Summary of Contents for Harris DAC-5016
- Page 1 5000 and 5100 Series Digital Analog Clocks Installation and Operation Manual Edition D 5000/5100 MAN...
- Page 3 5000/5100Series Digital Analog Clocks Installation and Operation Manual Edition D August 2006...
-
Page 4: Warranty Information
RouterWORKS, Signal Quality Manager, SpyderWeb, SuiteView, TitleMotion, UNIFRAME, Velocity, VelocityHD, VideoCarte, Videotek, and X75 are trademarks of the Harris Corporation, which may be registered in the United States, Canada, and/or other countries. All other trademarks are the property of their respective owners. -
Page 5: Table Of Contents
Contents Preface Manual Information ................iii Purpose .................... iii Audience ..................iii Revision History ................iii Writing Conventions ............... iv Obtaining Documents ..............iv Unpacking/Shipping Information ............v Unpacking a Product .................v Product Servicing ................v Returning a Product ................v Restriction on Hazardous Substances (RoHS) Compliance ....vi Waste from Electrical and Electronic Equipment (WEEE) Compliance vii Safety .................... - Page 6 Contents Specifications ..................12 Electrical ..................12 Primary Drive Inputs ..............12 Secondary Time Bases ..............12 Mechanical ..................13 Chapter 2: ADC-5100 Series Analog Digital Clocks Overview ....................15 Introduction ................... 16 Installation ..................... 18 Wall Mounting ................18 Rack Mounting ................
-
Page 7: Preface
Preface Manual Information Purpose This manual details the features, installation, operation, maintenance, and specifications for 5000/5100 Series Digital Analog Clocks. Audience This manual is written for engineers, technicians, and operators responsible for installation, setup, maintenance, and/or operation of 5000/5100 Series Digital Analog Clocks. Revision History Table P-1. -
Page 8: Writing Conventions
Obtaining Documents Product support documents can be viewed or downloaded from our Web site at www.broadcast.harris.com/leitch (go to Support> Documentation). Alternatively, contact your customer service representative to request a document. 5000/5100 Series Digital Analog Clocks Installation and Operation Manual... -
Page 9: Unpacking/Shipping Information
Preface Unpacking/Shipping Information Unpacking a Product This product was carefully inspected, tested, and calibrated before shipment to ensure years of stable and trouble-free service. 1. Check equipment for any visible damage that may have occurred during transit. 2. Confirm that you have received all items listed on the packing list. 3. -
Page 10: Restriction On Hazardous Substances (Rohs) Compliance
According to this EU Directive, all products sold in the European Union will be fully RoHS-compliant and “lead-free.” (See our Web site, www.broadcast.harris.com/leitch, for more information on dates and deadlines for compliance.) Spare parts supplied for the repair and upgrade of equipment sold before July 1, 2006 are exempt from the legislation. -
Page 11: Waste From Electrical And Electronic Equipment (Weee) Compliance
EU will affix labels indicating that such products must be properly recycled. (See our Web site, www.broadcast.harris.com/leitch, for more information on dates and deadlines for compliance.) Contact your local sales representative for information on returning these products for recycling. Equipment that complies with the EU directive will be marked with a WEEE-compliant emblem, as shown in Figure P-2. -
Page 12: Safety
Preface Safety Carefully review all safety precautions to avoid injury and prevent damage to this product or any products connected to it. If this product is rack-mountable, it should be mounted in an appropriate rack using the rack-mounting positions and rear support guides provided. It is recommended that each frame be connected to a separate electrical circuit for protection against circuit overloading. -
Page 13: Overview
Chapter 1 DAC-5000 Series Digital Analog Clocks Overview This chapter provides installation and operation information about the DAC-5000 Series digital analog clocks. It includes the following topics: • “Introduction” on page 2 • “Installation” on page 3 • “Control Modes” on page 8 •... -
Page 14: Introduction
Line Frequency Reference uses a 50/60 Hz power line. Selection of either 50 or 60 Hz is made by soldering a jumper on the 5000DL Drive Logic module. The following models are available: • DAC-5016 16 inch illuminated, wall mounting. Rack mounting kit optional. • DAC-5012 12 inch illuminated, wall mounting. -
Page 15: Installation
The DAC-5008, DAC-5012 and DAC-5016 Digital Analog Clocks are designed for wall mounting. Rack mounting kits are optional. The rear panels of both the DAC-5012 and DAC-5016 clocks are provided with four rubber feet and four keyholes while the DAC-5008 has only three keyholes. - Page 16 Chapter 1: DAC-5000 Series Digital Analog Clocks Table 1-1 provides information about clock wall mounting specifications Table 1-1. Clock Wall Mounting Specifications Overall Mounting Keyhole Clock Dimensions Centers DAC-5016 17.45×17.45 in. 16.0×15.5 in. (4 keyholes) DAC-5012 13.95×13.95 in. 12.0×10.5 in. (4 keyholes) DAC-5008 10.45×10.45 in.
