Page 1: Instruction Manual
Model i707 Instruction Manual Car Charger & FM Transmitter... - Page 2 FM Transmitter V11M11_IM_EN_11072008 INTRODUCTION Thank you for purchasing the i707. Unpack the unit and make sure all the accessories are put aside so they will not be lost. Be Free from Headphones and Share Your Music with Your Friends. ®...
-
Page 3: Getting Started
FM Transmitter V11M11_IM_EN_11072008 GETTING STARTED Location of Controls (Preset 1) button (Frequency up) button 30-pin connector (Preset 2) button (Frequency down) button LCD screen - 2 - www.i-Luv.com... - Page 4 Hole Display board and dock There are 2 pcs tubes included with the i707. The longer one is the extension tube which can be used as needed. One end of the extension is smaller and has pins while the other is wider and has an opening with two holes on either side.
- Page 5 The display board and dock can be adjusted up or down 180 degrees. The connector, which connects the display board and the extension tube, can adjust 35 degrees to the left or right allowing you to adjust the i707 for easy operation while driving. 180° 35°...
- Page 6 V11M11_IM_EN_11072008 OPERATING INSTRUCTIONS Inserting the Dock Adapter The i707 comes with dock adapters for your iPod. There are also dock adapters included with your iPod. Choose the correct adapter and follow the instructions below. 1. Align the hooks in the back of the dock adapter with the holes on the dock above the display board.
- Page 7 FM Transmitter V11M11_IM_EN_11072008 OPERATING INSTRUCTIONS Turning on / off the FM Transmitter This unit is designed to charge your iPod as it plays. When connected to your iPod and plugged into the cigarette lighter outlet in your car, it automatically turns on. When disconnected, it turns off.
- Page 8 FM Transmitter V11M11_IM_EN_11072008 OPERATING INSTRUCTIONS Transmitting Your Favorite Songs to a Nearby FM Radio Connect the FM transmitter to your iPod. Play songs from your iPod. Press one of the preset buttons. Turn on your car radio. Tune your FM radio to a FM frequency stored on the selected preset memory, and listen to your favorite music.
-
Page 9: Troubleshooting Guide
The i707 is not turned on. Turn on i707. Poor radio reception or interference • The i707 is tuned to a frequency that is used by a local radio station. Find a frequency with no interference and reset the memory. -
Page 10: Specifications
FM Transmitter V11M11_IM_EN_11072008 SPECIFICATIONS • Modulation: FM Stereo • Tuning Type: PLL (Phase-Lock Loop) • Frequency Range: 88.1MHz – 107.9MHz (Step: 0.1MHz) • Frequency Response (Audio): 80Hz – 15kHz • Audio Input Level: 800mV • Total Harmonic Distortion: 2.0% • Transmitting Power: ≤... - Page 11 Visit our website at www.i-Luv.com © 2008 www.i-Luv.com iLuv is registered a trademark of jWIN Electronics Corp. iPod is a trademark of Apple Inc. registered in the U.S. and other countries iPod is not included in this package. Features and specifications are subject to change without prior notification.
