GE-DS-82 and GE-DS-82-
PoE Managed Switch
Installation Sheet

Package Contents

Thank you for purchasing the Interlogix 8-Port Fast Ethernet + 2-Port Gigabit
TP/SFP Combo Managed PoE Switch.
The following Managed Switch model numbers are covered in this sheet:
•
GE-DS-82
•
GE-DS-82-PoE
Open the box of the Managed Switch and carefully unpack it. The box should
contain the following items:
•
The Managed Switch x1
•
User manual CD x1
•
This Installation Sheet x1
•
RS-232 cable x1
•
Rubber feet x 4
•
Two rack-mounting brackets with attachment screws x1
•
Power Cord x1
If any item is found missing or damaged, please contact your local reseller
for replacement.
© 2010 UTC Fire & Security.
All rights reserved.
P/N 1069669-EN • REV 1.01 •
ISS 19AUG10
1 of 11


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GE-DS-82 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Interlogix GE-DS-82

Summary of Contents for Interlogix GE-DS-82

  • Page 1: Package Contents

    GE-DS-82 and GE-DS-82- PoE Managed Switch Installation Sheet Package Contents Thank you for purchasing the Interlogix 8-Port Fast Ethernet + 2-Port Gigabit TP/SFP Combo Managed PoE Switch. The following Managed Switch model numbers are covered in this sheet: • GE-DS-82 •...

  • Page 2: System Requirements

    System Requirements Your switch is designed to operate with a variety of platforms, operating systems and network cards. Actual performance will depend on a combination of these components. Differences in performance can occur depending on the versions and types of platforms, operating system and network cards used.

  • Page 3: Terminal Setup

    RS-232 console To configure the system, connect a serial cable to a COM port on a PC or notebook computer and to the serial (console) port of the GE-DS-82 Managed Switch. The console port of the Managed Switch is DCE already, so that you can connect the console port directly through PC without the need of Null Modem.
  • Page 4 Logon to the Console Once the terminal has connected to the device, Supply power to the GE-DS- 82 and the GE-DS-82-PoE Managed Switch, the terminal will display that it is running testing procedures. The following message asks for the login username and password. The factory default password for the login screen is: •...
  • Page 5 Figure 3: GE-DS-82 Login screen Note: For security reasons, please change and memorize the new password after this first setup. Passwords must be entered in lowercase letters in the console interface. P/N 1069669-EN • REV 1.01 • ISS 19AUG10 5 of 11...

  • Page 6: Telnet Setup

    Telnet Setup 1. Connect an RJ-45 cable from the PC to a Switch port on the Managed Switch. Figure 4: RJ-45 connection diagram PC / Workstation with IE Managed browser switch IP address: RJ-45 / UTP cable IP address: 192.168.0.X 192.168.0.100 2.
  • Page 7 4. Change the Connect using drop-down menu to TCP/IP (Winsock) then input the Host address. The Managed Switches default IP address is 192.168.0.100 and the default telnet port number is 23, then press the OK button. Figure 6: The Connect to dialog window Log on to the Console...

  • Page 8: Web Browser Setup

    Web Browser Setup Start Web Management The following shows how to start up the Web Management of the GE-DS-82 Managed Switch. Please note that the Managed Switch is configured through an Ethernet connection, make sure the manager PC must be set on the same IP subnet address.
  • Page 9 Figure 8: IP management diagram PC / Workstation with IE Managed browser switch IP address: RJ-45 / UTP cable IP address: 192.168.0.X 192.168.0.100 Login to the managed Switch 1. Enter the IP address http://192.168.0.100 (the factory-default IP address or one you have previously changed in the console) in the Web Browsers Address Field 2.
  • Page 10 3. After entering the username and password, the main screen appears as shown in Figure 10. Figure 10: Main Screen of the GE-DS-82 PoE 4. You can use the Web Management interface to continue the Switch management, please refer to the user manual for more information.

  • Page 11: Resetting The Ip Address

    FAQ resource at our website first to check if it could solve you issue. If you need more support information, please contact your local support team. For contact information, see our Web site: www.interlogix.com. Contents subject to revision without prior notice.