-
Page 17: Rack Mounting
Chapter 1: DAC-5000 Series Digital Analog Clocks Rack Mounting The DAC-5008, DAC-5012 and DAC-5016 clocks can be rack mounted with the optional rack mounting kit. The kit is installed by removing the back panel side screws, placing the rack mount in position, and reinstalling the screws. -
Page 18: Rear Panel
“Speaker-Type” Connectors (red and black) Connector (plug) 115/230 VAC 10%250/60Hz 25VA Max OPERA TION MODE DAC-5008 DAC-5012 Multifunctional Pushbuttons DAC-5016 Full Instructions in Manual Push-Buttons: CW, CCW, MANUAL LINE VOLTAGE MANUAL SET Clock Modes 115 VAC (factory set) 230 VAC... - Page 19 Chapter 1: DAC-5000 Series Digital Analog Clocks Below this recessed area are the multifunction clock setting buttons and the six DIP switches (SW1 to SW6), all of which must be set prior to installation. LINE VOLTAGE 115 VAC Run on Secondary 230 VAC Use Offset Secondary Ref-Line...
-
Page 20: Control Modes
Chapter 1: DAC-5000 Series Digital Analog Clocks Control Modes Table 1-4 lists the Clock Control mode DIP switch options. Table 1-4. Clock Control Mode DIP switch options Switch Options Dip Switch Open Closed Timecode Impulse SMPTE Internal Line Normal Use offset Normal Run on secondary SW6 (Secondary) -
Page 21: General Operation
Chapter 1: DAC-5000 Series Digital Analog Clocks General Operation Clock Control Modes Primary Reference Mode The Primary Reference Mode provides two options, the Timecode and the Impulse Clock modes. Selection of either mode is done by switch SW1. Timecode Mode No setting of time is required when the timecode mode is selected. -
Page 22: Clock Setting Controls
Chapter 1: DAC-5000 Series Digital Analog Clocks Impulse Clock Mode The DAC-5000 Series clocks will emulate a standard impulse clock. Like any impulse clock, it must be manually set to the correct time and will stop if the impulses from the master clock also stop. The unit will check the polarity of the pulses so that the positive pulses from the red input connector on the rear panel will move the second hand to an even number of the clock face (i.e. - Page 23 Chapter 1: DAC-5000 Series Digital Analog Clocks • This button moves the selected hand counter-clockwise one unit. When the time is set, press the MANUAL SET button (a fourth time) and release it at the exact time that the clock is to be set.
-
Page 24: Specifications
Chapter 1: DAC-5000 Series Digital Analog Clocks Specifications Specifications and designs are subject to change without notice. Electrical Table 1-5. Electrical Item Specification Electrical voltage 115/230 VAC ±20% Frequency 50 or 60 Hz, selectable Power 25 VA max. Primary Drive Inputs Table 1-6. -
Page 25: Mechanical
Chapter 1: DAC-5000 Series Digital Analog Clocks Mechanical Table 1-8. Mechanical Specifications Clock Item Specification DAC-5016 Style Wall-mount Face diameter 16 in. (406 mm) Overall dimensions 17.45×17.45×2.8 in. (443×443×71 mm) Weight 9.1 lbs (4.1 kg) DAC-5012 Style Wall-mount Face diameter 11.75 in. - Page 26 Chapter 1: DAC-5000 Series Digital Analog Clocks 5000/5100 Series Digital Analog Clocks Installation and Operation Manual...
