 seconds and follow this procedure: 1. Fully press the brake pedal. 2. Fully press the accelerator pedal and hold it there. 3.
Page 180: Engine Block Heater
Starting and Stopping the Engine Stopping the Engine When Your Vehicle is Moving WARNING: Switching off the engine when the vehicle is still moving will result in a loss of brake and steering assistance. The steering will not lock, but higher effort will be required. When the ignition is switched off, some electrical circuits, warning lamps and indicators may also be off.
Page 181 Starting and Stopping the Engine The heater acts as a starting aid by warming the engine coolant. This allows the climate control system to respond quickly. The equipment includes a heater element (installed in the engine block) and a wire harness.
Page 182: Fuel And Refueling
Fuel and Refueling SAFETY PRECAUTIONS WARNING: Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. WARNING: The fuel system may be under pressure. If you hear a hissing sound near the fuel filler inlet, do not refuel until the sound stops.
Page 183: Fuel Quality
Fuel and Refueling • Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury.
Page 184: Running Out Of Fuel
Fuel and Refueling Octane Recommendations 3.5L V6 EcoBoost®, 3.7L V6 and 2.0L I4 EcoBoost® engines “Regular” unleaded gasoline with a pump (R+M)/2 octane rating of 87 is recommended. Some stations offer fuels posted as “Regular” with an octane rating below 87, particularly in high altitude areas. Fuels with octane levels below 87 are not recommended.
Page 185: Refueling
Fuel and Refueling Note: Do not use aftermarket funnels; they will not work with the capless fuel system and can damage it. The included funnel has been specially designed to work safely with your vehicle. When filling the vehicle’s fuel tank from a portable fuel container, use the funnel included with the vehicle.
Page 186 Fuel and Refueling Easy Fuel® “No Cap” Fuel System WARNING: The fuel system may be under pressure. If you hear a hissing sound near the fuel filler door, do not refuel until the sound stops. Otherwise, fuel may spray out, which could cause serious personal injury.
Page 187: Fuel Consumption
Fuel and Refueling FUEL CONSUMPTION Filling the Tank The advertised capacity is the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty. Empty reserve is the amount of fuel in the tank after the fuel gauge indicates empty.
Page 188 Information are essential to the life and performance of your vehicle and to its emissions system. If other than Ford, Motorcraft® or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 189 Fuel and Refueling An improperly operating or damaged exhaust system may allow exhaust to enter the vehicle. Have a damaged or improperly operating exhaust system inspected and repaired immediately. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent...
Page 190 Fuel and Refueling If the service engine soon indicator remains on, have your vehicle serviced at the first available opportunity. Although some malfunctions detected by the OBD-II may not have symptoms that are apparent, continued driving with the service engine soon indicator on can result in increased emissions, lower fuel economy, reduced engine and transmission smoothness, and can lead to more costly repairs.
Page 191: Transmission
Transmission AUTOMATIC TRANSMISSION WARNING: Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the off position and remove the key whenever you leave your vehicle. Your vehicle has been designed to improve fuel economy by reducing fuel usage while coasting or decelerating.
Page 192 Transmission S (Sport) Moving the gearshift lever to S (Sport): • Provides additional grade (engine) braking and extends lower gear operation to enhance performance for uphill climbs, hilly terrain or mountainous areas. This will increase engine RPM during engine braking. •...
Page 193 Transmission If your vehicle is equipped with paddles on the steering wheel: • Pull the left paddle (–) to downshift the transmission. • Pull the right paddle (+) to upshift the transmission. Upshift to the recommended shift speeds according to the following chart: Upshifts when accelerating (recommended for best fuel economy)
Page 194 Transmission Brake-shift interlock WARNING: Do not drive your vehicle until you verify that the brakelamps are working. WARNING: When doing this procedure, you will be taking the vehicle out of park which means the vehicle can roll freely. To avoid unwanted vehicle movement, always fully set the parking brake prior to doing this procedure.
Page 195 Transmission If the fuse is not blown and the brake lamps are working properly, the following procedure will allow you to move the gearshift lever from P (Park): 1. Apply the parking brake, turn the ignition off, and remove the key. 2.
Page 196: All-Wheel Drive (If Equipped)
All-Wheel Drive (If Equipped) USING YOUR ALL-WHEEL DRIVE (AWD) SYSTEM (IF EQUIPPED) AWD uses all four wheels to power the vehicle. This increases traction, enabling you to drive over terrain and road conditions that a conventional two-wheel drive vehicles cannot. The AWD system is active all the time and requires no input from the operator.
Page 197 All-Wheel Drive (If Equipped) Driving In Special Conditions With All-Wheel Drive (AWD) AWD vehicles are equipped for driving on sand, snow, mud and rough roads and have operating characteristics that are somewhat different from conventional vehicles, both on and off the highway. When driving at slow speeds in deep sand under high outside temperatures, use a low gear when possible.
Page 198 All-Wheel Drive (If Equipped) If Your Vehicle Gets Stuck WARNING: Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the lock position and remove the key whenever you leave your vehicle. WARNING: If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly.
Page 199 All-Wheel Drive (If Equipped) Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. Avoid reducing the tire pressures but shift to a lower gear and drive steadily through the terrain. Apply the accelerator slowly and avoid excessive wheel slip.
Page 200 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 201 All-Wheel Drive (If Equipped) Apply just enough power to the wheels to climb the hill. Too much power will cause the tires to slip, spin or lose traction, resulting in loss of vehicle control. Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating.
Page 202 Any modifications to a vehicle that raise the center of gravity can make it more likely the vehicle will rollover as a result of a loss of control. Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder or luggage racks).
Page 203: Brakes
Brakes GENERAL INFORMATION Note: Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn out. Have them inspected by an authorized dealer. If your vehicle has continuous vibration or shudder in the steering wheel while braking, have your vehicle inspected by an authorized dealer.
Page 204: Hints On Driving With Anti-Lock Brakes
Brakes Anti-Lock Brake System This system helps you maintain steering control during emergency stops by keeping the brakes from locking. This lamp momentarily illuminates when you turn the ignition on. If the light does not illuminate during start-up, remains on or flashes, the anti-lock brake system may be disabled and may need to be serviced.
Page 205: Traction Control
Traction Control PRINCIPLES OF OPERATION The traction control system helps avoid drive wheel spin and loss of traction. If your vehicle begins to slide, the system applies the brakes to individual wheels and, when needed, reduces engine power at the same time. If the wheels spin when accelerating on slippery or loose surfaces, the system reduces engine power in order to increase traction.
Page 206: Stability Control
Stability Control PRINCIPLES OF OPERATION WARNING: Vehicle modifications involving braking system, aftermarket roof racks, suspension, steering system, tire construction and wheel or tire size may change the handling characteristics of your vehicle and may adversely affect the performance of the AdvanceTrac® system.
Page 207: Advancetrac
Stability Control A Vehicle without AdvanceTrac® skidding off its intended route. B Vehicle with AdvanceTrac® maintaining control on a slippery surface. USING ADVANCETRAC® WITH RSC® The system automatically activates when you start your engine. The AdvanceTrac® with RSC® system cannot be completely turned off, but the electronic stability control and roll stability control portions of the system are disabled when the transmission is in reverse (R).
Page 208: Parking Aids
Parking Aids SENSING SYSTEM WARNING: To help avoid personal injury, please read and understand the limitations of the system as contained in this section. Sensing is only an aid for some (generally large and fixed) objects when moving in reverse on a flat surface at parking speeds. Traffic control systems, inclement weather, air brakes, and external motors and fans may also affect the function of the sensing system;...
Page 209 Parking Aids When receiving a detection warning, the radio volume is reduced to a predetermined level. After the warning goes away, the radio volume returns to the previous level. The system can be turned off using the information display control. Refer to the Information Display chapter.
Page 210: Active Park Assist
Parking Aids ACTIVE PARK ASSIST (IF EQUIPPED) WARNING: This system is designed to be a supplementary park aid. It may not work in all conditions and is not intended to replace the driver’s attention and judgment. The driver is responsible for avoiding hazards and maintaining a safe distance and speed, even when the system is in use.
Page 211 Parking Aids Using Active Park Assist Press the button; the touch screen displays a message and a corresponding graphic to indicate it’s searching for a parking space. Use the turn signal to indicate which side of the vehicle you want the system to search on.
Page 212 Parking Aids Automatic Steering into Parking Space Note: If vehicle speed exceeds 6 mph (10 km/h), the system turns off and you need to take full control of the vehicle. Note: If a maneuver is interrupted before completion, the system turns off and you need to full take control of the vehicle.
Page 213 Parking Aids When automatic steering is finished, the touch screen displays a message indicating that the active park assist process is done. The driver is responsible for checking the parking job and making any necessary corrections before putting the transmission in P (Park). Deactivating the Park Assist Feature The system can be deactivated manually by: •...
Page 214 Parking Aids Troubleshooting the System The system does not look for a space The traction control system may be off Any door (except the driver’s) may not be completely closed The system does not offer a particular space Something may be contacting the front bumper or side sensors There is not enough room on both sides of the vehicle in order to park There is not enough space for the parking maneuver on the opposite side of the parking space...
Page 215: Rear-View Camera System
Parking Aids REAR VIEW CAMERA SYSTEM (IF EQUIPPED) WARNING: The rear view camera system is a reverse aid supplement device that still requires the driver to use it in conjunction with the interior and exterior mirrors for maximum coverage. WARNING: Objects that are close to either corner of the bumper or under the bumper, might not be seen on the screen due to the limited coverage of the camera system.
Page 216 Parking Aids Using the Rear View Camera System The rear view camera system displays what is behind your vehicle when you place the transmission in R (Reverse). The system uses three types of guides to help you see what is behind your vehicle: 1.
Page 217 Parking Aids Guidelines and the Centerline Note: Fixed guidelines and active guidelines (if equipped) are only available when the transmission is in R (Reverse). Note: The centerline is only available if Fixed or Active (if equipped) guidelines are on. A. Active guidelines (if equipped) B.
Page 218 Parking Aids Enhanced Park Aids Note: Enhanced park aids is only available when the transmission is in R (Reverse). Note: The reverse sensing system is not effective at speeds above 3 mph (5 km/h) and may not detect certain angular or moving objects. The enhanced park aids allows the driver to view the area that is being detected by the reverse sensing system.
Page 219: Cruise Control
Cruise Control PRINCIPLES OF OPERATION Cruise control lets you maintain a set speed without keeping your foot on the accelerator pedal. USING CRUISE CONTROL WARNING: Do not use cruise control in heavy traffic, on winding roads or when the road surface is slippery. This could result in loss of vehicle control, serious injury or death.
