Designed with True User-Friendliness in Mind
Quick Startup
(PN-L703A/603A)
The whiteboard function on the PN-L703A/603A can start up
quickly at a press of the power button, so that meetings get
underway without delay.
Note: When booting the LCD monitor from power off status (power turned off using
the power button on the monitor or remote control)
Touch-Operated Onscreen Display
Pressing the Touch Menu button
displays an onscreen menu that lets
you easily switch input sources,
change volume level, or turn the
touchscreen function on and off
without using a remote controller.
Power button
Touch Menu button
Minimize Glare and Fingerprints
Protecting the screen is an anti-glare lm that helps work to reduce
glare and re ections and minimize ngerprint soiling on the glass.
MFP Connectivity
Documents and images scanned from a color-scan-capable Sharp
MFP can be imported directly to the Sharp Pen Software for
display on the AQUOS BOARD system. For added convenience,
image data shown onscreen—including notations—can be saved
to a PC or sent directly to an MFP for printout.
Scan
document
Write or draw
with Sharp MFP
directly on image
Import
to display
Touch Display Link enables the following interactive functions on the
AQUOS BOARD display and mobile devices connected via wireless LAN:
• sharing of onscreen content
• transfer of files
• interactive onscreen writing and drawing
• remote control of the AQUOS BOARD display from mobile devices
Up to 50 mobile devices can be connected simultaneously.
Files can be exchanged between mobile devices even if they are
not connected to the AQUOS BOARD display.
Users can capture onscreen images and save them on their mobile
devices to make personally annotated memos (personal memo).
Touch Display Link also connects two AQUOS BOARD interactive
display systems on the same network (intranet, VPN, etc.) to enable
larger-scale interactive communications.
Print
Save
data to PC
Front-Mounted Speakers
Two speakers (10W + 10W) are mounted low on the front of the
LCD monitor to deliver clearer sound.
A Wealth of Input/Output Terminals
The PN-L703A/703B and PN-L603A/603B come
standard-equipped with a wealth of input/output terminals—on the
side and the bottom of the monitor—to enable easy connection
with a wide variety of equipment. This array of terminals includes
three HDMI ports, two D-sub ports, two DisplayPort™ terminals
(one input, one output), and two touchscreen-supporting USB
ports. One of the USB ports can be assigned to a regularly
connected PC, such as a host PC used to operate the LCD
monitor. The other USB port facilitates temporary connection to
another PC, such as one used by a meeting participant. This allows
easy PC connection without the need to switch the USB cable.
(Side)
USB (for PC)
PC analog input
RGB (D-sub)
PC/AV input
(HDMI)
Audio input
(Bottom)
USB (for pen adaptor)
Audio output
LAN port Option terminal
External speakers
DisplayPort
USB
output
(for PC)
* For connecting keyboard, mouse, or USB ash drive
Feature Comparison
PN-L703A/603A
Quick Startup
1
Pen Software
(pre-installed)
with function buttons
(1 pen / adaptor set)
Touch
Pen
w/o function buttons
3
Touch Display Link
(
pre-installed /
bundled; user installed
Standard feature
▲ Feature available under conditions indicated in parentheses.
1 Supports 11 languages (English, German, Spanish, French, Italian, Dutch, Portuguese,
Russian, simpli ed Chinese, traditional Chinese, Japanese)
2 Please check with your local authorized Sharp dealer/representative on availability.
3 For details, see the section on Touch Display Link.
USB*
LAN port
PN-L703A/603A
PC/AV input (HDMI)
PC analog
DisplayPort
Audio
input (D-sub)
input
input
N-L703B/603B
(bundled; user installed)
2
(optionally available)
(1 pen)
)
(bundled; user installed)
