Operator's Manual
Read these instructions carefully and make sure
you understand them before using the 750.
Manual del operador
Lea cuidadosamente estas instrucciones y asegúrese
de que las comprende bien antes de usar el 750.
Manuel d'utilisation
Veuillez lire attentivement ces instructions et assurez-vous de
bien les comprendre avant d'utiliser la machine modèle 750.
750
Advertisement
Table of Contents
Related Manuals for Husqvarna 750
Summary of Contents for Husqvarna 750
- Page 1 750. Manual del operador Lea cuidadosamente estas instrucciones y asegúrese de que las comprende bien antes de usar el 750. Manuel d’utilisation Veuillez lire attentivement ces instructions et assurez-vous de bien les comprendre avant d’utiliser la machine modèle 750.
-
Page 2: Table Of Contents
Unpacking ..........techniques. Discard or recycle the packing material per your Transporting ..........regional laws. In your container will be the 750 saw, blade Sound Data ..........shaft wrench, spark plug wrench, an owner’s manual, an en- gine owner’s manual, a part list, a warranty card, a joint protec- ntroduction, personal safety ...... -
Page 3: I Ntroduction, Personal Safety
INTRODUCTION The 750 is designed as a medium duty commercial, industrial, and paving Ultra Early Entry con- crete saw. The patented Soff-Cut Ultra Early Entry dry cutting system controls random cracking of concrete through the early timing of the saw cutting usually within one to two hours after finishing process is com- pleted. -
Page 4: Registration Of The Product
SERIAL No: __________________ ENGINE MODEL: _____________ ENGINE TYPE: ______________ ENGINE CODE: ________________ The 750 model and serial number as well as the engine model number, engine type and code are critical in order to obtain the correct service parts. SAFETY DEFINITIONS... -
Page 5: Safety Warnings
• Do not operate the saw in areas of combustible material or fumes. Sparks may occur from the saw that could cause a • Use only Husqvarna Excel Series blades or blades marked fire or explosion. with a maximum operating speed greater than 3800 rpm. -
Page 6: Excel Series Blades
EXCEL SERIES BLADES The Excel Series of diamond blades have been designed specifically for the Soff-Cut Ultra Early Entry dry cutting system of green concrete. These specialty blades are designed to increase speed and life while cutting a wide range of aggregates. Choose the correct specification of diamond blade for your area as follows: Purple Excel Series 1000 XL8-1000... -
Page 7: What Is What
WHAT IS WHAT Model number and serial number What is what? Oil fill & dipstick Air cleaner C. Fuel tank D. Choke lever Fuel shut off lever Recoil starter G. Oil drain hose H. Blade shaft lock Fuel cap Engine on/off switch Hour meter/Tachometer Transmission oil fill cap M. -
Page 8: Operating Instructions
Front guide wheel guide wheel on the cut line to insure straight cuts. Make small Experience is very important when running the 750 saw. A adjustments by applying side pressure on the handle to keep skilled worker is highly recommended. Always do an inspec- the saw straight. -
Page 9: Fuel And Fuel Safety Warnings
Please read the enclosed Robin Operator’s Manual for com- when filling. plete oil information. - Remove the 750 from the truck or trailer and refuel it on the ground. If this is not possible, then refuel the equipment with a portable container, rather than from a gasoline dispenser nozzle. -
Page 10: Engine And Transmission Maintenance
ENGINE AND TRANSMISSION MAINTENANCE Engine Oil Air filter The air cleaner assembly (C) is a cyclone type on the engine Checking, Adding and Changing Oil at the front of the saw. The air cleaner element should be Check the engine oil level (B) daily with saw fully lowered and replaced every 50 hours. -
Page 11: Other Maintenance
Inspect all controls for proper function daily. Check all the interlocks for operation especially the red engine on/off WARNING switch for proper operation. Do not modify the saw! Use only Husqvarna Construc- tion Products replacement parts. Use of unauthorized parts may create a danger or damage the engine. Belts Inspect the blade drive belt and transmission belt for cracks or signs of wear. -
Page 12: Sawing Contraction Joints
Husqvarna sawed contraction joints should be a minimum of 1/8th the concrete depth and a minimum of 1”... -
Page 13: Maximizing The Soff-Cut System
Cut is being specified more today than ever, sometimes the ultra early-entry spec is not always followed on the job site. In order for the Soff-Cut system and an experienced Husqvarna contractor to do a satisfactory job, four components must exist to meet the “specification”:... -
Page 14: Troubleshooting
- Use Husqvarna joint protectors at all cut intersections. - Insure that all wheels rolls freely and smoothly. - Clean excess concrete debris from the blade block assembly. -
Page 15: Technical Specifications
TECHNICAL SPECIFICATIONS Weight and Dimensions 750 Weight – dry 240 lbs 109 kg Weight with gasoline and oil full 247 lbs 112 kg Length 48 inch 1219 mm Width 23 inch 584 mm Height 39 inch 991 mm Blade Material cut... -
Page 16: Warranty
HUSQVARNA EQUIPMENT WARRANTY New 750 sold by Husqvarna Construction Products are warranted to be free from manufacturing defects in normal service for a period of six (6) months for labor and up to one (1) year on parts from date of purchase by the original consumer purchaser or date of introduction into rental company fleet. - Page 17 505 41 78-07 Printed In U.S.A. 2009-09...
