INSTALLATION AND OPERATION MANUAL
Free-Standing
EPA Certified
Wood-Burning Stoves
Save These Instructions
For Future Reference
P/N 775,216M, Rev. E, 02/2010
A French manual is available upon request. Order P/N 775,216CF.
Report # 050-S-02b-2
Ce manuel d'installation est disponible en francais, simplement en faire la demande. Numéro de la
pièce 775,216CF.
These appliances must be properly installed and operated in order to prevent the
possibility of a house fire. Please read this entire installation and operation
manual before installing and using your wood stove. Failure to follow
these instructions could result in property damage, bodily injury or
Portland
US
•
Hot! Do not touch! The glass and surfaces of this appliance will
be hot during operation and will retain heat for a while after
shutting off the appliance. Severe burns may result.
•
Carefully supervise children in the same room as appliance.
Model Legacy™ S260 T-Top
even death. Contact your local building or fire officials to obtain
a permit and information on any installation requirements
and inspection requirements in your area.
WARNINGS
Wood Stoves
Advertisement
Table of Contents
Related Manuals for Lennox Legacy S260 T-Top
Summary of Contents for Lennox Legacy S260 T-Top
- Page 1 INSTALLATION AND OPERATION MANUAL Free-Standing EPA Certified Wood-Burning Stoves Save These Instructions For Future Reference P/N 775,216M, Rev. E, 02/2010 Wood Stoves Model Legacy™ S260 T-Top A French manual is available upon request. Order P/N 775,216CF. Ce manuel d’installation est disponible en francais, simplement en faire la demande. Numéro de la pièce 775,216CF.
-
Page 2: Table Of Contents
Brick Installation ................12 Operating Hints ................13 Thank you for selecting a Lennox Hearth Products wood stove as the answer to your home supplemental heating needs. Starting and Maintaining a Fire ............ 13 Blower Operation (optional kit) ........... -
Page 3: Important Safety Information
13. Inspect your chimney at least once a month during the burn- IMPORTANT SAFETY AND WARNIING ing season to check for soot and creosote accumulations. INFORMATION Any accumulations over 1/4” thick should be removed by a professional chimney sweep. Do not attempt to burn out heavy creosote accumulations with a hot fire. -
Page 4: Testing Information
W.C. As per NFPA-211 standard (see paragraph below), the installer TESTING INFORMATION must take into account all variables within the installation and install the appliance in such a manner that satisfies the draft requirements of the appliance. See Chimney Guidelines below to assist you in selecting the This manual describes the installation and operation of the Legacy™... -
Page 5: Negative Pressure Warning
Do not burn treated wood, coal, the stove or fireplace insert is not the source of negative pressure. Lennox garbage, cardboard, solvents, or colored paper. Burning treated wood,... -
Page 6: Clearances To Combustibles
WARNING: In the event that you remove the blower for any Canada CAN/CSA Z0 MH), or, when such a standard is not reason, make sure a cover plate (available from Lennox Hearth applicable, the Standard for Mobile Home Installations, ANSI Products) is installed before using the heater. -
Page 7: Installation Clearances Diagrams
INSTALLATION CLEARANCES - REFER TO DIAGRAMS A, B AND C PIPE INSTALLATION B (1) D (1) E† F (1,) G () H () ” Single Wall Residential 18” 1-1/” ” 1” 8” 11” 1” USA-7-1/” (0mm) (9mm) (0mm) (0mm) 00mm (79mm) (mm) CAN-100mm... -
Page 8: Leg And Heatshield Installation
If there is hidden damage, notify your 5. Do not over tighten the heatshield mounting bolts as it may bend the freight company or Lennox Hearth Products dealer immediately. heatshield. CAUTION: Wear gloves during installation in case of sharp edges on the stove. -
Page 9: Stove Installation
14. All horizontal runs of pipe should be as short as possible and are STOVE INSTALLATION required by NFPA No. 211 to have an upward pitch or rise in the same direction the smoke travels of no less than 1/4” to the linear foot. The connector pipe must meet minimum clearances in any direction If not previously installed, install floor protection and move the to walls or other combustible materials. -
Page 10: Pedestal Installation
5. If required, install the Outside Air Kit (cat. no. 71112) as per the PEDESTAL INSTALLATION following instructions. To locate the hole in the hearth for outside air mark and cut a 4” (102 mm) hole in the hearth. The hole’s center (For ash drawer pedestal see instructions included with pedestal) should be 3”... -
