Summary of Contents for Nextar ncd90
-
Page 2: Table Of Contents
Contents Precautions...2 Notes on Installation...3 Before You Install...4 Installation (DIN Front Mount)...5 Installation (Vehicle's Brackets)...6 Wiring Connections...7 Front Panel Conotrols...8 Basic Operation...9 Radio Operation...10 CD Operation...10-11 MP3 (CD)...11-12 AUX IN, RCA, & Subwoofer Control...13 Maintenance...13 Infra Red Remote Control...14 Simple Troubleshooting Guide...15 Specifications...15... -
Page 3: Precautions
Precautions • This unit will only play the following discs. Type of disc CD, MP3, WMA Care of Discs • Handle the disc by its edge to keep the disc clean. Do not touch the disc’s surface. • Do not use a CD with paste or ink residue on it. -
Page 4: Notes On Installation
Notes on Installation • Disconnect negative battery terminal before starting installation. Consult the vehicle’s owner’s manual for proper instruction. • The unit is designed for a 12Volt DC negative ground operation system only. Before installing the unit, make sure your vehicle is a 12Volt DC negative ground system. -
Page 5: Before You Install
Before You Install Automotive audio equipment installations can be troublesome at times, even to the most experienced of installation technicians. If you are not confident working with electrical wiring, removing and reinstalling interior panels, carpeting, dashboards or other components of your vehicle, please call your dealer in order to have the unit professionally installed. -
Page 6: Installation (Din Front Mount)
Installation Disconnect negative battery terminal from battery before starting installation. Consult the vehicle’s owner’s manual for proper instructions. NOTE: Mark the polarity of the existing speaker wires before disconnecting battery. NOTE: Remove the two transport screws from the top of the unit before installing. -
Page 7: Installation (Vehicle's Brackets)
Installation NOTE: Outer trim frame, hook, and mounting sleeve are not used for this installation. This is only intended as a general guide; contact the vehicle's manufacturer for specific instructions. This method of installation uses the screw holes at the sides of the unit and the holes of the existing vehicle mounting bracket. -
Page 8: Wiring Connections
Wiring Connections Make sure that you have a good chassis ground. Good ground connections will eliminate most electrical noise problems. A good chassis ground requires a tight connec- tion to the vehicle's metal chassis. The area around the ground connection should be clean, bare metal without rust, paint, plastic, dust, or dirt for a good electrical connection. -
Page 9: Front Panel Conotrols
Front Panel Controls... -
Page 10: Basic Operation
Basic Operation Tuning the unit On / Off Press any Button to turn the unit on, the display will show a message WELCOME to indicate it is ready for use. Press the POWER button for 2 seconds to turn the unit off. Mode Selection Press the BAND Button to select Ra- dio Mode. -
Page 11: Radio Operation
Radio Operation Choose Radio Band Press the BND•ID3 Button anytime to access the radio function. The unit comes with five bands- three FM Bands (FM1, FM2, and FM3) and two AM Bands (AM1, and AM2) selects. Each of the five bands can store up to six preset stations, for a total of 30 preset memory stations. -
Page 12: Mp3 (Cd)
CD Operation Insert/Eject CD Insert a disc into CD slot with label side up. The disc will be automati- cally loaded into the unit, even when it is off or at radio mode. The word “LOAD” will blink on the display and the CD will play automatically. - Page 13 Selecting Tracks On the Head Unit, press the SEEK >>| Button to advance CD to the next track. Track numbers will be shown on the display. Press and hold SEEK >>| to fast forward. Press the SEEK |<< Button to go to a previous track.
-
Page 14: Aux In, Rca, & Subwoofer Control
Auxilliary in, RCA out & Subwoofer out Auxiliary Input The Auxiliary Input Jack is on the pan- el of the unit. Insert the AUX IN cable's stereo plug into the AUX IN jack on the panel of the unit. Route the other end of the stereo plug to the headphone jack of any external audio device such as walkman and discman. -
Page 15: Infra Red Remote Control
Infra Red Remote Control This unit comes with a full remote control system. The CR-2025 Lithium battery is an included item with the remote control. In case you have to replace the batteries (1) remove the cover from the back of the remote control. (2) insert a CR-2025 Lithium battery. -
Page 16: Simple Troubleshooting Guide
Simple Troubleshooting Guide PROBLEM No Power Some errors occur in the LCD or nothing functions when buttons are pressed. Unable to receive stations Poor radio reception CD’s cannot be loaded Songs keep skipping File information shows in LCD but will not play. Specifications GENERAL Operating Power...12 Volts DC, Negative Ground...