-
Page 27: Overview
Chapter 2 ADC-5100 Series Analog Digital Clocks Overview This chapter provides installation and operation information about the ADC-5100 Series digital analog clocks. It includes the following topics: • “Introduction” on page 16 • “Installation” on page 18 • “Control Modes” on page 23 •... -
Page 28: Introduction
Chapter 2: ADC-5100 Series Analog Digital Clocks Introduction The ADC-5100 Series Analog Digital Clocks are a group of quiet, digitally controlled, self-setting analog face clocks. These may operate either stand-alone via power line frequency or internal crystal, or with a SMPTE or EBU serial timecode input. - Page 29 Chapter 2: ADC-5100 Series Analog Digital Clocks If timecode operation is not required, the ADC clock may be set to use the secondary timebase permanently, and the error LED will be extinguished. The following models are available: • ADC-5116 16 inch, wall mounting. Rack mounting and light kit optional.
-
Page 30: Installation
Chapter 2: ADC-5100 Series Analog Digital Clocks Installation Wall Mounting Figure 2-4. Typical Wall Mounting The ADC-5108, ADC-5112, and ADC-5116 Analog Digital Clocks are designed for wall mounting. Rack mounting kits are optional. The rear panels of both the ADC-5112 and ADC-5116 clocks are provided with four rubber feet and four keyholes, while the ADC-5108 has only three keyholes. - Page 31 Chapter 2: ADC-5100 Series Analog Digital Clocks Table 2-9 provides information about clock wall mounting specifications Table 2-9. Clock Wall Mounting Specifications Overall Mounting Keyhole Clock Dimensions Centers ADC-5116 17.5×17.5 in. 16.0×15.5 in. (4 keyholes) ADC-5112 14.0×14.0 in. 12.0×10.5 in. (4 keyholes) ADC-5108 10.5×10.5 in.
-
Page 32: Rack Mounting
Chapter 2: ADC-5100 Series Analog Digital Clocks Rack Mounting The ADC-5116, ADC-5112 and ADC-5108 clocks can be rack mounted with the optional rack mounting kit. The kit is installed by removing the back panel side screws, placing the rack mount in position, and reinstalling the screws. -
Page 33: Rear Panel
Chapter 2: ADC-5100 Series Analog Digital Clocks Rear Panel Spring Loaded “Speaker-Type” Connectors (red and black) Connector (plug) OPERA TION MODE SLAVE MASTER ADC-5108 Clock Modes ADC-5108-L Multifunctional Pushbuttons (factory set) Full Instructions in Manual ADC-5112 Push-Buttons: ADC-5112-L MANUAL CW, CCW, ADC-5116 MANUAL SET ADC-5116-L... - Page 34 Chapter 2: ADC-5100 Series Analog Digital Clocks Below this recessed area are the multifunction clock setting buttons and the six DIP switches (SW1 to SW6), all of which must be set prior to installation. OPERATION MODE SLAVE Run on Secondary MASTER Use Offset Secondary Ref-Line...
-
Page 35: Control Modes
Chapter 2: ADC-5100 Series Analog Digital Clocks Control Modes Selection of the clock control modes is achieved with the rear panel DIP switches. Table 2-12 lists the Clock Control mode DIP switch options. Table 2-12. Clock Control Mode DIP switch options Switch Options Dip Switch Open... -
Page 36: General Operation
Chapter 2: ADC-5100 Series Analog Digital Clocks General Operation Clock Control Modes Primary Reference (timecode) Mode No setting of time is required when input timecode is provided to the ADC Series clock. Once valid timecode is detected, either SMPTE or EBU, the clock will begin to self-set. - Page 37 Chapter 2: ADC-5100 Series Analog Digital Clocks Secondary Reference Mode The ADC-5100 Series clocks will run as standard wall clocks when no input timecode is provided. Rear panel DIP switch SW4 selects the timebase to be used, either the clock’s internal crystal, or the power line frequency (50/60Hz).