Page 220: Using Adaptive Cruise Control
Cruise Control Setting a Speed 1. Accelerate to the desired speed. 2. Press the SET control upward and release. 3. Take your foot off the accelerator pedal. The indicator will change colors in the instrument cluster. Changing the Set Speed Note: If you accelerate by pressing the accelerator pedal, the set speed will not change.
Page 221 Cruise Control WARNING: Adaptive cruise control is not a collision warning or avoidance system. Additionally, adaptive cruise control will not detect: • stationary or slow moving vehicles below 6 mph (10 km/h) • pedestrians or objects in the roadway • oncoming vehicles in the same lane. WARNING: Do not use the adaptive cruise control when entering or leaving a highway, in heavy traffic or on roads that are winding, slippery or unpaved.
Page 222 Cruise Control Setting Adaptive Cruise Control 1. Press and release ON. The information display will show the gray indicator light, current gap setting and SET. The system is set to standby mode. 2. Accelerate to the desired speed. 3. Press SET upward and release. The vehicle speed is stored in the memory.
Page 223 Cruise Control When a vehicle ahead of you enters the same lane or a slower vehicle is ahead in the same lane, the vehicle speed adjusts to maintain a preset gap distance. The distance setting is adjustable. The lead vehicle graphic will be illuminated. Your vehicle will maintain a constant distance between the vehicle ahead until: •...
Page 224 Cruise Control Each time you restart your vehicle, the system will select the last chosen gap for the current driver. Disengaging Adaptive Cruise Control Press the brake pedal or press CNCL to disengage the system. The last set speed will display with a strikethrough. Disengaging the system will not erase your previous set speed.
Page 225 Cruise Control Resuming the Set Speed Note: Resume should only be used if you are aware of the set speed and intend to return to it. Press and release RES. Your vehicle will return to the previously set speed. The set speed will display continuously in the information display while the system is active.
Page 226 Cruise Control Detection issues can occur: A. When driving on a different line than the vehicle in front. B. With vehicles that edge into your lane. The system can only detect these vehicles once they move fully into your lane. C.
Page 227 Cruise Control Blocked Sensor WARNING: Do not use ACC when towing a trailer with brake controls. Aftermarket trailer brakes will not function properly when ACC is activated because the brakes are electronically controlled. Failing to do so may result in loss of vehicle control, which could result in serious injury.
Page 228 Cruise Control Cause Action Swirling water, or snow or ice on Do not use system in these the surface of the road may conditions because it may not interfere with the radar signals. detect any vehicle ahead. You are in a desert or remote area Wait a short time or switch to with no other vehicles and no normal cruise control.
Page 229: Driving Aids
Driving Aids DRIVER ALERT (IF EQUIPPED) WARNING: The driver alert system is designed to aid you. It is not intended to replace your attention and judgment. You are still responsible to drive with due care and attention. Note: The system will store the on/off setting in the information display menu through ignition cycles.
Page 230 Driving Aids System Display When active the system will run automatically in the background and only issue a warning if required. You can view the status at any time using the information display. Refer to the Information Displays chapter. The alertness level is shown by six steps in a colored bar. The current assessment of your alertness is within a typical range.
Page 231: Lane Keeping System
Driving Aids LANE KEEPING SYSTEM (IF EQUIPPED) WARNING: The system is designed to aid the driver. It is not intended to replace the driver’s attention and judgment. The driver is still responsible to drive with due care and attention. The system detects unintentional drifting toward the outside of the lane and alerts and/or aids the driver to stay in the lane through the steering system and instrument cluster display.
Page 232 Driving Aids Note: Some vehicle are only equipped with the alert function only. Alert only – Provides a steering wheel vibration when an unintended lane departure is detected. Aid only (if equipped) – Provides a steering input toward the lane center when an unintended lane departure is detected.
Page 233 Driving Aids System Display When you switch the system on, an overhead graphic of a vehicle with lane markings will be displayed in the left instrument cluster display. If the aid mode is selected after you switch the system on, arrows will be displayed with the lane markings.
Page 234 Driving Aids Troubleshooting Why is the feature not available (line markings are gray) when I can see the lane markings on the road? Vehicle speed is outside the operational range of the feature Sun is shining directly into the camera lens Quick intentional lane change Staying too close to the lane marking Driving at high speeds in curves...
Page 235: Blind Spot Information System (Blis) With Cross Traffic Alert (Cta)
Driving Aids BLIND SPOT INFORMATION SYSTEM (BLIS®) WITH CROSS TRAFFIC ALERT (CTA) (IF EQUIPPED) WARNING: To help avoid injuries, NEVER use the BLIS® as a replacement for using the interior and exterior mirrors and looking over your shoulder before changing lanes. BLIS® is not a replacement for careful driving and only an assist.
Page 236 Driving Aids Using the Systems BLIS® turns on when the engine is started and the vehicle is driven forward above 3 mph (5 km/h); it remains on while the transmission is in D (Drive) or N (Neutral). If shifted out of D (Drive) or N (Neutral), the system enters CTA mode.
Page 237 Driving Aids Zone coverage also decreases when parking at shallow angles. Here, the left sensor is mostly obstructed; zone coverage on that side is severely limited. System Lights and Messages The BLIS® and CTA systems illuminate a yellow alert indicator in the outside mirror on the side of the vehicle the approaching vehicle is coming from.
Page 238 Driving Aids System Sensors WARNING: Just prior to the system recognizing a blocked condition and alerting the driver, the number of missed objects will increase. To help avoid injuries, NEVER use the BLIS® as a replacement for using the side and rear view mirrors and looking over your shoulder before changing lanes.
Page 239 Driving Aids Reasons for messages being displayed The radar surface is Clean the fascia area in front of the radar or dirty or obstructed remove the obstruction. The radar surface is Drive normally in traffic for a few minutes to not dirty or obstructed allow the radar to detect passing vehicles so it can clear the blocked state.
Page 240: Collision Warning System
Driving Aids System Errors If either system senses a problem with the left or right sensor, the BLIS® indicator in the information display will illuminate and remain on. Also, BLIND SPOT SYSTEM FAULT or CROSS TRAFFIC SYSTEM FAULT message will appear. When problems that may cause the left or right indicator not to illuminate, only the information display message faults appear.
Page 241 Driving Aids If it is, a red warning light illuminates and an audible warning chime sounds. The brake support system assists the driver in reducing the collision speed by charging the brakes. If the risk of collision further increases after the warning light illuminates, the brake support prepares the brake system for rapid braking.
Page 242 Driving Aids Blocked Sensors If a message regarding a blocked sensor appears in the information display, the radar signals from the sensor have been obstructed. The sensors are located behind a fascia cover near the driver side of the lower grille. When the sensors are obstructed, a vehicle ahead cannot be detected and the collision warning system does not function.
Page 243: Lincoln Adaptive Drive
Driving Aids System Limitations WARNING: The collision warning system’s brake support can only help reduce the speed at which a collision occurs if the driver applies the vehicle’s brakes. The brake pedal must be pressed just like any typical braking situation. Due to the nature of radar technology, there may be certain instances where vehicles do not provide a collision warning.
Page 244 Driving Aids Lincoln Drive Control consists of the following systems: • Continuously Controlled Damping (CCD) dynamically adjusts the shock absorbers stiffness in real time to match the road surface and driver inputs. Vehicle motion (roll, pitch, bounce), suspension position, vehicle loading, vehicle speed, road conditions, and steering are continuously monitored to adjust the suspension damping for optimal vehicle control.
Page 245: Steering
Driving Aids Using Lincoln Drive Control You can configure which of the Drive Control modes are active when the vehicle is in D (Drive) or in S (Sport). The configuration is retained until modified using the information display. To change the vehicle’s Drive Control settings, access the main menu on the information display: 1.
Page 246 Driving Aids WARNING: Obtain immediate service if a system error is detected. You may not notice any difference in the feel of your steering, but a serious condition may exist. Failure to do so may result in loss of steering control. Your vehicle is equipped with an electric power-assisted steering system.
Page 247: Load Carrying
Load Carrying REAR UNDER FLOOR STORAGE (IF EQUIPPED) Pull the strap at the front of the cargo area to open the storage compartment. CARGO NET WARNING: The cargo net is not designed to restrain objects during a collision or heavy braking. The cargo net secures lightweight objects in the cargo area.
Page 248: Luggage Cover
Load Carrying LUGGAGE COVERS (IF EQUIPPED) WARNING: Make sure that the posts are properly latched in mounting features. The cover may cause injury in a sudden stop or accident if it is not securely installed. WARNING: Do not place any objects on the cargo area shade. They may obstruct your vision or strike occupants of vehicle in the case of a sudden stop or collision.
Page 249 Load Carrying Vehicle Curb Weight – is the weight of your new vehicle when you picked it up from your authorized dealer plus any aftermarket equipment. Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
Page 250 Load Carrying Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load weight is also part of cargo weight. 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 251 Load Carrying GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) – including vehicle curb weight and all payload. GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label.
Page 252 Load Carrying • Example only: WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury. 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 253 Load Carrying GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 254 Load Carrying Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.” on your vehicle’s placard. 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle.
Page 255 Load Carrying • Suppose your vehicle has a 1400 lb. (635 kg) cargo and luggage capacity. You and one of your friends decide to pick up cement from the local home improvement store to finish that patio you have been planning for the past 2 years.
Page 256: Towing
Towing TOWING A TRAILER WARNING: Do not exceed the GVWR or the GAWR specified on the certification label. WARNING: Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of your vehicle and could result in engine damage, transmission damage, structural damage, loss of vehicle control, vehicle rollover and personal injury.
Page 257 TRAILER SWAY CONTROL (IF EQUIPPED) WARNING: Turning off trailer sway control increases the risk of loss of vehicle control, serious injury or death. Ford does not recommend disabling this feature except in situations where speed reduction may be detrimental (such as hill climbing), the driver has significant trailer towing experience, and can control trailer sway and maintain safe operation.
Page 258 Towing Your vehicle may tow a Class I or III trailer provided the maximum trailer weight is less than or equal to the maximum trailer weight listed for your vehicle configuration on the following chart. Powertrain and Maximum GCWR Maximum trailer trailer class weight 3.7L TiVCT front-wheel...
