OWNER'S MANUAL
LED TV *
* LG LED TV applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it
for future reference.
LN54 **
LP36 **
LP63 **
LP86**
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP86 Series and is the answer not in the manual?

Questions and answers

Related Manuals for LG LP86 Series

Summary of Contents for LG LP86 Series

  • Page 1 OWNER’S MANUAL LED TV * * LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. LN54 ** LP36 ** LP63 ** LP86** www.lg.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS 24 REMOTE CONTROL 27 MAINTENANCE 27 Cleaning your TV TABLE OF CONTENTS - Screen, frame, cabinet and stand - Power cord LICENSES 27 TROUBLESHOOTING OPEN SOURCE SOFTWARE NOTICE 28 CAUTION FOR USING EZSIGN INSTALLATION PROCEDURE 28 SPECIFICATIONS ASSEMBLING AND PREPARING 32 IR CODES Unpacking Separate purchase 33 EXTERNAL CONTROL Parts and buttons DEVICE SETUP...

  • Page 3: Licenses

    In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to...

  • Page 4: Installation Procedure

    INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING NOTE Image shown may differ from your TV. Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. The available menus and options may differ from the input source or product model that you are using.
  • Page 5 ASSEMBLING AND PREPARING Owner’s manual Remote control, Stand Body / Stand Base batteries (AAA) (Only LP36**, LN54**, LP63**) (See p.24, 25, 26) (See p.10) Stand base / Stand Base Stand screws Desk-mount screw (Only LP86**) M4 x 14 M4 x 20 (See p.10) (7EA : Only LP36**, LN54**, (1EA: Only LP36**, LP63**) LN54**, LP63**) (8EA : Only LP86**) (2EA : Only 42/47LP86**)
  • Page 6 ASSEMBLING AND PREPARING NOTE Antenna Isolator Installation Guide - Use this to install TV in a place where there is a voltage difference between TV Set and GND of antenna signal. » If there is a voltage difference between TV Set and GND of antenna signal, the antenna contact might be heated and excessive heat might cause an accident.

  • Page 7: Separate Purchase

    ASSEMBLING AND PREPARING Separate purchase Separate purchase items can be changed or modified for quality improvement without any notification. Contact your dealer to buy these items. These devices only work with certain models. LG Audio Device Wireless Dongle LED Clock AN-MR300 Magic Remote AN-WF100 LEC-001...

  • Page 8: Parts And Buttons

    Accesses the main menu, or saves your input and exits the menus. Changes the input source. INPUT Turns the power on or off. NOTE You can set the LG Logo Light or Power Indicator Light to on or off by selecting OPTION in the main menus.(Depending on model)

  • Page 9: Lifting And Moving The Tv

    ASSEMBLING AND PREPARING Lifting and moving the TV When moving or lifting the TV, read the following to y When transporting a large TV, there should be prevent the TV from being scratched or damaged at least 2 people. and for safe transportation regardless of its type y When transporting the TV by hand, hold the TV and size.

  • Page 10: Setting Up The Tv

    ASSEMBLING AND PREPARING Setting up the TV (Only LP86**) *Image shown may differ from your TV. Attaching the stand 4 EA (Only LP36**, LN54**, LP63**) M4 x 14 M4 x 14 Stand Body Front Stand Body Front Stand Base Stand Base M4 x 14 M4 x 14...

  • Page 11: Mounting On A Table

    ASSEMBLING AND PREPARING Mounting on a table CAUTION Lift and tilt the TV into its upright position on a When attaching the stand to the TV set, table. place the screen facing down on a cushioned - Leave a 10 cm (minimum) space from the table or flat surface to protect the screen wall for proper ventilation.
  • Page 12 ASSEMBLING AND PREPARING Securing the TV to a table Adjusting the angle of the TV to suit view (Only 32LN54 ** , 32LP36 ** , 32LP63 ** , 42/47/55LP86 ** ) Fix the TV to a table to prevent from tilting forward, Swivel 15 degrees to the left or right and adjust the damage, and potential injury.
  • Page 13 ASSEMBLING AND PREPARING Using the Kensington security system Securing the TV to a wall (This feature is not available for all models.) (This feature is not available for all models.) The Kensington security system connector is located at the rear of the TV. For more information of installation and using, refer to the manual provided with the Kensington security system or visit http://www.kensington.com.

  • Page 14: Mounting On A Wall

    When you attach the TV to other building materials, please contact qualified personnel. LG recommends that wall mounting be performed CAUTION by a qualified professional installer. Disconnect the power first, and then move or install the TV.