Page 11: Post Installation Checks
FOR YOUR OWN PROTECTION AND INSURANCE PURPOSES, POST INSTALLATION CHECKS HAVE YOUR CHIMNEY AND CONNECTOR PIPE INSTALLATION INSPECTED BY YOUR LOCAL BUILDING CODE AUTHORITY OR 1. Check that all chimney pipe joints are securely fastened. FIRE MARSHAL BEFORE STARTING A FIRE IN YOUR STOVE. NOTIFY YOUR INSURANCE COMPANY. -
Page 12: Brick Installation
WARNING: IF THE BRICKS ARE NOT INSTALLED EXACTLY AS BRICK INSTALLATION SHOWN, THEY COULD FALL OUT OF PLACE DURING RE- FUELING OR BURNING OF THE STOVE, CAUSING SERIOUS CAUTION: Wear gloves during brick installation in case of INJURY. sharp edges inside the stove. Note: Installation of the baffle boards and insulating blanket is easier Legacy™... -
Page 13: Operating Hints
OPERATING HINTS STARTING AND MAINTAINING A FIRE Be sure to clean the Nickel or Gold Plated door with a house- 1. Burn only dry, well-seasoned wood for maximum heat output. In some hold type glass cleaner and a very soft cloth to remove any states it is illegal to burn wet wood or anything other than clean, dry wood products. -
Page 14: Blower Operation (Optional Kit)
In the event that you remove the blower for any reason, turned on. Likewise, when the stove cools off, the blower is turned off make sure a cover plate (available from Lennox Hearth to prevent circulating cool air. Depending on the size and intensity of the Products) is installed before using the heater. -
Page 15: Operating Techniques And Hints
OPERATING TECHNIqUES AND HINTS ACHIEVING CLEAN, LONG BURNS Recent developments in wood burning technology have made wood burning To achieve long burn times, after having thoroughly preheated the a cleaner and more convenient way to heat your home. Overall efficiency stove, let the stove top cool down to 7 to 00 degrees (on Elites, in a wood burning appliance is a combination of combustion efficiency locate thermometer on the face of the insert just above the door). -
Page 16: Maintenance
DOOR HINGES: If door hinges need lubricating, use an anti-seize compound SEE MAINTENANCE FOR GLASS CLEANING TIPS (never use oil) available from your Lennox Hearth Products dealer. The operator plays an important part in keeping the glass clean and free DOOR LATCH: If your door latch fails to latch tightly and the gasket is of build-ups. -
Page 17: Troubleshooting
TROUBLESHOOTING Problem Solution POOR DRAFT: Extend chimney in length or have the chimney realigned to the proper size flue. Oversized chimneys normally have poor drafts. Remember, the stoves’ draft depend solely on the natural draft of the chimney (See Drafting section on Page 4). -
Page 18: Do's And Don'ts
DO’S AND DON’TS DO NOT: Install or operate this stove before reading this manual. DO NOT: Close the draft beyond the point at which the flames are completely extinguished. DO NOT: Open the stove door without fully opening the draft first. DO NOT: Burn driftwood or wood that has been in salt water. -
Page 19: Replacement Parts Lists
REPLACEMENT PARTS - MODEL S0 FSB BLOWER PARTS Item # Cat. No Description Contact an Authorized Lennox Hearth Products dealer to obtain H80 FSB700 Blower Only Assembly w/ blower wiring harness any of these parts. Never use substitute materials. Use of... - Page 20 REPLACEMENT PARTS - MODEL S0 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
- Page 21 REPLACEMENT PARTS - MODEL S0 Door Parts Blower Parts NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
- Page 22 REPLACEMENT PARTS - MODEL S0 Leg and Leg Parts NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
- Page 23 REPLACEMENT PARTS - MODEL S0 Ash Drawer Pedestal and Pedestal NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
-
Page 24: Accessories
ACCESSORIES - MODEL S0 PEDESTALS (REqUIRED) Cat. No. Model Description 7111 WL-PED Pedestal (ref. form #506033-16) 7111 WL-PED-ASHD Ash Drawer Pedestal (ref. form #506033-15) OR LEGS (REqUIRED) (ref. form #506033-14) 70000 LEG-OLY-B Olympic Sculptured Blacks ( per pkg.) 70001 LEG-OLY-G Olympic Sculptured Golds ( per pkg.) 7000 LEG-OLY-N... -
Page 25: Safety / Listing Labels
SAFETY / LISTING LABEL - ENGLISH... -
Page 26: Safety / Listing Labels
SAFETY / LISTING LABEL - FRENCH... - Page 27 NOTES...
-
Page 28: Product Reference Information
The Date On Which Your Appliance Was Installed __________________________ Your Dealer's Name _________________________________________________ Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
