18
ASSEMBLING AND PREPARING

Mounting on a wall

Attach an optional wall mount bracket at the rear
of the TV carefully and install the wall mount
bracket on a solid wall perpendicular to the
floor. When you attach the TV to other building
materials, please contact qualified personnel.
LG recommends that wall mounting be
performed by a qualified professional installer.
10 cm
Make sure to use screws and wall mount
bracket that meet the VESA standard. Standard
dimensions for the wall mount kits are described
in the following table.
Separate purchase(Wall Mounting Bracket)
Model 32LN54**
32LN565*
32LA61**
VESA (A x B) 200 x 100
Standard M4
screw
Number of 4
screws
Wall mount LSW130B
bracket
Model
47/50/55LN54**
50LA61**
VESA (A x B) 400 x 400
Standard
M6
screw
Number of
4
screws
Wall mount LSW430B
bracket MSW240
Wall mount bracket
LSW130B
LSW230B
LSW430B
MSW240
A
B
37/39/42LN54**
42LA61**
200 x 200
M6
4
LSW230B
MSW240
60LN54**
400 x 400
M6
4
LSW430B
