  • Page 1: Ifs Es2001-4P-4T User Manual

    IFS ES2001-4P-4T User Manual P/N 1072680 • REV A • ISS 09MAY14...
  • Page 2 Copyright © 2014 United Technologies Corporation. Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks or registered trademarks of patents the manufacturers or vendors of the respective products.

  • Page 3: Table Of Contents

    IFS ES2001-4P-4T User Manual TABLE OF CONTENTS IFS ES2001-4P-4T USER MANUAL ................1 1. INTRODUCTION ......................5 1.1 Checklist ...............................5 1.2 Features ..............................5 1.3 Specification ............................5 2. HARDWARE DESCRIPTION ..................7 2.1 Product Description ..........................7 2.2 Front Panel............................7 2.2.1 LED indicators ..........................8 2.3 Rear Panel .............................8...
  • Page 4 IFS ES2001-4P-4T User Manual 5.2 Classification ............................. 19 5.3 Start-up ............................... 20 5.4 Operation ............................20 Power Overloads ..........................20 5.5 Power Disconnection Scenarios ..................... 20 DC Disconnect ............................ 20 AC Disconnect ............................ 20 6.TROUBLESHOOTING....................22 APPENDIX A NETWORKING CONNECTION ............... 23 A.1 DATA OUT PoE Switch RJ-45 Port Pin Assignments (Port 1 to Port-4) ........

  • Page 5: Introduction

    IFS ES2001-4P-4T User Manual 1. Introduction 1.1 Checklist Check the contents of your package for following parts:  ES2001-4P-4T  User's manual CD x1  Power cord x 1 If any of these pieces are missing or damaged, please contact your dealer immediately. If possible, retain the carton including the original packing material, to repack the product in case there is a need to return it to us for repair.
  • Page 6 IFS ES2001-4P-4T User Manual Per port feeding power: 48V DC, 15.4W, 350mA (Maximum) (Pin 1, 2, 3, 6) Power AC 100~240V, 50/60Hz, Power Consumption Max. 65 watts / 221 BTU Dimension (W x D x H) 217 x 135 x 43 mm Weight 1.0 kg...

  • Page 7: Hardware Description

    IFS ES2001-4P-4T User Manual 2. Hardware description This product operates at two different running speeds – 10Mbps or 100Mbps. The switch automatically distinguishes the speed of incoming connection. This section describes the hardware features of ES2001-4P-4T. For easier management and control of the Switch, familiarize yourself with its display indicators, and ports.

  • Page 8: Led Indicators

    IFS ES2001-4P-4T User Manual 2.2.1 LED indicators  System Color Function Green Lights to indicate that the Switch has power.  Per 10/100Mbps port Color Function PoE In-use Green Lights to indicate the port is providing 48VDC in-line power. (1-4 ports)

  • Page 9: Desktop Installation

    IFS ES2001-4P-4T User Manual Cabling Each 10/100Base-TX port uses RJ-45 sockets for connection of unshielded twisted-pair cable (UTP). The IEEE 802.3u Fast Ethernet standard requires Category 5 UTP for 100Mbps 100Base-TX. 10Base-T networks can use Cat.3, 4, or 5 UTP (see table below). Maximum distance is 100meters (328 feet).

  • Page 10: Rack Mounting

    IFS ES2001-4P-4T User Manual Note Connection to the Switch requires UTP Category 5 network cabling with RJ-45 tips. For more information, please see the Cabling Specification in Appendix A. Step 5: Supply power to the Switch. A. Connect one end of the power cable to the Switch.

  • Page 11: Product Application

    IFS ES2001-4P-4T User Manual Figure 2-5 Mounting the Switch in a Rack Step 6: Proceeds with the steps 4 and steps 5 of session 2.5 Desktop Installation to connect the network cabling and supply power to your Switch. 2.7 Product Application 2.7.1 Connecting end node or switch...

  • Page 12: Typical Uses

    IFS ES2001-4P-4T User Manual Figure 2-6 End node or Switch connection Note: Cable distance for Switch: The cable distance between the ES2001-4P-4T and PC should not exceed 100 meter for UTP/STP cable. Make sure the wiring is correct: It Category 3/4/5 cable can be used in 10 Mbps operation. To reliably operate your network at 100Mbps, you must use an Unshielded Twisted-Pair (UTP) Category 5 cable, or better Data Grade cabling.