Page 259 Towing Trailer Towing Connector (Vehicles with a Trailer Towing Package and 7–Pin Connector) When attaching the trailer wiring connector to your vehicle, only use a proper fitting connector that works with the vehicle and trailer functions. If your vehicle has a trailer towing package, it may have a 7–pin connector.
Page 260 Towing Trailer Brakes WARNING: Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. Electric brakes and manual, automatic or surge-type trailer brakes are safe if you install them properly and adjust them to the manufacturer’s specifications.
Page 261 Towing Trailer Lamps WARNING: Never connect any trailer lamp wiring to the vehicle’s tail lamp wiring; this may damage the electrical system resulting in a fire. Contact an authorized dealer as soon as possible for assistance in proper trailer tow wiring installation. Additional electrical equipment may be required.
Page 262 Towing • Avoid parking on a grade. However, if you must park on a grade: 1. Turn the steering wheel to point your vehicle tires away from traffic flow. 2. Set your vehicle parking brake. 3. Place the automatic transmission in position P. 4.
Page 263: Wrecker Towing
We recommend the use of a wheel lift and dollies or flatbed equipment to tow your vehicle. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Vehicle damage may occur if towed incorrectly, or by any other means.
Page 264: Recreational Towing
Towing Towing an all-wheel drive vehicle requires that all wheels be off the ground, such as using a wheel lift and dollies or flatbed equipment. This prevents damage to the transmission, all-wheel drive system and vehicle. TOWING THE VEHICLE ON FOUR WHEELS Emergency Towing If your vehicle becomes inoperable (without access to wheel dollies, car-hauling trailer, or flatbed transport vehicle), it can be flat-towed...
Page 265 Towing Vehicles Equipped with a 3.5L or 3.7L Engine Note: Put your climate control system in recirculated air mode to prevent exhaust fumes from entering your vehicle. See the Climate Control chapter. Follow these guidelines if you have a need for recreational towing, such as towing your vehicle behind a motorhome or truck.
Page 266: Driving Hints
Driving Hints BREAKING-IN You need to break in new tires for approximately 300 miles (480 kilometers). During this time, your vehicle may exhibit some unique driving characteristics. Avoid driving too fast during the first 1000 miles (1600 kilometers). Vary your speed frequently and change up through the gears early.
Page 267: Driving Through Water
Driving Hints • Drive a heavily loaded vehicle or tow a trailer. • Carry unnecessary weight (approximately 1 mpg [0.4 km/L] is lost for every 400 pounds [180 kilograms] of weight carried). • Add particular accessories to your vehicle (e.g.; bug deflectors, rollbars or light bars, running boards, ski racks).
Page 268: Floor Mats
Driving Hints FLOOR MATS WARNING: Always use floor mats that are designed to fit the foot well of your vehicle, leaving the pedal area unobstructed, and which can be firmly secured to retention posts so that they cannot slip out of position and interfere with the pedals or impair safe operation of your vehicle in other ways.
Page 269: Roadside Emergencies
ROADSIDE ASSISTANCE Vehicles Sold in the United States: Getting Roadside Assistance To fully assist, if you you have a vehicle concern, Ford Motor Company offers a complimentary Roadside Assistance program. This program is separate from the New Vehicle Limited Warranty.
Page 270: Hazard Warning Flashers
United States Lincoln vehicle clients who require Roadside Assistance, call 1-800-387-9333. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest Lincoln dealership within 100 miles (161 kilometers). To obtain reimbursement information, United States Lincoln vehicle clients, call 1-800-521-4140.
Page 271: Fuel Cut-Off Switch
WARNING: Failure to inspect and if necessary repair fuel leaks after a collision may increase the risk of fire and serious injury. Ford Motor Company recommends that the fuel system be inspected by an authorized dealer after any collision. In the event of a moderate to severe collision, this vehicle is equipped with a fuel pump shut-off feature that stops the flow of fuel to the engine.
Page 272 Roadside Emergencies Preparing Your Vehicle Note: Use only a 12–volt supply to start your vehicle. Note: Do not disconnect the battery of the disabled vehicle as this could damage the vehicle’s electrical system. 1. Park the booster vehicle close to the hood of the disabled vehicle making sure the two vehicles do not touch.
Page 273 Roadside Emergencies 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.
Page 274 Roadside Emergencies Removing the Jumper Cables Note: In the illustration, the vehicle on the bottom is used to designate the assisting (boosting) battery. Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface.
Page 275: Customer Assistance
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 276 2. If your inquiry or concern remains unresolved, contact the Sales Manager, Service Manager or Customer Relations Manager. 3. If you require assistance or clarification on Ford Motor Company policies, please contact the Ford Customer Relationship Center In order to help you serve you better, please have the following information available when contacting a Customer Relationship Center: •...
Page 277 Customer Assistance In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the BBB...
Page 278 BBB Auto Line dispute, and decision, are admissible in the court action. Should you choose to accept the BBB AUTO LINE decision, Ford is then bound by the decision, and must comply with the decision within 30 days of receipt of your acceptance letter.
Page 279 (CANADA ONLY) This pertains to vehicles delivered to authorized Canadian dealers. In those cases, where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation or arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 280 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company or Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 281 If you buy your vehicle in North America and then relocate to any of the above locations, register your vehicle identification number (VIN) and new address with Ford Motor Company Export Operations & Global Growth Initiatives by emailing expcac@ford.com. If you are in another foreign country, contact the nearest authorized dealer.
Page 282: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 283: Fuses
Fuses CHANGING A FUSE Fuses WARNING: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. If electrical components in your vehicle are not working, a fuse may have blown.
Page 284: Fuse Specification Chart
Fuses FUSE SPECIFICATION CHART Power Distribution Box WARNING: Always disconnect the battery before servicing high current fuses. WARNING: To reduce risk of electrical shock, always replace the cover to the power distribution box before reconnecting the battery or refilling fluid reservoirs. The power distribution box is located in the engine compartment.
Page 285 Fuses Fuse or relay Fuse amp Protected components number rating 30A** Wipers, Washer pump 50A** Anti-lock brake system pump 50A** B+ #1 access circuit (limousine/livery) 30A** Power liftgate 20A** Moonroof, Power sunshade 20A** 2nd row console power point — 3rd row power seats relay —...
Page 286 Fuses Fuse or relay Fuse amp Protected components number rating 30A** Rear heated/cooled seats 20A** Rear heated seats 25A** Electronic fan relay 3 — Auxiliary blower relay — Cooling fan #1 relay — Front blower relay — Cooling fan (series) relay —...
Page 287 Fuses Fuse or relay Fuse amp Protected components number rating 30A* Fuel injectors, Fuel pump relay 20A* Left high-intensity discharge headlamps 10A* Alternator sensor 10A* Brake on/off switch 10A* Trailer tow back-up lamps 20A* B+ #6 access circuit (limousine/livery) 10A* A/C clutch 15A* Trailer tow stop/turn lamps...
Page 288 Fuses Fuse or relay Fuse amp Protected components number rating Limousine/livery run/accessory Limousine/livery battery saver — Not used — Not used — Not used — Trailer tow park lamps relay 20A* Right high-intensity discharge headlamps 10A* Adaptive cruise control 30A* B+ #3 access circuit (limousine/livery) 15A*...
Page 289 Fuses Fuse or relay Fuse amp Protected components number rating Auxiliary blower, Rear defroster, Battery charge / vacuum pump relays 30A** Body control module run/start — Not used — Not used — Not used — A/C clutch relay *Mini Fuses **Cartridge Fuses Passenger Compartment Fuse Panel The fuse panel is located under the instrument panel to the left of the steering wheel.
Page 290 Fuses The fuses are coded as follows: Fuse or relay Fuse amp Protected components number rating Passenger side rear window Memory seat, Second row seats Passenger side front window Battery saver relay (interior demand lamps and seat power), Limousine battery saver 2 0A Smart amplifier Rear climate control, Rear seat...
Page 291 Fuses Fuse or relay Fuse amp Protected components number rating Low beam headlamps (left) 3rd row power seats, Start button run indicator, Keypad illumination, Brake shift interlock, Powertrain control module wake-up Smart amplifier, Subwoofer amplifier Not used (spare) Not used (spare) Horn relay Steering wheel control module, Instrument cluster...
Page 292 Fuses Fuse or relay Fuse amp Protected components number rating Blind spot monitor, 2nd row heated seats, Reverse sensing system, Rearview camera, Interior mirror, Auto high beam/Lane departure warning/Lane keep assist module Heads-up display, Climate control humidity sensor, Overdrive cancel switch (limousine/livery) Heated steering wheel Refrigerator...
Page 293: Maintenance
GENERAL INFORMATION Have your vehicle serviced regularly to help maintain its roadworthiness and resale value. There is a large network of Ford authorized dealers who are there to help you with their professional servicing expertise. We believe that their specially trained technicians are best qualified to service your vehicle properly and expertly.
Page 294: Opening And Closing The Hood
Maintenance OPENING AND CLOSING THE HOOD 1. Inside the vehicle, pull the hood release handle located at the bottom of the instrument panel near the steering column. 2. Go to the front of the vehicle and release the auxiliary latch using the handle that is located under the front passenger side of the hood.
Page 295: Under Hood Overview
Maintenance UNDER HOOD OVERVIEW 3.7L V6 engine A. Engine coolant reservoir B. Windshield washer fluid reservoir C. Brake fluid reservoir D. Battery E. Power distribution box F. Air filter assembly G. Automatic transmission fluid dipstick H. Engine oil dipstick I. Engine oil filler cap 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 296 Maintenance 3.5L V6 EcoBoost® Engine A. Engine coolant reservoir B. Brake fluid reservoir C. Battery D. Power distribution box E. Air filter assembly F. Automatic transmission fluid dipstick (out of view) G. Engine oil dipstick H. Engine oil filler cap I.
Page 297 Maintenance Engine shield Some vehicles may be equipped with an aero-shield under the engine. This shield needs to be removed for service, including oil and filter changes. It is secured with four quick release fasteners. 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 298 Maintenance 2.0L EcoBoost® Engine A. Engine coolant reservoir B. Brake fluid reservoir C. Battery D. Power distribution box E. Air filter assembly F. Engine oil filler cap G. Engine oil dipstick H. Windshield washer fluid reservoir 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 299: Engine Oil Dipstick
Maintenance ENGINE OIL DIPSTICK 2.0L EcoBoost A. MIN B. MAX 3.7L and 3.5L EcoBoost A. MIN B. MAX ENGINE OIL CHECK Note: Check the level before starting the engine. Note: Make sure that the level is between the MIN and MAX marks. 1.
Page 300: Engine Coolant Check
Note: For best results, coolant concentration should be tested with a refractometer such as Rotunda tool 300ROB75240 available from your dealer. Ford does not recommend the use of hydrometers or coolant test strips for measuring coolant concentrations. Note: Automotive fluids are not interchangeable; do not use engine coolant/antifreeze or windshield washer fluid outside of its specified function and vehicle location.
Page 301 Maintenance Adding Engine Coolant WARNING: Do not add engine coolant when the engine is hot. Steam and scalding liquids released from a hot cooling system can burn you badly. Also, you can be burned if you spill coolant on hot engine parts.
