Nextar NCU160 Instruction Manual

Cd/mp3/wma/usb/sd/mmc receiver with bluetooth a2dp handsfree
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Attention!! This car radio unit is compatible with the latest profile Bluetooth. It is inevitably possible
that certain mobile phones are not compatible concerning the communications as well as the
identification numbers. Check if your mobile phone is compatible with Bluetooth version 1.2 or 2.0.
VOL
SEL
PUSH
T K
ST
The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks
is under license. Other trademarks and trade names
are those of their respective owners.
CD/MP3/WMA/USB/SD/MMC RECEIVER WITH
BLUETOOTH A2DP HANDSFREE
PHONE
TRK
MUTE
INTR
RDM RPT
LO/DX
PAU
INT
RPT
LUD
1
2
3
CD/MP3
NCU160
USB/SD/MMC/WMA
FLAT
POP
ROCK
CLSC
LOUD
RDM
4
5
6
RESET
MIC
AMS
BND
MP3 INPUT
DIS
MUTE/PAIRING
MOD
NCU160

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NCU160 and is the answer not in the manual?

Questions and answers

Related Manuals for Nextar NCU160

Summary of Contents for Nextar NCU160

  • Page 1 Attention!! This car radio unit is compatible with the latest profile Bluetooth. It is inevitably possible that certain mobile phones are not compatible concerning the communications as well as the identification numbers. Check if your mobile phone is compatible with Bluetooth version 1.2 or 2.0. CD/MP3 NCU160 USB/SD/MMC/WMA RESET FLAT...

  • Page 2: Table Of Contents

    Contents Notes on Installation..............2 Before You Install..............2 Remove the Old Unit from the Dashbord.......2 Installation................3 Wiring Connections..............4 Care of Discs................4 Location of Controls...............5 Operating Instructions............6-8 Precautions................9 Instruction to play MP3/WMA Songs........9 Pairing the Unit with Mobile Phone via Bluetooth Wireless Technology..........10 Receive Call.................10 Handsfree Operation............10 Simple Troubleshooting Guide..........11...

  • Page 3: Notes On Installation

    Notes on Installation Disconnect negative battery terminal before starting installation. Consult the vehicle's owner's manual for proper instruction. The unit is designed for a 12Volt DC negative ground operation system only. Before Installing the unit, make sure your vehicle is a 12Volt DC negative ground system. Be sure to connect the leads according to the diagram.

  • Page 4: Installation

    Installation DIN FRONT DASH MOUNT Removing the unit Installation the unit 1. Frame 1. Dashboard. 2. Insert fingers into the groove in the front of 2. Holder frame and pull out to remove the frame, After inserting (When re-attaching the frame, point the side the holder into with a groove downwards and attach it.) the dashboard,...

  • Page 5: Wiring Connections

    Wiring Connections Make sure that you have a good chassis ground. Good ground connections will eliminate most electrical noise problems. A good chassis ground requires a tight connection to the vehicle's metal chassis. The area around the ground connection should be clean, bare metal without rust, paint, plastic, dust, or dirt for a good electrical connection.

  • Page 6: Location Of Controls

    Location of Controls (2) (15) (21) (1) (3) (20)(18) CD/MP3 NCU160 USB/SD/MMC/WMA RESET FLAT CLSC ROCK PHONE LOUD MUTE INTR RDM RPT MP3 INPUT MUTE/PAIRING PUSH LO/DX (14) (11) (12) (13) (17) (10) (16) (7) (6) (19) O F F...

  • Page 7: Operating Instructions

    Operating Instructions 1. POWER ON/OFF CONTROL Press the button to turn the power “ON” or “OFF”. Note : The unit can be turn on by pressing any keys on the panel (except panel release button & disc eject button). It will help the user who cannot find the power button in dark. 2.
  • Page 8 10. MODE SELECTION Press this button to select Radio (TUNER), CD/MP3/WMA (S-CDP), USB (USB-DRIV) or SD/MMC (MEM- CARD) mode. 11. STEREO/MONO CONTROL Press this button to select “FM STEREO” or “MONO” reception. 12. TALK BUTTON Press this button for Bluetooth wireless technology operation (please refer to the “Handsfree Operation” for details).

  • Page 9: Usb Port

    NOTE: When the preset button to be memorized is kept pressed for more than 2 seconds, the receiving station frequency will be stored in the button pressed. After this, the memorized station can be recalled by pressing the button once. On CD / MP3 / WMA / USB-DRIV / MEM-CARD Mode Preset 1- press this button to pause the disc / file played.

  • Page 10: Precautions

    Precautions This unit will only play the following discs. Type of disc Recorded material Label on the disc Size of disc Audio only CD, MP3, WMA 12 cm Instruction to play MP3/WMA Songs IMPORTANT NOTES The MP3/WMA file recording media acceptable to this unit are CD-R, CD-RW, USB flash memory, SD or MMC memory card.

  • Page 11: Bluetooth Wireless Technology

    Pairing the Unit with Mobile Phone via Bluetooth Wireless Technology Attention!! This car radio unit is compatible with the latest profile Bluetooth. It is inevitably possible that certain mobile telephones are not compatible concerning the communications as well as the identification numbers.

  • Page 12: Simple Troubleshooting Guide

    Simple Troubleshooting Guide PROBLEM CAUSE/SOLUTION No Power Check wiring connections. Check and make sure the fuse is not blown. Replace with the proper rating / size fuse. Some errors occur in the LCD or Press the RESET Button (21). nothing functions when buttons are pressed.