  • Page 15: Tidying Cables

    ASSEMBLING AND PREPARING Tidying cables *image shown may differ from your TV. (Only LP86**) (Only LP36**, LN54**, LP63**) Coaxial Cable Holder Secure the power cord with the protective Cable Holder bracket/bolt. Power Cord Holder Cable Management CAUTION Do not move the TV by holding the Cable Holder and Power Cord Holder, as the Cable holders may break, and injuries and Protective bracket/bolt...

  • Page 16: How To Use Dual Lock

    ASSEMBLING AND PREPARING How to use Dual Lock™ (Only LP63 ** ) Attach the set-top box to the TV by pressing Fix the set-top box to the TV and use it when you want to. the Velcro strips together. After removing the protection paper from the Dual Lock, stick it to the TV and the set-top box as shown.

  • Page 17: Making Connections

    MAKING CONNECTIONS MAKING Antenna connection CONNECTIONS Connect the TV to a wall antenna socket with an RF cable (75 Ω). /DVI IN * image shown may differ from your TV. (RGB) COMPONENT AUDIO IN OPTICAL This section on MAKING CONNECTIONS mainly (COMPONENT/RGB/DVI) AUDIO OUT uses diagrams for the LP36...

  • Page 18: Hdmi Connection

    MAKING CONNECTIONS HDMI connection DVI to HDMI connection /DVI IN Transmits the digital video and audio signals from your (Only LN54**, LP36**, LP63**) PC to the TV. Connect the PC and the TV with the Transmits the digital video signal from an external (RGB) HDMI cable as shown.

  • Page 19: Rgb-Pc Connection

    MAKING CONNECTIONS Component connection RGB-PC connection (Only LP36**, LN54**, LP63**) (Only LN54 ** , LP36 ** ) Transmits the analogue video and audio signals Transmits the video signal from PC to the TV. To from an external device to the TV. Connect the transmit an audio signal, connect an audio cable.

  • Page 20: Speaker Output Setup

    MAKING CONNECTIONS Speaker output setup Method of Volume control port Each Up/ Down Connect the external speaker to the SPEAKER pin is pulled to OUT jack on the TV. 3.3V with CPU GPIO. Cable CPU detects Spec. (Only LN548C, LN549C, LP36**) GND / Up / Down transition from /DVI IN 3.3V to GND...

  • Page 21: Ci Module Connection

    MAKING CONNECTIONS Euro Scart connection CI module connection Transmits the video and audio signals from an View the encrypted (pay) services in digital TV external device to the TV set. Connect the external mode. This feature is not available in all countries. device and the TV set with the euro scart cable as shown.

  • Page 22: Audio Connection

    MAKING CONNECTIONS /DVI IN Audio connection Headphone connection (RGB) COMPONENT AUDIO IN OPTICAL (COMPONENT/RGB/DVI) AUDIO OUT You may use an optional external audio system Transmits the headphone signal from the TV to an external device. Connect the external device instead of the built-in speaker. and the TV with the headphone as shown.

  • Page 23: Network Setup

    MAKING CONNECTIONS Network setup Wired network connection Wireless network connection /DVI IN (Only LP63 **, LP86 ** ) (Only LN549E) This TV can be connected to a Pro:Centric server This TV can be connected to wireless network (RGB) via the LAN port. After making the physical con- COMPONENT AUDIO IN OPTICAL...

  • Page 24: Remote Control

    REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover.
  • Page 25 REMOTE CONTROL (Only LN549E) (POWER) Turns the TV on or off. ꕊ ENERGY SAVING Adjusts the brightness of the screen to reduce energy consumption. ENERGY AV MODE INPUT AV MODE Selects an AV mode. INPUT Changes the input source. SAVING TV/RAD Selects Radio, TV and DTV programme. Number buttons Enters numbers.
  • Page 26 REMOTE CONTROL (Only LP63 **, LP86 ** ) (POWER) Turns the TV on or off. ꕊ ENERGY SAVING Adjusts the brightness of the screen to reduce energy consumption. ENERGY AV MODE INPUT AV MODE Selects an AV mode. INPUT Changes the input source. SAVING TV/RAD Selects Radio, TV and DTV programme. Number buttons Enters numbers.

  • Page 27: Maintenance

    MAINTENANCE / TROUBLESHOOTING MAINTENANCE Cleaning your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges.