Page 302 Severe Climates If you drive in extremely cold climates: • It may be necessary to have a Ford authorized dealer increase the coolant concentration above 50%. • A coolant concentration of 60% will provide improved freeze point protection.
Page 303 Maintenance Vehicles driven year-round in non-extreme climates should use prediluted engine coolant for optimum cooling system and engine protection. Engine fluid temperature management (EcoBoost engine only) WARNING: To reduce the risk of collision and injury, be prepared that the vehicle speed may reduce and the vehicle may not be able to accelerate with full power until the fluid temperatures reduce.
Page 304 Maintenance 3. Turn the engine off and wait for it to cool before checking the coolant level. WARNING: Never remove the coolant reservoir cap while the engine is running or hot. 4. If the coolant level is normal, you may restart your engine and continue on.
Page 305: Automatic Transmission Fluid Check
Maintenance When Fail-Safe Mode is Activated WARNING: Fail-safe mode is for use during emergencies only. Operate the vehicle in fail-safe mode only as long as necessary to bring the vehicle to rest in a safe location and seek immediate repairs. When in fail-safe mode, the vehicle will have limited power, will not be able to maintain high-speed operation, and may completely shut down without warning, potentially losing engine power, power steering assist,...
Page 306 Maintenance Do not use supplemental transmission fluid additives, treatments or cleaning agents. The use of these materials may affect transmission operation and result in damage to internal transmission components. 6F50/6F55 Transmission WARNING: The dipstick cap and surrounding components may be hot; gloves are recommended. WARNING: Use gloves when moving the air filter assembly;...
Page 307 Maintenance Moving the Air Filter Assembly (EcoBoost engine) WARNING: Do not run engine with the air filter disconnected. 1. Shut the engine off. 2. Clean the area around the clamp that connects the air filter assembly to the rubber hose (1). 3.
Page 308 Maintenance 7. Without disconnecting the sensor (4), pull the air filter assembly up to disconnect the air filter assembly from the seated grommets located underneath the air filter assembly. 8. Rotate the air filter assembly 90 degrees counterclockwise and reinstall into the rubber hose. 9.
Page 309 Maintenance High fluid level If the fluid level is above the MAX range of the dipstick, remove fluid to reach the hashmark level. Note: Fluid level above the MAX level may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. If your vehicle has been operated for an extended period at high speeds, in city traffic during hot weather or pulling a trailer, the vehicle should be turned off until normal operating temperatures are reached.
Page 310: Brake Fluid Check
Add fluid to fill the reservoir if the level is low. Only use a washer fluid that meets Ford specifications. See the technical specifications chart in the Capacities and Specifications chapter. Note: The front and rear washer systems are supplied from the same reservoir.
Page 311: Battery
Maintenance Washer fluids containing non-methanol antifreeze agents should be used only if they provide cold weather protection without damaging the vehicle’s paint finish, wiper blades or washer system. CHANGING THE VEHICLE BATTERY WARNING: Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery.
Page 312 Maintenance If you see any corrosion on the battery or terminals, remove the cables from the terminals and clean with a wire brush. You can neutralize the acid with a solution of baking soda and water. It is recommended that the negative battery cable terminal be disconnected from the battery if you plan to store your vehicle for an extended period of time.
Page 313: Checking The Wiper Blades
Maintenance CHECKING THE WIPER BLADES Run the tip of your fingers over the edge of the blade to check for roughness. Clean the wiper blades with washer fluid or water applied with a soft sponge or cloth. CHANGING THE WIPER BLADES 1.
Page 314: Air Filter(S)
Maintenance Changing rear window wiper blade To replace the rear wiper blade: 1. Grab the wiper arm with one hand close to the arm/blade joint and pull it as far away from the glass as possible. Do not use excessive force because it can break the wiper arm at the heel.
Page 315 Maintenance Note: Failure to use the correct air filter element may result in severe engine damage. The customer warranty may be void for any damage to the engine if the correct air filter element is not used. Changing the air filter element 3.7L V6/2.0L EcoBoost®...
Page 316: Adjusting The Headlamps
Maintenance 2. Lift the passenger’s side of the cover and push the cover toward the passenger’s side. Release the three tabs on the cover from the three slots in the driver’s side of the housing. 3. Carefully separate the cover from the housing. 4.
Page 317 Maintenance Vertical Aim Adjustment 1. Park the vehicle directly in front of a wall or screen on a level surface, approximately 25 feet (7.6 meters) away. • (1) 8 feet (2.4 meters) • (2) Center height of lamp to ground •...
Page 318: Changing A Bulb
Maintenance 5. Locate the vertical adjuster on each headlamp. Using a Phillips #2 screwdriver, turn the adjuster either clockwise or counterclockwise in order to adjust the vertical aim of the headlamp. The horizontal edge of the brighter light should touch the horizontal reference line.
Page 319 Maintenance Replacing HID headlamp bulbs The headlamps on your vehicle use a “high intensity discharge” source. These lamps operate at a high voltage. When the bulb is burned out, the bulb and starter capsule assembly must be replaced by your authorized dealer.
Page 320 Maintenance Replacing rear stop/tail/turn/backup and side marker lamps Your vehicle is equipped with stop/tail/turn/backup and side marker lamp assemblies containing integral multiple light emitting diodes (LED). If replacement is required, see your authorized dealer. Replacing high-mount brake lamp bulbs Your vehicle is equipped with an LED high-mount brake lamp. It is designed to last the life of the vehicle.
Page 321 Maintenance BULB SPECIFICATION CHART Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to ensure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.
Page 322: Vehicle Care
Vehicle Care GENERAL INFORMATION Your Ford or Lincoln authorized dealer has many quality products available to clean your vehicle and protect its finishes. CLEANING PRODUCTS For best results, use the following products or products of equivalent quality: Motorcraft Bug and Tar Remover (ZC-42)
Page 323 Vehicle Care • Note: Suntan lotions and insect repellents can damage any painted surface; if these substances come in contact with your vehicle, wash it off as soon as possible. • Remove any exterior accessories before entering a car wash. Stripes or Graphics (if equipped) Do not use a commercial or high-pressure wand on the surface or edge of stripes and graphics.
Page 324: Waxing
Vehicle Care WAXING Regular waxing is necessary to protect the paint on your car from the elements. We recommend that you wash and wax the painted surface once or twice a year. When washing and waxing, park your vehicle in a shaded area out of direct sunlight.
Page 325: Cleaning The Windows And Wiper Blades
Vehicle Care • Spray Motorcraft Engine Shampoo and Degreaser on all parts that require cleaning and pressure rinse clean. In Canada, use Motorcraft Engine Shampoo. • Never wash or rinse the engine while it is hot or running; water in the running engine may cause internal damage.
Page 326: Cleaning The Interior
Vehicle Care CLEANING THE INTERIOR WARNING: Do not use cleaning solvents, bleach or dye on the vehicle’s safety belts, as these actions may weaken the belt webbing. WARNING: On vehicles equipped with seat-mounted airbags, do not use chemical solvents or strong detergents. Such products could contaminate the side airbag system and affect performance of the side airbag in a collision.
Page 327: Cleaning The Instrument Panel And Instrument Cluster Lens
Vehicle Care CLEANING THE INSTRUMENT PANEL AND INSTRUMENT CLUSTER LENS WARNING: Do not use chemical solvents or strong detergents when cleaning the steering wheel or instrument panel to avoid contamination of the airbag system. Clean the instrument panel and cluster lens with a clean, damp, white, cotton cloth, then use a clean and dry, white, cotton cloth to dry these areas.
Page 328: Cleaning Leather Seats
Vehicle Care CLEANING LEATHER SEATS (IF EQUIPPED) • Remove dust and loose dirt with a vacuum cleaner. • Clean spills and stains as quickly as possible. • For routine cleaning, wipe the surface with a soft, damp cloth. For more thorough cleaning, wipe the surface with a mild soap and water solution.
Page 329: Vehicle Storage
Vehicle Care VEHICLE STORAGE If you plan on storing your vehicle for an extended period of time (30 days or more), read the following maintenance recommendations to make sure your vehicle stays in good operating condition. All motor vehicles and their components were engineered and tested for reliable, regular driving.
Page 330 Vehicle Care Cooling system • Protect against freezing temperatures. • When removing vehicle from storage, check coolant fluid level. Confirm there are no cooling system leaks, and fluid is at the recommended level. Battery • Check and recharge as necessary. Keep connections clean. •...
Page 331: Wheels And Tires
Wheels and Tires GENERAL INFORMATION Notice to Crossover Vehicle Owners Crossover vehicles handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Crossover vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road...
Page 332 Wheels and Tires Note: Your all-wheel drive vehicle is not intended for off-road use. This feature gives your vehicle some limited off-road capabilities in which driving surfaces are relatively level, obstruction-free and otherwise similar to normal on-road driving conditions. Operating your vehicle under other than those conditions could subject the vehicle to excessive stress which might result in damage which is not covered under your warranty.
Page 333: Tire Care
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 334 Wheels and Tires Traction AA A B C WARNING: The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. The traction grades, from highest to lowest are AA, A, B, and C. The grades represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete.
Page 335 Wheels and Tires • Extra load: A class of P-metric or Metric tires designed to carry a heavier maximum load at 42 psi (2.9 bar). Increasing the inflation pressure beyond this pressure will not increase the tire’s load-carrying capability. • kPa: Kilopascal, a metric unit of air pressure. •...
Page 336 Wheels and Tires Information on P Type Tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) A.
Page 337 Wheels and Tires G. H: Indicates the tire’s speed rating. The speed rating denotes the speed at which a tire is designed to be driven for extended periods of time under a standard condition of load and inflation pressure. The tires on your vehicle may operate at different conditions for load and inflation pressure.
Page 338 Wheels and Tires J. Tire Ply Composition and Material Used: Indicates the number of plies or the number of layers of rubber-coated fabric in the tire tread and sidewall. Tire manufacturers also must indicate the ply materials in the tire and the sidewall, which include steel, nylon, polyester, and others. K.
Page 339 Wheels and Tires Additional Information Contained on the Tire Sidewall for LT Type Tires LT type tires have some additional information beyond those of P type tires. These differences are described below. Note: Tire Quality Grades do not apply to this type of tire. A.
Page 340 Wheels and Tires Information on T Type Tires T type tires have some additional information beyond those of P type tires. These differences are described below. T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 341 You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 342 Wheels and Tires Maximum Inflation Pressure is the tire manufacturer’s maximum permissible pressure or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure, which can be found on the Safety Compliance Certification Label (affixed to either the door hinge pillar, door-latch post, or the door edge that meets the door-latch post, next to the driver’s seating position), or Tire Label which is located...
Page 343 Wheels and Tires Note: Some spare tires operate at a higher inflation pressure than the other tires. For T-type mini-spare tires, see the Dissimilar Spare Tire and Wheel Assembly Information section. Store and maintain at 60 psi (4.15 bar). For full-size and dissimilar spare tires, see Dissimilar Spare Tire and Wheel Assembly Information under Changing a Road Wheel in this chapter.
