Connect with computer and turn on power
1.
Connect with computer by USB cable.
Via computer
cable
[Notice] You can connect from side.
2.
Connect with computer by Video cable.
①
②
3.
Turn on display main power.
Start up "White board"
1.
Double click "Pen Software" icon
2.
Then "White board" start up.
Brief Guide
PN-L703B/L603B
④
⑤
⑥
①D-Sub input
②Display Port input
③HDMI input
③
④D-Sub input
⑤HDMI input
⑥HDMI input
on desktop. *twice quickly.
ver1.1
4.
Press POWER button
5.
Turn on Computer power.
*You need to install "Touch panel setting tool"
and "SHARP Pen software" to computer.
6.
Change and select input I/F of this computer.
You can select by touching "TOUCH MENU" button.
7.
Touch input I/F of this computer.
in left bottom.
POWER button / TOUCH MENU
1
Advertisement
Related Manuals for Sharp aquos PN-L703B
Summary of Contents for Sharp aquos PN-L703B
- Page 1 POWER button / TOUCH MENU Turn on Computer power. *You need to install “Touch panel setting tool” and “SHARP Pen software” to computer. Connect with computer by Video cable. Change and select input I/F of this computer. You can select by touching “TOUCH MENU” button.
- Page 2 Draw character on “White board” You can draw character by touching display Set on the setting menu like following image. (White board area) with pen. Bundled pen ・Please select the kind of pen (Standard pen /Brush pen/Marker/Figure pen), Color (Black/Red/Blue/Green/Yellow/White), ●Change size and color of pen Size(１～５).
- Page 3 Add new sheet ●Change sheet by dragging display ・Touch “Add” icon on “Tool bar” in bottom , then you can add new sheet. ・Touch “View” icon on “Square menu” and drag display to right or left (with keeping touch), then you can change sheet. ・Touch ”Page”...
- Page 4 Open saved data Touch “Open file” icon on “Square menu”. Read the file. ・Select the saved location and touch “OK”. Select the file and touch “OK”. Select file opening method. ・New ： Create a new sheet ・Open as a new file ：...