  • Page 28: Caution For Using Ezsign 2.0

    CAUTION FOR USING EZSIGN 2.0 / SPECIFICATIONS CAUTION FOR USING EZSIGN 2.0 Only LN549E Do not remove a USB drive while data is being copied. It can corrupt the data and EzSign may not work properly. While loading a USB device or dongle, your TV may function slower than normal. While EzSign contents is running, the movie with internal subtitles is not supported in USB mode.
  • Page 29 SPECIFICATIONS 42LN54 ** 47LN54 ** 32LP36 ** 47LN548C-ZA 42LN548C-ZA MODEL 32LP360H-ZA 42LN549C-ZA 47LN549C-ZA 32LP361H-ZA 42LN549E-ZA 47LN549E-ZA Dimensions With stand (mm) 968 x 629 x 236 1080 x 694 x 264 738 x 497 x 207 (W x H x D) Without stand (mm) 968 x 579 x 79.0 1080 x 642 x 80.5...
  • Page 30 SPECIFICATIONS CI Module Size 100.0 mm x 55.0 mm x 5.0 mm (W x H x D) Operating 0 °C to 40 °C Temperature Environment Operating Humidity Less than 80 % condition Storage Temperature -20 °C to 60 °C Storage Humidity Less than 85 % Satellite Digital TV Digital TV...
  • Page 31 SPECIFICATIONS RGB-PC, HDMI/DVI-PC supported mode HDMI/DVI-DTV supported mode (Only LN54 ** , LP36 ** ) Horizontal Vertical Resolution Frequency (kHz) Frequency (Hz) Horizontal Vertical Resolution Frequency (kHz) Frequency (Hz) 31.469 59.94 720x480 31.5 720x400 31.469 70.08 720x576 31.25 640x480 31.469 59.94 37.5 1280x720 44.96 59.94...

  • Page 32: Ir Codes

    IR CODES IR CODES This feature is not available for all models. Code (Hexa) Function Note Remote control Button (Power On/Off) (POWER) ENERGY SAVING Remote control Button AV MODE Remote control Button INPUT Remote control Button TV/RAD Remote control Button 10-19 Number Key 0-9 Remote control Button LIST Remote control Button...

  • Page 33: External Control Device Setup

    EXTERNAL CONTROL DEVICE SETUP EXTERNAL CONTROL DEVICE SETUP RS-232C setup RS-232C configurations Connect the RS-232C (serial port) input jack to an external con- 7-Wire Configurations trol device (such as a computer or an A/V control system) to (Standard RS-232C cable) control the product’s functions externally. Connect the serial port of the control device to the RS-232C jack on the product back panel.

  • Page 34: Communication Parameters

    EXTERNAL CONTROL DEVICE SETUP Communication parameters y Baud rate: 9600 bps (UART) y Stop bit: 1 bit y Data length: 8 bits y Communication code: ASCII code y Parity : None y Use a crossed (reverse) cable. Command reference list (Depending on model) (Depending on model) DATA DATA...

  • Page 35: Transmission / Receiving Protocol

    EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV.(j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the set ID to choose desired monitor ID number in option menu. Adjustment range is 1 to 99.
  • Page 36 EXTERNAL CONTROL DEVICE SETUP 01. Power (Command: k a) 04. Volume Mute (Command: k e) ► To control Power On/Off of the set. ► To control volume mute on/off. You can also adjust mute using the MUTE button on remote Transmission[k][a][ ][Set ID][ ][Data][Cr] control.
  • Page 37 EXTERNAL CONTROL DEVICE SETUP 09. Tint (Command: k j) 13. Treble (Command: k r) (Except for LP86**) ► To adjust the screen tint. ► To adjust treble. You can also adjust tint in the PICTURE menu. You can also adjust treble in the AUDIO menu. Transmission [k][j][ ][Set ID][ ][Data][Cr] Transmission [k][r][ ][Set ID][ ][Data][Cr] Data Red : 00 to Green : 64...
  • Page 38 EXTERNAL CONTROL DEVICE SETUP . Tune Command (Command: m a) 17. Energy Saving (Command: j q) ► Select channel to following physical number. ► To reduce the power consumption of the TV. You can also adjust Energy Saving in PICTURE menu. Transmission [m][a][ ][Set ID][ ][Data0][ ][Data1][ ][Data2][Cr] Transmission [j][q][ ][Set ID][ ][Data][Cr] Data00 : High channel data...
  • Page 39 EXTERNAL CONTROL DEVICE SETUP 23. Input select (Command: x b) (Main Picture Input) ► To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data Structure External Input Input Number External Input Data Analogue Component HDMI Input Number Data Input1 Input2...
  • Page 40 The model and serial numbers of the TV is located on the back of the TV Record it below should you ever need service. Model Serial...