Page 344 Wheels and Tires Damage Periodically inspect the tire treads and sidewalls for damage (such as bulges in the tread or sidewalls, cracks in the tread groove and separation in the tread or sidewall). If damage is observed or suspected, have the tire inspected by a tire professional. Tires can be damaged during off-road use, so inspection after off-road use is also recommended.
Page 345 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label (affixed to either the door hinge pillar, door-latch post, or the door edge that meets the door-latch post, next to the driver’s seating position), or the Tire Label...
Page 346 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your tire pressure monitoring system.
Page 347 Wheels and Tires Safety Practices WARNING: If your vehicle is stuck in snow, mud, or sand, do not rapidly spin the tires. Spinning the tires can tear the tire and cause an explosion. A tire can explode in as little as three to five seconds.
Page 348 Wheels and Tires The tires should also be balanced periodically. An unbalanced tire and wheel assembly may result in irregular tire wear. Tire Rotation Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 349 USING SNOW CHAINS WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 350: Tire Pressure Monitoring System (Tpms)
Wheels and Tires TIRE PRESSURE MONITORING SYSTEM WARNING: The tire pressure monitoring system is NOT a substitute for manually checking tire pressure. The tire pressure should be checked periodically (at least monthly) using a tire gauge. See Inflating Your Tires in this chapter. Failure to properly maintain your tire pressure could increase the risk of tire failure, loss of control, vehicle rollover and personal injury.
Page 351 Wheels and Tires telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly. The tire pressure monitoring system complies with part 15 of the FCC rules and with RSS-210 of Industry Canada.
Page 352 Wheels and Tires When You Believe Your System Is Not Operating Properly The main function of the tire pressure monitoring system is to warn you when your tires need air. It can also warn you in the event the system is no longer capable of functioning as intended.
Page 353 Wheels and Tires Low tire Possible cause Customer action required pressure warning light Flashing Spare tire in use Repair the damaged road wheel warning light and tire assembly and reinstall it on the vehicle to restore system function. For a description on how the system functions, see When Your Temporary Spare Tire is Installed in this section.
Page 354: Changing A Road Wheel
Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 355 Wheels and Tires 2. Full-size dissimilar spare with label on wheel: This spare tire has a label on the wheel that states: THIS TIRE AND WHEEL FOR TEMPORARY USE ONLY When driving with one of the dissimilar spare tires listed above, do not: •...
Page 356 Wheels and Tires • Winter weather driving capability • Wet weather driving capability • All-Wheel driving capability • Load leveling adjustment When driving with the full-size dissimilar spare tire and wheel assembly, additional caution should be given to: • towing a trailer. •...
Page 357 Wheels and Tires WARNING: Always use the jack provided as original equipment with your vehicle. If using a jack other than the one provided as original equipment with your vehicle, make sure the jack capacity is adequate for the vehicle weight, including any vehicle cargo or modifications.
Page 358 Wheels and Tires Limousine 1. Remove the wing nut that secures the spare tire by turning it counterclockwise. 2. Lift and remove the spare tire from the trunk. 3. Remove the wrench (1) and jack (2) from the jack foam pockets. 4.
Page 359 Wheels and Tires 6. Remove the wheel cover (if equipped) with the lug wrench tip and loosen each wheel lug nut one-half turn counterclockwise, but do not remove them until the wheel is raised off the ground. 7. The vehicle jacking points are shown here, and are depicted on the yellow warning label on the jack.
Page 360 Wheels and Tires Stowing the tire and jack (non-limousine) 1. Fully collapse the jack, fold the lug wrench socket into the handle and place the jack and wrench into the felt bag as shown. Place the extension bolt or L-shaped bolt into the external pocket of the felt bag.
Page 361 Wheels and Tires If you are stowing the flat tire, remove the L-shaped bolt from the external pocket of the felt bag. With the third row seat in the raised position, stand the flat tire in the rear of the vehicle with the tire’s valve stem facing the rear of the vehicle.
Page 362: Technical Specifications
M14 x 1.5 150 ft-lb 204 N•m * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. Note: Inspect the wheel pilot hole and mounting surface prior to installation. Remove any visible corrosion or loose particles.
Page 363: Capacities And Specifications
Capacities and Specifications ENGINE SPECIFICATIONS 3.5L V6 2.0L EcoBoost Engine 3.7L V6 engine EcoBoost engine engine Cubic inches Fuel See Octane See Octane See Octane recommendations recommendations recommendations in the Fuel and in the Fuel and in the Fuel and Refueling chapter.
Page 364 Capacities and Specifications 2.0L EcoBoost engine A. Long drivebelt on the first pulley groove closest to the engine B. Short drivebelt on the second pulley groove farthest from the engine 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 365 Capacities and Specifications 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 366 Capacities and Specifications 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 367 Capacities and Specifications 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 368 Capacities and Specifications 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 369: Part Numbers
Note: Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft® or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used.
Page 370: Vehicle Certification Label
Capacities and Specifications The Vehicle Identification Number (VIN) contains the following information: A. World manufacturer identifier B. Brake system / Gross Vehicle Weight Rating (GVWR) / Restraint Devices and their location C. Make, vehicle line, series, body type D. Engine type E.
Page 371: Transmission Code Designation
Capacities and Specifications TRANSMISSION CODE DESIGNATION You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Code 6-speed automatic transmission (6F50) 6-speed automatic transmission (6F55) 6-speed automatic transmission (6F35) 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 372: Accessories
Accessories ACCESSORIES For a complete listing of the accessories that are available for your vehicle, please contact an authorized dealer or visit our online store at: www.Accessories.Lincoln.com (United States only). Lincoln Motor Company will repair or replace any properly authorized dealer-installed Lincoln Genuine Accessories found to be defective in factory-supplied materials or workmanship during the warranty period, as well as any component damaged by the defective accessories.
Page 373 Accessories For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety Compliance Certification label).
Page 374: Ford Extended Service Plan
3. BaseCARE – Covers 84 components 4. PowertrainCARE – Covers 29 critical components Ford ESP is honored by all Ford and Lincoln Dealers in the United States and Canada. It is the only Extended Service Plan authorized and backed by Ford Motor Company. That means you get: •...
Page 375 • Destination assistance for taxi, shuttle, rental car coverage and emergency transportation Transferable Coverage If you sell your vehicle before your Ford Extended Service Plan coverage expires, you can transfer any remaining coverage to the new owner. Whenever you sell your vehicle, prospective buyers may have a higher...
Page 376 To learn more, call our Ford ESP specialists at 800-367-3377. Don’t forget to ask about our interest free payment program, allowing you all the security and benefits Ford ESP has to offer while paying over time. You are pre-approved with no credit checks, no hassles!
Page 377: Audio System
Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Note: Do not insert CDs with homemade paper (adhesive) labels into the CD player as the label may peel and cause the CD to become jammed.
Page 378 Audio System MP3 Track and Folder Structure Audio systems capable of recognizing and playing MP3 individual tracks and folder structures work as follows: • There are two different modes for MP3 disc playback: MP3 track mode (system default) and MP3 folder mode. •...
Page 379: Mylincoln Touch™ System
Audio System AM/FM/CD PREMIUM AUDIO SYSTEM WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 380: Rear Seat Controls (If Equipped)
Audio System D. TUNE + and TUNE - : • In radio mode, press these buttons to manually search through the radio frequency band. • In Sirius mode, press these buttons to find the next or previous available satellite radio station. E.
Page 381 Audio System MEDIA HUB The media hub is located behind a small access door in the instrument panel and has the following features: A. A/V inputs B. SD card slot C. USB ports For more information, see the MyLincoln Touch chapter. 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 382: Mylincoln Touch
MyLincoln Touch™ INTRODUCTION WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 383 MyLincoln Touch™ Note: Some features are not available while your vehicle is moving. Note: Your system is equipped with a feature that allows you to access and control audio features for 30 minutes after you switch the ignition off (and no doors open). PHONE Press to select any of the following: •...
Page 384 MyLincoln Touch™ SETTINGS Press to select any of the following: • Clock • Display • Sound • Vehicle • Settings • Help HOME Press to access your home screen. Depending on your vehicle’s option package and software, your screens may vary in appearance from the descriptions in this section.
Page 385 MyLincoln Touch™ Using the Touch-sensitive Controls on Your System To turn a feature on and off, just touch the graphic with your finger. To get the best performance from the touch-sensitive controls, keep in mind: • Do not press hard on the controls. They are sensitive to light touch. •...
Page 386 Safety information WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 387 MyLincoln Touch™ • For your safety, some SYNC® functions are speed dependent and cannot be performed when the vehicle is traveling at speeds greater than 3 mph (5 km/h). • Ensure that you review your device’s user guide before using with SYNC®.
Page 388: Privacy Information
Master Reset to erase all information stored in SYNC®. SYNC® data cannot be accessed without special equipment and access to the vehicle’s SYNC® module. Ford Motor Company and Ford of Canada will not access SYNC® data for any purpose other than as...
Page 389: Infotainment Display
MyLincoln Touch™ ACCESSING AND ADJUSTING MODES THROUGH YOUR RIGHT VEHICLE INFORMATION DISPLAY The display is located on the right side of your instrument cluster. You can use your steering wheel controls to view and make minor adjustments to active modes without taking your hands off the wheel. For example: •...
Page 390: Voice Recognition
MyLincoln Touch™ Audio Sources and Memory Presets Use the OK and arrow buttons on the right side of your steering wheel to scroll through the available modes. You can make selections from the menu by using the OK button. The selection menu expands and different options appear. •...
Page 391 MyLincoln Touch™ How to Use Voice Commands with Your System Press the voice icon. After the tone, speak your command clearly. These commands can be said at any time. “Cancel” “Exit” “Go back” “List of commands” “Main menu” “Next page” “Previous page”...
Page 392 MyLincoln Touch™ Accessing a List of Available Commands • If you use the touchscreen, press the Settings icon > Help > Voice Command List. • If you use the steering wheel control, press the voice icon. After the tone, speak your command clearly. Voice command list “Audio list of commands”...
Page 393 MyLincoln Touch™ Confirmation Prompts: The system uses these short questions to confirm your voice request. If turned off, the system simply makes a best guess as to what you requested. The system may still occasionally ask you to confirm settings. Phone/Media Candidate Lists: Candidate lists are lists of possible results from your voice commands.
