Hunter Piccolo Owner's Manual

Ceiling fan

Advertisement

Quick Links

Assembly
Electrical Rating:
Piccolo
Owner's Manual
Installation
Product:
Ceiling Fan
Trademark:
Revolutions
Quantity:
1 Piece
120V ~ 60Hz
Operation
ME003-01 r060414

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Piccolo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hunter Piccolo

  • Page 1 Piccolo Owner’s Manual Assembly Installation Operation • • • Product: Ceiling Fan Trademark: Revolutions Quantity: 1 Piece Electrical Rating: 120V ~ 60Hz ME003-01 r060414...
  • Page 2 - To reduce the risk of fire, electrical shock, or motor damage, use only Hunter Speed Controls. w.4 - To reduce the risk of personal injury, do not bend the blade brackets when installing the blade brackets, balancing the blades, or cleaning the fan.
  • Page 3: Tools And Materials Required

    Unpacking the Fan 1. Unpack your fan and check the contents. Do not discard the box. If warranty replacement or repair is ever necessary, the fan should be returned in its original packaging. Remove all parts and hard- ware. Do not lay the motor housing on its side; the decorative casing may shift. 2.
  • Page 4: Installing The Mounting Bracket

    Assessing the Installation Location CAUTION ,8 Meters from blade tip To reduce the risk of injurty to to nearest wall persons, install fan so that the blade or obstruction 2,1 Meters is at least 2,1 m above the floor. from bottom edge of blade to the floor Installing the Mounting Bracket...
  • Page 5: Mounting The Fan

    Mounting the Fan WARNING: The fan must be hung with a least 2,3 m of clearance from floor to blades. 1. Remove the three pre-installed screws from the motor hanging bracket. Keep the screws. 2. Slide the narrow end of the motor hanging bracket into the corresponding cut-out in the mounting bracket allowing the fan to hang (Fig.
  • Page 6: Installing The Blades

    Assembling the Motor Housing 1. Raise the fan so that the motor bracket meets the mounting bracket. Align the three screw holes. 2. Install the screws you kept from “Mounting the Fan.” (Fig. 8) 3. Lift the Motor Housing over the fan motor. Align the screw holes in the motor housing with the screw holes in the mounting bracket (Fig.
  • Page 7: Operating The Fan

    Assembling the Light Kit 1. Remove the thumbscrews from the light kit. 2. Install a 60 watt max bulb into the socket. 3. Raise the globe to the light kit. 4. Reinstall the thumbscrews. Tighten screws securely (Fig. 11A). 5. Assemble decorative fob and extension chains from hardware bag to the fan pull chains by inserting end of chain into chain coupling.
  • Page 8: Troubleshooting

    Troubleshooting FAN WILL NOT START: 1. Check all fuses or circuit breakers. Replace if missing. 2. Turn off electrical power and check all wire connections to fan and in the wall control. FAN IS NOISY 1. Use of standard light rheostat or continuously variable fan speed wall control will always cause har- monic distortions or a huming noise.
