- Page 1 23-411.fm Page 1 Friday, August 6, 1999 3:00 PM Cat. No. 23-411 OWNER’S MANUAL Please read before using this equipment. Racing Battery Pack AC/DC Charger for 4.8V/6V/7.2V/9.6V Ni-Cd Battery Packs...
- Page 2 23-411.fm Page 2 Friday, August 6, 1999 3:00 PM FEATURES Your RadioShack Racing Battery Pack AC/DC Charger is perfect for charging WARNING: To reduce the risk of your radio-controlled racing cars’ battery fire or shock hazard, do not ex- packs. It connects to standard AC power pose this product to rain or mois- or your vehicle’s cigarette-lighter socket, ture.
-
Page 3: Important Safety Instructions
23-411.fm Page 3 Friday, August 6, 1999 3:00 PM IMPORTANT SAFETY INSTRUCTIONS 1. SAVE THESE INSTRUCTIONS — This manual contains important safety instructions battery charger Cat. No. 23-411. 2. Before using the battery charger, read all instructions and cautionary markings on the battery charger, the battery, and the product using the battery. -
Page 4: Operation
23-411.fm Page 4 Friday, August 6, 1999 3:00 PM OPERATION This table shows the estimated typical • Do not charge a battery pack that is fast-charging time for battery packs of damaged or leaking. different capacities: • Do not cover the vents on the top and back of the charger while charg- Charging Charging... -
Page 5: Charging Battery Packs
23-411.fm Page 5 Friday, August 6, 1999 3:00 PM CONNECTING TO A CHARGING BATTERY VEHICLE’S CIGARETTE- PACKS LIGHTER SOCKET 1. To charge a 6V battery pack, simply insert it into the compartment on the Plug the DC cord into your vehicle’s cig- charger, then skip to Step 3. - Page 6 23-411.fm Page 6 Friday, August 6, 1999 3:00 PM 5. When charging is complete, the charger and indicator automatically turn off. Disconnect and remove the battery pack from the charger, then unplug the charger’s power cord. ILLUSTRATION of 4.8 V battery pack connection 2.
-
Page 7: Replacing The Fuse
23-411.fm Page 7 Friday, August 6, 1999 3:00 PM REPLACING THE FUSE The charger’s fuse blows if you connect 3. Twist off the fuse holder’s black cap the DC cord’s clamps to the wrong bat- and carefully remove the inner tip, tery terminals. -
Page 8: Care And Maintenance
23-411.fm Page 8 Friday, August 6, 1999 3:00 PM CARE AND MAINTENANCE Your Racing Battery Pack AC/DC Charger for 4.8V/6V/7.2V/9.6V Ni-Cd Battery Packs is an example of superior design and craftsmanship. The following sugges- tions will help you care for your charger so you can enjoy it for years. -
Page 9: Specifications
23-411.fm Page 9 Friday, August 6, 1999 3:00 PM SPECIFICATIONS Charging Current .......... 2.5 Amps for 4.8V, 6V and 9.6V battery 4.5 Amps for 7.2 battery AC Supply Voltage ................AC 120V 60 Hz DC Supply Voltage ..................DC 11–16V Charging Times: (Fully Discharged Battery Pack) Minimum Charging Time ................ - Page 10 23-411.fm Page 10 Friday, August 6, 1999 3:00 PM NOTES...
- Page 11 23-411.fm Page 11 Friday, August 6, 1999 3:00 PM...
- Page 12 23-411.fm Page 12 Friday, August 6, 1999 3:00 PM Limited Ninety-Day Warranty This product is warranted by RadioShack against manufacturing defects in material and workman- ship under normal use for ninety (90) days from the date of purchase from RadioShack company- owned stores and authorized RadioShack franchisees and dealers.
