Page 2
- All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 3
We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit.
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box.
1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Progress Check: Your fan should look like this. Note: Fan style may vary.
Follow these steps to get your fan wired quickly and safely. Follow the route below that best matches your wall switch setup. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualifi ed electrician. Hunter Pro Tip: You are going to need these:...
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Installing the Blades Put the blade washers found in the hardware bag onto the blade screws found in the hardware bag.
1886 Assembling the LIght Kit Assembling the LIght Kit 2 of 3 Light Kit Screw Feed the wire plugs through the center Partially install two light kit hole of the upper switch housing, then assembly screws, found in the wrap keyhole slots around the screws hardware bag, halfway into and twist counterclockwise.
Page 10
1886 Preparing the Wall Control Turning off the power KEY PRESS FUNCTION Ensure the power is OFF at the outlet box and wall switch location before proceeding LIGHT FUNCTIONS with installation. Light On/Off Light Dimming Control Long Light High Press Installing the battery Long Battery...
Page 11
Follow the onscreen prompts to set up your fan. (fan style may vary). Hunter Pro Tip: Need to install the app later? When ready, turn the wall switch off and then on.
