TV/FM Indoor Antenna

OWNER'S MANUAL — Please read before using this equipment.

Your RadioShack TV/FM Indoor Antenna helps improve

your TV's VHF (channels 2–13) and UHF (channels 14–

69) reception, or your home stereo system's FM recep-

tion.

Its features include:

Rotating VHF/FM Dipoles and UHF Reflector — im-

prove reception without moving the antenna console

Twelve-Position Fine-Tune Control — allows precise

tuning to help eliminate ghosting, picture graininess,

and static.

RadioShack and RadioShack.com

are trademarks used

by RadioShack Corporation.

Page 1 15-1825.RI.fm Page 1 Monday, October 2, 2000 10:11 AM TV/FM Indoor Antenna OWNER’S MANUAL — Please read before using this equipment. Your RadioShack TV/FM Indoor Antenna helps improve your TV’s VHF (channels 2–13) and UHF (channels 14– 69) reception, or your home stereo system’s FM recep- tion.
Page 2 15-1825.RI.fm Page 2 Monday, October 2, 2000 10:11 AM INSTALLATION 1. Place the antenna on or near your TV. 2. Connect the supplied coaxial cable to the antenna’s 75-ohm connector, then to the TV’s 75-ohm VHF connector. Antenna’s 300-Ohm VHF Terminals Antenna’s 75-Ohm...
Page 3 15-1825.RI.fm Page 3 Monday, October 2, 2000 10:11 AM OPERATION Extend the telescoping elements to full length and move them to an angle that produces the best reception. Hold the elements at their bases while adjusting. Telescoping Element FINE TUNING...
Page 4 15-1825.RI.fm Page 4 Monday, October 2, 2000 10:11 AM For channels 7–13 and FM radio, shorten the telescop- ing elements slightly. For all VHF channels, adjust the angle of the telescoping elements. Limited Ninety-Day Warranty This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for ninety (90) days from the date of purchase from RadioShack company-owned stores and authorized RadioShack franchisees and dealers.