  • Page 13: Examples Of Power Over Ethernet Powered Device

    IFS ES2001-4P-4T User Manual Figure 2-7 Department / workgroup PoE Switch connection 2.8 Examples of Power over Ethernet Powered Device The below devices are typical examples of PoE powered devices. The power ratings (in watts) are given as a guideline only. Please refer to the instructions of the powered device for accurate information.

  • Page 14: Switch Operation

    IFS ES2001-4P-4T User Manual 3. Switch Operation 3.1 Address Table The Switch is implemented with an address table. This address table is composed of many entries. Each entry is used to store the address information of some node in network, including MAC address, port no, etc. This information comes from the learning process of Ethernet Switch.
  • Page 15 IFS ES2001-4P-4T User Manual Reset). Detecting the modes does this and speeds at the second of both devices are connected and capable of, both 10Base-T and 100Base-TX devices can connect with the port in either Half- or Full-duplex mode.

  • Page 16: Power Over Ethernet Overview

    IFS ES2001-4P-4T User Manual 4. Power OVER Ethernet Overview What is PoE? Based on the global standard IEEE 802.3af, PoE is a technology for wired Ethernet, the most widely installed local area network technology adopted today. PoE allows the electrical power necessary for the operation of each end-device to be carried by data cables rather than by separate power cords.

  • Page 17: When To Install Poe

    IFS ES2001-4P-4T User Manual Power Sourcing Powered Equipment Device (PD) (PSE) DC/DC Converter Spare Pair Figure 1 - Power Supplied over the Spare Pins The data pairs are used. Since Ethernet pairs are transformer coupled at each end, it is possible to apply DC power to the center tap of the isolation transformer without upsetting the data transfer.

  • Page 18: References

    IFS ES2001-4P-4T User Manual • Management asks for IP Surveillance Cameras and business access systems throughout the facility, but they would rather avoid another electrician's payment. References IEEE Std 802.3af-2003 (Amendment to IEEE Std 802.3-2002, including IEEE Std 802.3ae-2002), 2003 Page(s):0_1-121 White Paper on Power over Ethernet (IEEE 802.3af)

  • Page 19: The Poe Provision Process

    IFS ES2001-4P-4T User Manual 5. The PoE Provision Process While adding PoE support to networked devices is relatively painless, it should be realized that power cannot simply be transferred over existing CAT-5 cables. Without proper preparation, doing so may result in damage to devices that are not designed to support provision of power over their network interfaces.

  • Page 20: Start-Up

    IFS ES2001-4P-4T User Manual Classifying a PD according to its power consumption may assist a PoE system in optimizing its power distribution. Such a system typically suffers from lack of power resources, so that efficient power management based on classification results may reduce total system costs.
  • Page 21 IFS ES2001-4P-4T User Manual AC Disconnect detection involves the induction of low AC signal in addition to the 48 VDC operating voltage. The returned AC signal amplitude is monitored by the PSE at the port terminals. During normal operation, the PD's relatively low impedance lowers the returned AC signal while a sudden disconnection of this PD will cause a surge to the full AC signal level and will indicate PD disconnection.

  • Page 22: Troubleshooting

    IFS ES2001-4P-4T User Manual 6.Troubleshooting This chapter contains information to help you solve problems. If the Switch is not functioning properly, make sure the Ethernet Switch was set up according to instructions in this manual. The Link LED is not lit Solution: Check the cable connection and remove duplex mode of the Switch.

  • Page 23: Appendix A Networking Connection

    IFS ES2001-4P-4T User Manual Appendix A Networking Connection A.1 DATA OUT PoE Switch RJ-45 Port Pin Assignments (Port 1 to Port-4) PIN NO RJ-45 SIGNAL ASSIGNMENT • Output Transmit Data + • Power + • Output Transmit Data – • Power + •...

  • Page 24: Cable Pin Assignment

    IFS ES2001-4P-4T User Manual A.3 RJ-45 cable pin assignment There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight cable and crossover cable connection: Straight Cable...

  • Page 25: Contacting Technical Support

    IFS ES2001-4P-4T User Manual Contacting Technical Support Contact technical support if you encounter any difficulties during this installation. Please make sure you have the requested diagnostic or log files ready before you contact us by phone or go to www.interlogix.com/customer-support.