-
Page 38: Clock Setting
Chapter 2: ADC-5100 Series Analog Digital Clocks Local offsets (hand position offsets) are still in effect while using the auxiliary offset. The hand positioning local offsets are totally transparent to the input timecode’s user bit offset. If input timecode is removed while is selected, the clock USE OFFSET will retain the time with the offset added, not the original time. - Page 39 Chapter 2: ADC-5100 Series Analog Digital Clocks When first powered up, the clock will start from 12:00:00. Or, if the external timecode is present, the clock will automatically reset to the correct time. This may take up to 15 minutes. The battery is enabled when power is first applied.
- Page 40 Chapter 2: ADC-5100 Series Analog Digital Clocks • Pressed together, these buttons move MANUAL SET second hand position in counter-clockwise direction for precise tracking during normal operation (non-Manual Set Mode). Repositioning the Hands To reposition the clock hands, follow these steps: 1.
- Page 41 Chapter 2: ADC-5100 Series Analog Digital Clocks This method assumes that the local time reference is 12:00:00. The hands are manually set to the required offset time (according to Table 2-13 on page 29) and the microprocessor is then reset. This tells the microprocessor that the hands are at the 12:00 position, whereas in fact they are set to the offset time.
- Page 42 Chapter 2: ADC-5100 Series Analog Digital Clocks Table 2-13. Table 3.1 Local Offset Programming (Continued) Offset Desired (hrs) Move Hands To Offset Desired (hrs) Move Hands To 8:00:00 -3 1/2 8:30:00 9:00:00 -2 1/2 9:30:00 10:00:00 -1 1/2 10:30:00 11:00:00 -1/2 11:30:00 Note...
- Page 43 Chapter 2: ADC-5100 Series Analog Digital Clocks buttons be held for 50 seconds. When adjustments MANUAL SET are complete and the second hand is on the marker, be sure to release the button after the button in order to MANUAL SET avoid accidentally entering the Manual Set Mode.
-
Page 44: Troubleshooting
Chapter 2: ADC-5100 Series Analog Digital Clocks Troubleshooting Hands are Offset Sometimes the hands are offset by any number of hours, minutes, or seconds. This generally occurs when the microprocessor loses track of where the clock hands are positioned. This problem may occur if the rear push buttons have been pressed in the wrong sequence. - Page 45 Chapter 2: ADC-5100 Series Analog Digital Clocks 7. Release the button, and then release the MANUAL SET button. 8. Re-connect timecode. 5000/5100 Series Digital Analog Clocks Installation and Operation Manual...
-
Page 46: Specifications
Chapter 2: ADC-5100 Series Analog Digital Clocks Specifications Specifications and designs are subject to change without notice. Electrical Table 2-14. Electrical Item Specification Electrical voltage 115/230 VAC ±20%, selectable Frequency 50 or 60 Hz, automatic selection Inputs and Outputs Table 2-15. Inputs Item Specification Serial timecode... -
Page 47: Controls
Chapter 2: ADC-5100 Series Analog Digital Clocks Controls Table 2-18. Controls Item Specification Output timecode format SMPTE/EBU Secondary reference Internal or power line Second hand movement Step or continuous sweep Aux. offset Requires one of the following system clock drivers: •... - Page 48 Chapter 2: ADC-5100 Series Analog Digital Clocks 5000/5100 Series Digital Analog Clocks Installation and Operation Manual...
- Page 50 A brand of Harris Corporation Harris and Leitch are registered trademarks of Harris Corporation. Trademarks and tradenames are the property of their respective companies. Broadcast Communications Division 4393 Digital Way | Mason, OH USA 45040 | Tel: 1 (513) 459 3400 www.broadcast.harris.com...