Page 394: Listening To Music
MyLincoln Touch™ ENTERTAINMENT A. AM 1 and AM AST B. FM 1, FM 2 and FM AST C. SIRIUS D. CD E. USB F. Touch this button to scroll down for more options, such as: • SD Card • BT Stereo •...
Page 395 MyLincoln Touch™ Browsing Device Content When listening to audio on a device, you can browse through other devices without having to change sources. For example, if you are currently listening to audio on an SD card, you can browse all the artists that are stored on your USB device.
Page 396 MyLincoln Touch™ Your voice system allows you to change audio sources with a simple voice command. For example, if you are listening to music on a USB device, then want to switch to a satellite radio channel, simply press the voice button on the steering wheel controls and say the name of the Sirius station (such as, “the Highway”).
Page 397 MyLincoln Touch™ Scan Touch this button to go to the next strong AM or FM radio station. The light on the button illuminates when the feature is on. Options Sound Settings allows you to adjust settings for: • Bass • Midrange •...
Page 398 MyLincoln Touch™ HD Radio™ Information (If Available) Note: HD Radio broadcasts are not available in all markets. HD Radio technology is the digital evolution of analog AM/FM radio. Your system has a special receiver that allows it to receive digital broadcasts (where available) in addition to the analog broadcasts, it already receives.
Page 399 MyLincoln Touch™ When HD Radio broadcasts are active, you can access the following functions: • Scan allows you to hear a brief sampling of all available stations. This feature still works when HD Radio reception is on, although it does not scan for HD2-HD7 channels.
Page 400 MyLincoln Touch™ In order to provide the best possible experience, use the contact form to report any station issues found while listening to a station broadcasting with HD Radio technology. Independent entities own and operate each station. These stations are responsible for making sure all audio streams and data fields are accurate.
Page 401 HD Radio Technology manufactured under license from iBiquity Digital Corp. U.S. and foreign patents. HD Radio and the HD and HD Radio logos are proprietary trademarks of iBiquity Digital Corp. Ford Motor Company and iBiquity Digital Corp. are not responsible for the content sent using HD Radio technology.
Page 402 MyLincoln Touch™ “TUNE” “AM autoset” “FM2” “AM autoset preset <#>” “FM 2 preset <#>” “AM preset <#>” “HD <#>” “FM” “Preset <#>” “FM <87.9–107.9>” “Help” “FM <87.9-107.9> HD <#>” If available. Sirius Satellite Radio (If Activated) Press the lower left corner of the touchscreen, then select the SIRIUS tab.
Page 403 Note: Sirius does not support the Alert feature on all channels. Ford Motor Company shall not be responsible for Alert feature variation. Electronic Serial Number (ESN) is required when you need to activate, modify or track your satellite radio account.
Page 404 MyLincoln Touch™ Browse Touch this button to view a list of all available stations. Scroll to see more categories. Touch the station you want to listen to. Touch Skip if you want to skip this channel. Touch Lock if you do not want anyone to listen to this channel. Touch Title or Artist to see song and artists on other stations.
Page 405 Note: Sirius reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 406 MyLincoln Touch™ Potential satellite radio reception issues Antenna For optimal reception performance, keep the obstructions antenna clear of snow and ice build-up and keep luggage and other materials as far away from the antenna as possible. Terrain Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree foliage and thunderstorms can interfere with your reception.
Page 407 MyLincoln Touch™ Sirius troubleshooting tips Radio display Condition Possible action Unsubscribed Channel. Your subscription does Contact Sirius at not include this 1–888–539–7474 to channel. subscribe to the channel, or tune to another channel. No Signal. The signal is lost from The signal is blocked.
Page 408 MyLincoln Touch™ Shuffle Touch this button to play the tracks or entire albums in random order, or turn the feature off if already on. Scan Touch this button to hear a brief sampling of all available tracks. More Info Touch this button to see disc information. Options Sound Settings allows you to adjust settings for: •...
Page 409 MyLincoln Touch™ SD Card Slot and USB Port SD Card Slot Note: Your SD card slot is spring-loaded. To remove the SD card, press the card in and the system ejects it. Do not attempt to pull the card to remove it as this could cause damage.
Page 410 MyLincoln Touch™ Playing Music from Your Device Note: The system is capable of indexing up to 30,000 songs. Insert your device and select the SD Card or USB tab once the system recognizes it. You can then select from the following options: Repeat replays the currently playing song or album.
Page 411 MyLincoln Touch™ SD Card and USB Voice Commands If you are listening to a USB device or an SD card, press the voice button on the steering wheel control. When prompted, say any of the commands in the following chart. If you are not listening to a USB device or an SD card, press the voice button and, after the tone, say “USB”...
Page 412 MyLincoln Touch™ “BROWSE” “Album <name>” “All video podcasts” “All albums” “All videos” “All artists” “Artist <name>” “All audiobooks” “Audiobook <name>” “All authors” “Author <name>” “All composers” “Composer <name>” “All folders” “Folder <name>” “All genres” “Genre <name>” “All movies” “Playlist <name>” “All music videos”...
Page 413 MyLincoln Touch™ Bluetooth Audio Your system allows you to stream audio over your vehicle’s speakers from your connected, Bluetooth-enabled cellular phone. To access, press the lower left corner on the touchscreen, then select the BT Stereo tab. Bluetooth Audio Voice Commands If you are listening to a Bluetooth audio device, press the voice button on the steering wheel control.
Page 414 MyLincoln Touch™ Your A/V inputs allow you to connect an auxiliary audio/video source (such as a gaming systems or a personal camcorder) by connecting RCA cords (not included) to these input jacks. The jacks are yellow, red and white and are located either behind a small access door on the instrument panel or in your center console.
Page 415: Phone Features
MyLincoln Touch™ Troubleshooting • Do not connect the audio input jack to a line level output. The jack only works correctly with devices that have a headphone output with a volume control. • Do not set the portable music player’s volume level higher than is necessary to match the volume of the CD or FM radio as this causes distortion and reduces sound quality.
Page 416 MyLincoln Touch™ Hands-free calling is one of the main features of SYNC. Once you pair your phone, you can access many options using the touchscreen or voice commands. While the system supports a variety of features, many are dependent on your cellular phone’s functionality. At a minimum, most cellular phones with Bluetooth wireless technology support the following functions: •...
Page 417 MyLincoln Touch™ 3. If you are prompted to enter a PIN on your device, it does not support Secure Simple Pairing. To pair, enter the PIN displayed on the touchscreen. Skip the next step. 4. When prompted on your phone’s display, confirm that the PIN provided by SYNC matches the PIN displayed on your cellular phone.
Page 418 MyLincoln Touch™ Receiving Calls During an incoming call, an audible tone sounds. Call information appears in the display if it is available. Accept the call by pressing Accept on the touchscreen or by pressing this phone button on your steering wheel controls. Reject the call by pressing Reject on the touchscreen or by pressing this phone button on your steering wheel controls.
Page 419 MyLincoln Touch™ Messaging Send text messages using your touchscreen. See Text messaging later in this section. Settings Touch this button to access various phone settings, such turning Bluetooth on and off, managing your phonebook and more. See Phone settings later in this section. Text Messaging Note: Downloading and sending text messages using Bluetooth are phone-dependent features.
Page 420 MyLincoln Touch™ Pre-defined text message options I’ll call you back in a few minutes. I just left, I’ll be there soon. Can you give me a call? I’m on my way. I’m running a few minutes late. I’m ahead of schedule, so I’ll be there early. I’m outside.
Page 421 MyLincoln Touch™ Bluetooth Touch this tab to turn Bluetooth off or on. Do Not Disturb Touch this tab if you want all calls to go directly to your voice mail and not ring in the vehicle. When this feature is on, text message notifications do not ring inside the cabin either.
Page 422 MyLincoln Touch™ Phone Voice Commands Press the voice button on the steering wheel control. After the tone, say any of the following commands: “PHONE” “Call” “Join calls” “Call <name>” “Listen to text message <#>” “Call <name> at home” “Listen to text messages” “Call <name>...
Page 423: Information Menu
Note: SYNC Services varies by trim level and model year and may require a subscription. Traffic alerts and turn-by-turn directions available in select markets. Message and data rates may apply. Ford Motor Company reserves the right to change or discontinue this product service at any time without prior notification or incurring any future obligation.
Page 424 For more information, see SYNC Services Terms and Conditions at www.SYNCMyRide.com. If you do not want Ford or its service providers to collect your vehicle travel information or other information identified in the Terms and Conditions, do not subscribe or use the service.
Page 425 MyLincoln Touch™ Connecting to SYNC Services Using the Touchscreen If your vehicle is equipped with Navigation, touch the i (Information) button to access these features. If your vehicle is not equipped with Navigation, touch the corner of the touchscreen with the green tab. Press Services.
Page 426 MyLincoln Touch™ If your vehicle is equipped with Navigation, SYNC Services downloads your requested destination to the navigation system. The navigation system then calculates the route and provides driving instructions. See the Navigation system section for more information. Disconnecting from SYNC Services 1.
Page 427 Sirius Travel Link. Note: Neither Sirius nor Ford is responsible for any errors or inaccuracies in the Sirius Travel Link services or its use in vehicles. When you subscribe to Sirius Travel Link, it can help you locate the best...
Page 428 MyLincoln Touch™ Fuel Prices Touch this button to view fuel prices at stations close to your vehicle’s location or on an active navigation route. Movie Listings Touch this button to view nearby movie theaters and their show times, if available. Weather Touch this button to view the nearby weather, current weather, or the five day forecast for the chosen area.
Page 429 MyLincoln Touch™ Sports headlines, sports schedules and sports scores voice commands “Baseball” “My teams” “College basketball” “NBA” “College football” “NFL” “Golf” “NHL” “MLS” “WNBA” “Motor sports” “TRAVEL LINK” “5–day weather “Golf schedule” “NBA scores” forecast” “Baseball headlines” “MLS headlines” “NFL headlines” “Baseball schedule”...
Page 430 MyLincoln Touch™ Alerts If your vehicle is equipped with Navigation, touch the i (Information) button to access these features. If your vehicle is not equipped with Navigation, touch the corner of the touchscreen with the green tab. Press Alerts, and then choose from any of the following services: •...
Page 431 MyLincoln Touch™ Note: The SYNC 911 Assist feature must be set on prior to the incident. Note: Before setting this feature on, make sure that you read the 911 Assist privacy notice later in this section for important information. Note: If any user turns 911 Assist on or off, that setting applies for all paired phones.
Page 432 MyLincoln Touch™ • A connected Bluetooth-enabled phone must have adequate network coverage, battery power and signal strength. • The vehicle must have battery power and be located in the United States, Canada or in a territory in which 911 is the emergency number.
Page 433 MyLincoln Touch™ Vehicle Health Report (If Equipped, United States Only) WARNING: Always follow scheduled maintenance instructions, regularly inspect your vehicle, and seek repair for any damage or problem you suspect. Vehicle Health Report supplements, but cannot replace, normal maintenance and vehicle inspection. Vehicle Health Report only monitors certain systems electronically monitored by your vehicle and will not monitor or report the status of any other system, (such as brake lining wear).
