3. Insert a Smart Card

Orient the compatible smart card with its face up so that the gold end of the card is nearest to the
smart card reader slot. Then, insert the gold end of the card into the smart card reader slot. The smart
card indicator light briefly illuminates when the smart card is fully seated and detected by the reader.
At this time, the card is in the secure PIN mode
Figure 4 Inserting a Smart Card
NOTE: The keyboard's smart card LED turns solid blue when the smart card is in secure PIN mode.
While the LED is solid blue, the keyboard will stop working until the secure transaction is complete.
This protects the smart card PIN code from being intercepted.

Identifying Compatible Smart Cards

Refer to the HP Web site for the lists of compatible Synchronous and Asynchronous smart cards for
this product at
4 HP USB Smartcard CCID Keyboard
http://www.hp.com and then search for Smartcard CCID keyboard.
