- Page 1 FM Transmitter Instruction Manual i705 Please read this manual carefully before operating and save it for future reference. Have a question? Please visit http://www.i-Luv.com...
-
Page 2: User Safety Guide
FM Transmitter V10M10_IM_EN_01312007 USER SAFETY GUIDE YOU CAN HELP TO PROTECT THE ENVIRONMENT! Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal center. Important Safety Warnings FCC regulations state that any change or modification to the equipment, not expressly approved by maker or its authorized parties, could void user’s authority to operate this equipment. - Page 3 FM Transmitter V10M10_IM_EN_01312007 USER SAFETY GUIDE Important Safety Instructions – Continued HEAT - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat. POWER SOURCES - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance.
-
Page 4: Additional Safety Instructions
FM Transmitter V10M10_IM_EN_01312007 USER SAFETY GUIDE Important Safety Instructions – Continued 12. SERVICING - The user should not attempt to service the appliance beyond what is described in the user's operating instructions. All other servicing should be referred to qualified service professional. 13. -
Page 5: Fcc Notice To U.s. Users
FM Transmitter V10M10_IM_EN_01312007 USER SAFETY GUIDE About Electromagnetic Interference (EMI) – Continued The term “EMI” is short for the electromagnetic interference caused by the electromagnetic field generated by electronic devices. In fact, most electrical appliances and devices emit electric and magnetic fields, and most of modern electronic devices are susceptible to electromagnetic interference (EMI) if they are inadequately shielded or designed. -
Page 6: Industry Canada Notice To Canadian Users
FM Transmitter V10M10_IM_EN_01312007 USER SAFETY GUIDE FCC Notice to U.S. Users – Continued This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one or more of the following measures:... -
Page 7: Getting Started
FM Transmitter V10M10_IM_EN_01312007 GETTING STARTED Thank you for purchasing the i705. Unpack the unit and make sure all the accessories are put aside so they will not be lost. ® FM transmitter for your iPod nano sends the DJ packing... -
Page 8: Location Of Controls
FM Transmitter V10M10_IM_EN_01312007 GETTING STARTED Location of Controls 30-pin connector for your iPod nano (2 generation) Right-arrow ( ) button for changing FM frequency and preset MEMU button for the frequency / preset display and setup Left-arrow ( ) button for changing FM frequency and preset USB port for charging and synchronizing... - Page 9 FM Transmitter V10M10_IM_EN_01312007 GETTING STARTED Screen Indications Indication for active preset memory number FM frequency from 88.1MHz to 107.9MHz Turning on/off the FM Transmitter When connected to your iPod, it automatically turns on. When disconnected, it automatically turns off. If there is no audio input signal until 1 minute after connected to your iPod, this unit automatically enters the standby mode.
- Page 10 FM Transmitter V10M10_IM_EN_01312007 OPERATING INSTRUCTIONS Setting up the Preset Memory You can store up to 9 FM frequencies in the preset memory and easily call them up later. Connect the FM transmitter to your iPod. Press the “MENU” button to see the FM frequency on your iPod screen.
- Page 11 FM Transmitter V10M10_IM_EN_01312007 OPERATING INSTRUCTIONS Setting up the Preset Memory – Cont. Select an FM frequency using the left-arrow “ ” or right- arrow “ ” buttons. • Press the “ ” or “ ” button to change the frequency with 0.1MHz step.
- Page 12 FM Transmitter V10M10_IM_EN_01312007 OPERATING INSTRUCTIONS Setting up the Preset Memory – Cont. Press and hold the “MENU” button until one of the preset numbers is activated. Select the preferred preset memory number using the left- arrow “ ” or right-arrow “ ” buttons. - 11 - www.i-Luv.com...
- Page 13 FM Transmitter V10M10_IM_EN_01312007 OPERATING INSTRUCTIONS Setting up the Preset Memory – Cont. Press and hold the “MENU” button to store the frequency into the selected preset number. The indication “M” will be on. Repeat Steps 2 to 7 to preset other frequencies. Changing One Preset to Another Press the “MENU”...
- Page 14 FM Transmitter V10M10_IM_EN_01312007 OPERATING INSTRUCTIONS Changing One Preset to Another – Cont. • If they are currently on, select a preset memory number using the left-arrow “ ” or right-arrow “ ” buttons. • If they are currently off, press the “MENU” button to turn on the preset mode and then, select a preset memory number using the...
- Page 15 FM Transmitter V10M10_IM_EN_01312007 OPERATING INSTRUCTIONS Transmitting Your Favorite Songs to a Nearby FM Radio Connect the FM transmitter to your iPod. Select the preset number using the left-arrow “ ” or right-arrow “ ” buttons. Note: The FM transmitter screen will change to the normal iPod screen if there is no action for 5 seconds with the FM transmitter.
- Page 16 FM Transmitter V10M10_IM_EN_01312007 OPERATING INSTRUCTIONS Transmitting Your Favorite Songs to a Nearby FM Radio – Cont. Play a song on your iPod as usual. Tune your nearby radio to the FM frequency that you want to listen to. If properly set, you will hear the song from your iPod on the radio.
- Page 17 FM Transmitter V10M10_IM_EN_01312007 OPERATING INSTRUCTIONS Helpful Tips on Getting the Clearer Sound – Cont. • If the battery of your iPod is low, the sound quality may also be poor. In this case, charge your iPod first and try it again. Charging and Synchronizing Your iPod You can charge or synchronize your iPod without disconnecting the FM transmitter.
-
Page 18: Operatiing Instructions
FM Transmitter V10M10_IM_EN_01312007 OPERATIING INSTRUCTIONS Specifications • Modulation: FM Stereo • Tuning Type: PLL (Phase-Lock Loop) • Oscillating frequency: 16MHz • Frequency Range: 88.1MHz – 107.9MHz • Frequency Response (Audio): 80Hz – 20kHz • Audio Input Level: 800mV • Total Harmonic Distortion: 2.0% •... - Page 19 FAX: 516-626-7105 website: www.i-Luv.com e-mail: info@i-Luv.com iLuv is a trademark of jWIN Electronics Corp. iPod and iTunes are trademarks of Apple Computer, Inc. iPod not included with the product. All other trademarks and trade names are those of their respective owners. The illustrated product and specifications may differ slightly from that supplied.