Page 434 “Vehicle health report”. Vehicle Health Report Privacy Notice When you create a Vehicle Health Report, Ford Motor Company may collect your cellular phone number (to process your report request) and diagnostic information about your vehicle. Certain versions or updates to Vehicle Health Report may also collect more vehicle information.
Page 435: Settings
MyLincoln Touch™ SETTINGS A. Clock B. Display C. Sound D. Vehicle E. Settings F. Help Under this menu, you can set your clock, access and adjust the display, sound and vehicle settings as well as access settings for specific modes or the help feature. Clock Note: You cannot manually set the date.
Page 436 MyLincoln Touch™ You can also turn the outside air temperature display on and off. It appears at the top center of the touchscreen, next to the time and date. The system automatically saves any updates you make to the settings. Display You can adjust the touchscreen display through the touchscreen or by pressing the voice button on your steering wheel controls and when...
Page 437 MyLincoln Touch™ Only the photograph(s), which meets the following conditions, display: • Compatible file formats are as follows: .jpg, .gif, .png, .bmp. • Each file must be 1.5 MB or less. • Recommended dimensions: 800 x 384. Sound Press the Settings icon > Sound, then select from the following: Sound Settings Bass...
Page 438 MyLincoln Touch™ Door Keypad Code To change the keypad code for your keyless entry keypad system: 1. Press the Settings icon > Vehicle > Door Keypad Code. 2. Enter your current factory code, then, when prompted, enter your new code. Rear View Camera This menu allows you to access settings for your rear view camera.
Page 439 MyLincoln Touch™ System Touch Screen Button Select to have the system beep to confirm Beep choices made through the touchscreen. Touch Panel Button Select to have the system beep to confirm Beep button choices made through the climate or audio system. Keyboard Layout Have the touchscreen keyboard display in QWERTY or ABC format.
Page 440 MyLincoln Touch™ Media Player Press the Settings icon > Settings > Media Player, then select from the following: Media player Autoplay When this feature is on, the system automatically switches to the media source upon initial connection. This allows you to listen to music during the indexing process.
Page 441 MyLincoln Touch™ Navigation Press the Settings icon > Settings > Navigation, then select from the following: Navigation Map Preferences Turn breadcrumbs on and off. Have the system display your turn list top to bottom or bottom to top. Turn the Parking POI notification on and off. Route Preferences Preferred Route allows you to choose to have the system display the Shortest,...
Page 442 MyLincoln Touch™ Navigation Traffic Preferences Have the system display areas where roadwork occurs. Have the system display incident icons. Have the system display areas where difficult driving conditions may occur. Have the system display areas where snow and ice on the road may occur. Have the system display any smog alerts.
Page 443 MyLincoln Touch™ Phone Phone Ringer Select the type of notification for phone calls - ring tone, beep, text to speech, or have it be silent. Text Message Select the type of notification for text messages - alert tone, beep, text to speech, or Notification have it be silent.
Page 444 MyLincoln Touch™ Wireless & Internet Your system has a Wi-Fi feature that creates a wireless network within your vehicle, thereby allowing other devices (such as personal computers or phones) in your vehicle to speak to each other, share files or play games.
Page 445 MyLincoln Touch™ Wireless & Internet USB Mobile Instead of using Wi-Fi, your system can also Broadband use a USB mobile broadband connection to access the internet. (You must turn on your mobile broadband device on your personal computer before connecting it to the system.) This screen allows you to set up what is your typical area for your USB mobile broadband connection.
Page 446 MyLincoln Touch™ Help Press the Settings icon > Help, then select from the following: Help Where Am I? View your vehicle’s current location, if your vehicle is equipped with navigation. If your vehicle is not equipped with navigation, nothing displays. System Information Touchscreen system serial number.
Page 447: Climate Features
MyLincoln Touch™ To access Help using the voice commands, press the voice button, then, after the tone, say “Help”. The system provides allowable voice commands for the current mode. CLIMATE Press the lower right corner on the touchscreen to access your climate control features.
Page 448 MyLincoln Touch™ • Touch + or – to adjust the temperature. • To adjust fan speed, touch + or – next to the fan icon. • Touch Auto to engage automatic rear climate operation. The system determines fan speed and airflow direction to maintain the set temperature.
Page 449 MyLincoln Touch™ K. Manual controls: Select any of the following airflow distribution modes: • Floor and Defrost: Distributes air through the windshield defroster vents, demister vents, floor vents and rear seat floor vents, and provides outside air to reduce window fogging. •...
Page 450 MyLincoln Touch™ There are additional climate control commands but in order to access them, you have to say “Climate” first, then when the system is ready to listen, you may say any of the following commands: Additional climate control voice commands “Automatic”...
Page 451: Navigation System
MyLincoln Touch™ NAVIGATION SYSTEM (IF EQUIPPED) Note: The navigation SD card must be in the SD card slot to operate the navigation system. If you need a replacement SD card, see your authorized dealer. Note: The SD card slot is spring-loaded. To remove the SD card, just push the card in and release it.
Page 452 MyLincoln Touch™ 3. Choose from up to three different types of routes, and then select Start Route. • Fastest Route: Uses the fastest moving roads possible. • Shortest Route: Uses the shortest distance possible. • Eco Route: Uses the most fuel-efficient route. You can cancel the route or have the system demo the route for you.
Page 453 MyLincoln Touch™ Subcategories Personal Care Services Automobile Dealership Government Office Public Transit Education To expand these listings, press the + in front of the point of interest listing. When programming a point of interest destination, the system allows you to sort the resulting lists alphabetically, by distance or by cityseekr listings (if available).
Page 454 MyLincoln Touch™ Hotel Coffeehouse Food & Drink Nightlife Attraction This icon appears when your selection exists in multiple categories within the system. When you are viewing more information for hotels, cityseekr also tells you if the hotel has certain services and facilities using icons. Hotel services and facilities Restaurant 24 Hr Room Service...
Page 455 MyLincoln Touch™ Setting Your Navigation Preferences Select settings for the system to take into account when planning your route. Press the Settings icon > Settings > Navigation. Map Preferences Breadcrumbs displays your vehicle’s previously traveled route with white dots. Turn this feature ON or OFF. Turn List Format allows you to choose to have the system display your turn list Top to Bottom or Bottom to Top.
Page 456 MyLincoln Touch™ Traffic Preferences Avoid Traffic Problems allows you to choose how you want the system to handle traffic problems along your route. • Automatic: Have the system reroute you to avoid traffic incidents that develop and impact the current route. The system does not provide a traffic alert notification.
Page 457 MyLincoln Touch™ 3D landmarks appear as clear, visible objects that are typically recognizable and have a certain tourist value. The 3D landmarks appear in 3D map mode only. Coverage varies, and improves with updated map releases. Change the appearance of the map display by repeatedly pressing the arrow button in the upper left corner of the screen.
Page 458 MyLincoln Touch™ Auto Zoom Press the green bar to access map mode, then select the + or - zoom button to bring up the zoom level and Auto buttons on the touchscreen. When you press Auto, Auto Zoom turns on and Auto displays in the bottom left corner of the screen in the map scale.
Page 459 MyLincoln Touch™ Destination symbol indicates the ending point of a planned route. Next maneuver point indicates the location of the next turn on the planned route. No GPS symbol indicates that insufficient GPS satellite signals are available for accurate map positioning. This icon may display under normal operation in an area with poor GPS access.
Page 460 Annual navigation map updates are available for purchase through your dealership, by calling 1-800-NAVMAPS (in Mexico, call 01–800–557–5539) or going to www.navigation.com/ford. You need to specify the make and model of your vehicle to determine if there is an update available.
Page 461 MyLincoln Touch™ Navigation system voice commands “Destination play nametags” “Voice guidance off” “Destination POI” “Voice guidance on” “Destination POI category” “Where am I?” “Destination previous destination” “Zoom in” “Destination street address” “Zoom out” “Detour” “Help” This command is only available when a navigation route is active. If you have said the command, “Destination”, you may say any of the above commands or commands in the following Destination chart.
Page 462 MyLincoln Touch™ “NAVIGATION” “Destination” “Zoom city” “Zoom country” “Zoom in minimum” “Zoom out maximum” “Zoom province” “Zoom state” “Zoom street” “Zoom to <distance>” “Help” If you have said, “Destination”, you may say any of the commands in the Destination chart. One-shot Destination Street Address When you say either “Navigation destination street address”...
Page 463: Appendices
SYNC® End User License Agreement (EULA) • You have acquired a device (“DEVICE”) that includes software licensed by Ford Motor Company and its affiliates (“FORD MOTOR COMPANY”) from an affiliate of Microsoft Corporation (“MS”). Those installed software products of MS origin, as well as associated media, printed materials, and “online”...
Page 464 Neither FORD MOTOR COMPANY nor its suppliers shall be liable for any damages arising out of errors in the speech recognition process.
Page 465 • Consent to Use of Data: You agree that MS, Microsoft Corporation, FORD MOTOR COMPANY, third party software and systems suppliers, their affiliates and/or their designated agent may collect and use technical information gathered in any manner as part of product support services related to the SOFTWARE or related services.
Page 466 DEVICE. UPGRADES AND RECOVERY MEDIA: If the SOFTWARE is provided by FORD MOTOR COMPANY separate from the DEVICE on media such as a ROM chip, CD ROM disk(s) or via web download or other means, and is labeled “For Upgrade Purposes Only” or For Recovery Purposes...
Page 467 For additional information, see http://www.microsoft.com/exporting/. TRADEMARKS: This EULA does not grant you any rights in connection with any trademarks or service marks of FORD MOTOR COMPANY, MS, Microsoft Corporation, third party software or service providers, their affiliates or suppliers.
Page 468 End user notice Microsoft® Windows® Mobile for Automotive Important Safety Information This system Ford SYNC™ contains software that is licensed to Manufacturer FORD MOTOR COMPANY by an affiliate of Microsoft Corporation pursuant to a license agreement. Any removal, reproduction, reverse engineering or other unauthorized use of the software from this system in violation of the license agreement is strictly prohibited and may subject you to legal action.
Page 469 Appendices Keep User’s Guide in Vehicle When kept in the vehicle, the User’s Guide will be a ready reference for you and other users unfamiliar with the Windows Automotive-based system. Please make certain that before using the system for the first time, all persons have access to the User’s Guide and read its instructions and safety information carefully.
Page 470 Appendices Navigation Features Any navigation features included in the system are intended to provide turn by turn instructions to get you to a desired destination. Please make certain all persons using this system carefully read and follow instructions and safety information fully. Distraction Hazard Any navigation features may require manual (non-verbal) setup.
