Nextar NCS-102 Instruction Manual

WIRING DIAGRAM
ANTENNA JACK
RED
R.
RCA LINE OUT
L.
GREEN
WHITE
+
FRONT
L.
SPEAKER
REAR
L.
SPEAKER
+
BLUE
4 SPEAKERS SYSTEM
NOTE:
Speakers with a load impedance less than 4 ohms could damage this device.
If you have 2 speaker system, make sure use a speaker with 4 ohm load impedance;
If you have 4 speaker system, make sure use a speaker with 8 ohm load impedance to reduce
the distortion during high volume level.
SPECIFICATION
GENERAL
Power Supply Requirements...................DC 12Volts. Negative Ground
Dimensions (SET).................................178(W) X 111(D) X 45.5(H) mm
FM SECTION
Frequency Range........................................................88MHz - 108MHz
AM SECTION
Frequency Range.....................................................530KHz - 1700KHz
3A
RED
FUSE
B+ POWER
GREY
+
FRONT
R.
SPEAKER
REAR
R.
SPEAKER
+
(BLACK) GROUND
WHITE
AM 540 620 750 900 1200 1600 KHz
ON/VOL
CD IN
FM 88 91 94 98 103 108 KHz
TONE
EJECT
CAR STEREO WITH CASSETTE PLAYER
ST
TUNE
BAL
BAND
ST
NCS102
