Page 1 Sunlight Readable Touch Panel PC HP-5N Series User Manual...
Page 2: Table Of Contents
Introduction …………………………………………………………………………………………………… • Features …………………………………………………………………………………………………...…. • Motherboard Specification ……………………………………...………………………………………….. • System Specification …………...…………………………………………………………………………… • Mounting Installation ………………………………………………………………………………………… • Bios setup ………………………………………………………………………………...……………….…. • Driver Installation …………………………………………………………………..…………………….…. • Contact Information ……………………………………………………………………..……………….…. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 3: Package Contents
• 1 x CD • 4 x screw (M3 x 4) for 2.5” HDD or SSD (If customers order 2.5” HDD or SSD from our side, we don’t offer 4 screws) Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 5: Fcc & Ce Statement
The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 6: Introduction
Kingdy knows your challenge and launches the HP-5N Series, Sunlight Readable Touch Panel PC, to help you create more effic ient manufacturing processes through its 1600 nit high-brightness LED-backlight LCD panel designed to emit more light than normal commercial grade.
Page 7: Features
1024 x 768 dpi (15”) 1280 x 1024 dpi (17”, 19”) 1920 x 1080 dpi (21.5” widescreen) High quality black or silver aluminum front bezel with anodic treatment OSD (On-Screen Display) controller (optional) Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 8: Motherboard Specification
- 1 x Line-in/surround, 1 x Line-out, 1 x Mic-in/Center+Subwoofer Power DC 19V ~ 24V input Watchdog Timer Output System reset, Programmable 1 ~ 255 sec/min Operating temperature: 0°C ~ 60°C Environment Storage temperature: -20°C ~ 85°C Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 9: System Specification
Win XP Pro, Win 7 Pro, Embedded XP, Embedded 7 OSD controller, Waterproof gasket, External DVD-RW driver, RFID sensor, None touch screen, Open frame Optional Items Stainless front bezel, CPU, Memory, Storage devices, WiFi, OS, Riser card Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 10 Win XP Pro, Win 7 Pro, Embedded XP, Embedded 7 OSD controller, Waterproof gasket, External DVD-RW driver, RFID sensor, None touch screen, Open frame Optional Items Stainless front bezel, CPU, Memory, Storage devices, WiFi, OS, Riser card Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 11: Mounting Installation
Panel Mount PC (Back Side) Panel Mount PC (Front Side) Screw Holes for Screw Mounting Installation Align the bottom of panel housing with the bottom edge of the cut out Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 12 Step2: screw the VESA mounting bracket to the front of a wall or the front / back of an object dependingly ······ Step3: slide the VESA mounting plate onto the VESA mounting bracket Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 13: Bios Setup
23. Minute displays minutes from 00 to 59. Second Enables or disables the boot option for legacy mass displays seconds from 00 to 59. storage devices with option ROM. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 14 Enable this field to use the PME signal to wake up the system. Wake system with fixed time Enable or disable system wake on alarm event. When enabled, system will wake on the hr::min::sec specified. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 15 If you are using an operating system other than Windows, this problem may occur. To avoid this problem, enable this field to limit the return value to 3 or less than 3. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 16 EHCI driver. Legacy IDE This option configures the Serial A TA drives Device reset time-out as Legacy IDE storage devices. Selects the USB mass storage device start unit command timeout. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 17 Set this field to Enabled to allow the system to alert you returns of a chassis intrusion event. Watchdog This field is used to enable or disable the Watchdog Timer function. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 18 PC Health Status Configuration This section displays the SIO hardware health monitor. Serial Port Enables or disables the serial port. Change Settings Selects the IO/IRQ setting of the I/O device. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 24 NumLock on wherein the function of the numeric keypad is the number keys. When set to Off, the function of the numeric keypad is the arrow keys. Quiet Boot Enables or disables the quiet boot function. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 25 Save Changes Save the changes done so far to any of the setup options. Discard Changes Discard the changes done so far to any of the setup options. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 26 To restore user default to all the setup options, select then press <Enter>. this field and then press <Enter>. A dialog box will appear. Select Yes to restore user default. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
Page 27: Driver Installation
Driver Installation The HP-5N Series comes with an AutoRun CD-ROM that Step 3 –Install LAN Driver contains all drivers and utilities that can help you to 1. Click on the STEP3-LAN folder and select the OS install the driver automatically.
Page 28: Contact Information
Any questions, please contact your local dealer or contact us via the following means: Add: 10F, No. 2, Jian 8th Rd., Zhonghe Dist., New Taipei City 23511, Taiwan Tel: +886-2-6621-8811 Fax: +886-2-8226-1518 Sales Email: sales@kingdy.com.tw Technical Support Email: tech@kingdy.com.tw Website: www.kingdy.biz Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. HP-5N Series...
