Synth-Programming Examples
Synth Pad
2 3
1 Choose "PRESET D-8". The sawtooth wave is selected.
2 Press the [WAVE] button of the OSC1 section and select the SUPER SAW.
3 Turn the [PW/FEEDBACK] knob of the OSC1 section to the "one o'clock" position.
4 Turn the [CUTOFF] knob in the FILTER section all the way left to (MIN).
The sound becomes inaudible.
5 Press the [TYPE] button in the FILTER section and select HPF.
The sound is audible once again.
6 Let's determine the overall timbre. Raise the [D] slider of the FILTER ENV mid-way up
and raise the [R] slider all the way up.
7
Raise the [DEPTH] slider of the FILTER ENV gradually to determine the overall timbre.
8 Turn the [LEVEL] knob of AMP section all the way right to (MAX).
9 Raise the [A] slider of AMP ENV mid-way up. The initial attack of the sound becomes slower.
10 Raise the [R] slider of the AMP ENV mid-way up. The sound will not die off after you release
your fingers from the keyboard now.
11
Press the [FX ON] button.
12
Turn the [TIME] knob in the EFFECTS section all the way left to (MIN). Turn the [DEPTH]
knob to enhance the resonance.
21
5 4 6 8 11 12
1 7 9 10 12
4
Synth-Programming Examples

Sound Effects

2
Let's create a sound effect like a synth drum.
This sound is created from deliberately
generated sound from the filter.
Choose "PRESET D-8". The sawtooth wave is selected.
1
2
Press the [WAVE] button in the OSC1 section and select NOISE.
3 Turn the [CUTOFF] knob in the FILTER section all the way left to (MIN).
The sound becomes inaudible.
4 Turn the [RESONANCE] knob in the FILTER section all the way right to (MAX).
Raise the [D] and [R] sliders of the FILTER ENV mid-way up.
5
6 Lower the [S] slider of the FILTER ENV all the way down.
7 Raise the [DEPTH] slider of the FILTER ENV gradually upward.
8 Lower the [A] slider of the AMP ENV all the way down.
9 Raise the [S] and [R] sliders of the AMP ENV all the way up.
10
As you turn the [KEY FOLLOW] knob rightward a little, you can change sound's
brightness with your key location.
3 4 10 5
6 7 8 9
1
* Sudden loud sound may occur. In order
NOT to damage your hearing or speakers,
turn the knob slowly.