Page 471 Appendices TeleNav Software End User License Agreement Please read these terms and conditions carefully before you use the Telenav Software. Your use of the Telenav Software indicates that you accept these terms and conditions. If you do not accept these terms and conditions, do not break the seal of the package, launch, or otherwise use the Telenav Software.
Page 472 Appendices You agree to indemnify and hold Telenav harmless against all claims resulting from any dangerous or otherwise inappropriate use of the Telenav Software in any moving vehicle, including as a result of your failure to comply with the directions above. 2.
Page 473 Appendices 4. Disclaimers To the fullest extent permissible pursuant to applicable law, in no event will Telenav, its licensors and suppliers, or agents or employees of any of the foregoing, be liable for any decision made or action taken by you or anyone else in reliance on the information provided by the Telenav Software.
Page 474 Appendices NOTWITHSTANDING ANY DAMAGES THAT YOU MIGHT INCUR FOR ANY REASON WHATSOEVER (INCLUDING, WITHOUT LIMITATION, ALL DAMAGES REFERENCED HEREIN AND ALL DIRECT OR GENERAL DAMAGES IN CONTRACT, TORT (INCLUDING NEGLIGENCE) OR OTHERWISE), THE ENTIRE LIABILITY OF TELENAV AND OF ALL OF TELENAV’S SUPPLIERS SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU FOR THE TELENAV SOFTWARE.
Page 475 Appendices 8. Miscellaneous 8.1 This Agreement constitutes the entire agreement between Telenav and you with respect to the subject matter hereof. 8.2 Except for the limited licenses expressly granted in this Agreement, Telenav retains all right, title and interest in and to the Telenav Software, including without limitation all related intellectual property rights.
Page 476 Appendices 9. Other Vendors Terms and Conditions The Telenav Software utilizes map and other data licensed to Telenav by third party vendors for the benefit of you and other end users. This Agreement includes end-user terms applicable to these companies (included at the end of this Agreement), and thus your use of the Telenav Software is also subject to such terms.
Page 477 Appendices License Limitations on Transfer: Your limited license does not allow transfer or resale of the Data, except on the condition that you may transfer the Data and all accompanying materials on a permanent basis if: (a) you retain no copies of the Data; (b) the recipient agrees to the terms of this End-User License Agreement;...
Page 478 Appendices Disclaimer of Liability: HERE AND ITS LICENSORS (INCLUDING THEIR LICENSORS AND SUPPLIERS) SHALL NOT BE LIABLE TO YOU IN RESPECT OF ANY CLAIM, DEMAND OR ACTION, IRRESPECTIVE OF THE NATURE OF THE CAUSE OF THE CLAIM, DEMAND OR ACTION ALLEGING ANY LOSS, INJURY OR DAMAGES, DIRECT OR INDIRECT, WHICH MAY RESULT FROM THE USE OR POSSESSION OF THIS DATA;...
Page 479 Appendices Governing Law: The above terms and conditions shall be governed by the laws of the State of Illinois (for Data for the Americas and/or the Asia Pacific region) or The Netherlands (for Data for Europe, the Middle East and Africa), without giving effect to (i) its conflict of laws provisions, or (ii) the United Nations Convention for Contracts for the International Sale of Goods, which is explicitly excluded.
Page 480 Appendices Gracenote® Copyright CD and music — related data from Gracenote, Inc., copyright 2000–2007 Gracenote. Gracenote Software, copyright 2000–2007 Gracenote. This product and service may practice one or more of the following U.S. Patents #5,987,525; #6,061,680; #6,154,773, #6,161,132, #6,230,192, #6,230,207, #6,240,459, #6,330,593, and other patents issued or pending.
Page 481 Appendices respectively, reserve all rights in Gracenote Data, the Gracenote Software, and the Gracenote Servers and Gracenote Content, including all ownership rights. Under no circumstances will either Gracenote become liable for any payment to you for any information that you provide, including any copyrighted material or music file information.
Page 482 Appendices Vehicle with SYNC only FCC ID: KMHSG1G1 IC: 1422A-SG1G1 Vehicle with SYNC and MyFord Touch or MyLincoln Touch FCC ID: KMHSYNCG2 IC: 1422A-SYNCG2 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 483: Scheduled Maintenance
Parts installed at your dealership carry a nationwide 24-month or unlimited miles (kilometers) parts and labor limited warranty. If you do not use Ford authorized parts they may not meet our specifications and depending on the part, it could affect emissions compliance.
Page 484 Ford Motor Company has recommended maintenance intervals for various parts and component systems based upon engineering testing. Ford Motor Company relies upon this testing to determine the most appropriate mileage for replacement of oils and fluids to protect your vehicle at the lowest overall cost to you and recommends against maintenance schedules that deviate from the scheduled maintenance information.
Page 485 Scheduled Maintenance Ford strongly recommends the use of only genuine Ford, Motorcraft or Ford-authorized remanufactured replacement parts because they are engineered for your vehicle. Additives and Chemicals Ford Motor Company recommended additives and chemicals are listed in the owner manual and in the Ford Workshop Manual. Additional chemicals or additives not approved by Ford Motor Company are not recommended as part of normal maintenance.
Page 486 In order to keep your vehicle running right, it is important to have the systems on your vehicle checked regularly. This can help identify potential issues and prevent major problems. Ford Motor Company recommends the following multi-point inspection be performed at every scheduled maintenance interval to help make sure your vehicle keeps running great.
Page 487 Scheduled Maintenance 2014 MKT (mkt) Owners Guide gf, 2nd Printing, December 2013 USA (fus)
Page 488: Normal Scheduled Maintenance And Log
Scheduled Maintenance NORMAL SCHEDULED MAINTENANCE AND LOG Intelligent Oil-Life Monitor® Your vehicle is equipped with an Intelligent Oil-Life Monitor that determines when the engine oil needs to be changed based on how your vehicle is used. By using several important factors in its calculations, the monitor helps reduce the cost of owning your vehicle and reduce environmental waste at the same time.
Page 489 Scheduled Maintenance Normal scheduled maintenance At every oil change Change engine oil and filter. interval as indicated by Rotate tires, inspect tire wear and measure the information display tread depth. Perform multi-point inspection (recommended). Inspect automatic transmission fluid level (if equipped with dipstick). Consult dealer for requirements.
Page 490 Scheduled Maintenance Other maintenance items Every 20000 miles Replace cabin air filter (if equipped). (32000 km) Every 30000 miles Replace climate-controlled (heated and (48000 km) cooled) seat filter (if equipped). Replace engine air filter. At 100000 miles Change engine coolant. (160000 km) Every 100000 miles Replace spark plugs.
Page 491 Scheduled Maintenance Maintenance Schedule Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS...
Page 492 Scheduled Maintenance EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE...
Page 493 Scheduled Maintenance EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE...
Page 494 Scheduled Maintenance SPECIAL OPERATING CONDITIONS If you operate your vehicle primarily in any of the following conditions, you need to perform additional maintenance as indicated. If you occasionally operate your vehicle under any of these conditions, it is not necessary to perform the additional maintenance. For specific recommendations, see your dealership service advisor or technician.
Page 495 Scheduled Maintenance Extensive idling or low-speed driving for long distances as in heavy commercial use (such as delivery, taxi, patrol car or livery) Every 30000 miles Change automatic transmission fluid (except (48000 km) Focus). Every 60000 miles Replace spark plugs. (96000 km) Operating in dusty or sandy conditions such as unpaved or dusty roads...
Page 496 Scheduled Maintenance Special Operating Condition Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#:...
Page 497 Scheduled Maintenance EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE...
Page 498 Normal vehicle axle maintenance: Rear axles and power take-off (PTO) units with synthetic fluid and light-duty trucks equipped with Ford-design axles are lubricated for life; do not check or change fluid unless a leak is suspected, service is required or the assembly has been submerged in water.
Page 499 Scheduled Maintenance Edge/MKX AWD only: Vehicles operating off-road in sand during high ambient temperatures must replace the AWD PTU (All-wheel drive Power Transfer Unit) lube every 20000 miles (32000 kilometers). Engine air filter & cabin air filter replacement: Engine air filter and cabin air filter life is dependent on exposure to dusty and dirty conditions.
Page 500: Index
Index 911 Assist™ ......429 Automatic transmission driving an automatic overdrive .........190 fluid, adding ....304–305 fluid, checking ....304–305 ABS (see Brakes) .....203 fluid, refill capacities ....364 Accessing and using your fluid, specification ....364 USB port ........408 Selectshift (SST) ....191 Accessing your calendar ..429 Auxiliary Input Jack ....404 Accessory delay ......109 Auxiliary powerpoint ....169...
Page 501 Index CD ..........378 Customer Assistance ....268 Ford Extended Service CD player ......376, 406 Plan ..........373 CD voice commands ....407 Getting roadside assistance ...268 Cell phone use ......16 Getting the service you Changing a tire ......353 need .........274 Child safety restraints ..31, 33 Ordering additional owner’s...
Page 502 Index Emergency brake fuel pump shut-off ....270 (see Parking brake) ....203 octane rating ....183, 362 quality ........182 Emission control system ..187 running out of fuel ....183 End user license agreement ..462 safety information relating to automotive fuels .....181 Engine ........362 cleaning ........323 Fuses ........282–283 coolant ........299...
Page 503 Index Inspection/maintenance (I/M) Locks testing ........189 autolock ........80 childproof ........38 Instrument panel doors ..........78 cleaning ........326 Lubricant specifications ...364 cluster ........115 Lug nuts ........361 Intelligent Access Key ....67 Making and receiving calls ..416 Jack ..........353 MAP DVD - Loading and positioning .......353 Unloading ........416 storage ........353...
Page 504 Index Radio ..........378 Pairing other phones ....416 AM/FM ........395 Pairing your phone ....415 Single CD ........378 Pairing your phone for the Radio reception ......376 first time ........415 Radio voice commands .....400 Parental MyKey programming ...73 Rear heated/cooled seats ..150 Rear seat controls Park Assist ........209 (if equipped) ......379 Parking brake ......203...
Page 505 Index extension assembly ....45 Setting a destination by for adults ......41, 43 voice ...........450 for children .......25 Settings ........434 inflatable safety belt ....49 Setting the clock ....378, 434 Occupant Classification Sensor ........57 Side air curtain ......62 safety belt maintenance ...51 Side-curtain airbags system ..62 seat belt maintenance ....51 warning light and chime ..45–46...
Page 506 Index Transaxle fluid, refill capacities ....364 lubricant specifications ..364 Temperature control (see Climate control) ..137, 446 Transmission brake-shift interlock (BSI) ..193 Text messaging ......418 fluid, checking and adding Third-row power fold seat ..162 (automatic) .....304–305 Tilt steering wheel ......91 Turn signal ........104 Tires ......332–333, 353 alignment ........346 care ..........332...

Lincoln MKT 2014 Owner's Manual

Table of Contents

Table of Contents

Table of Contents

Table of Contents

Introduction

Child Safety

Safety Belts

Personal Safety System

Supplementary Restraints System

Keys and Remote Control

Mykey

Locks

Security

Steering Wheel

Pedals

Wipers and Washers

Lighting

Windows and Mirrors

Instrument Cluster

Information Displays Controls

Climate Control

Seats

Universal Garage Door Opener (if Equipped)

Auxiliary Power Points

Storage Compartments

Starting and Stopping the Engine

Fuel and Refueling

Transmission

All-Wheel Drive (if Equipped)

Brakes

Traction Control

Stability Control

Parking Aids

Cruise Control

Driving Aids

Load Carrying

Towing

Driving Hints

Roadside Emergencies

Customer Assistance

Fuses

Maintenance

Vehicle Care

Wheels and Tires

Capacities and Specifications

Accessories

Ford Extended Service Plan

Audio System

Mylincoln Touch

Appendices

Scheduled Maintenance

Index

Quick Links

Related Manuals for Lincoln MKT 2014

Summary of Contents for Lincoln MKT 2014
