VIVIBright PLX8100F Specifications

Large venue projector

Advertisement

PLX8100F,Large Venue Projector
Basic Features:
* Perfect Image quality With a Pixelworks™ Processor.by SONY "BrightEra" 3LCD Panels
* Brightness: 10,000 ansi Lumens (Market) / 8,000 ansi Lumens (std)
* Resolution: XGA /native 1024x768 Pixels.
* Weight: 22.3 lb (9.7 kg) only Projector, 15 kg with Packing,G.W 21kg
* Excellent Connectivity, High emitting effeciency,High performance 450W single lamp
* HDMI standard terminal,Power Lens Shift & Lens options...
Basic Parameters:
Display Technology
3LCD Panels x 0.79" SONY
Native Resolution
XGA / Native 1024x768 Pixels Original resolution_PLX8100F
Max. Video Input
4K
Brightness
10,000 ansi Lumens (Market) / 8,000 ansi Lumens (std)
Contrast
4000:1 Contrast Ratio,Dynamic Video contrast ratio up to 10000:1 by HDMI
Fan Noise
As low as 31 dBa
Aspect Ratio
4:3 Native, 16:9 Compatible
Projection Method
Front, Rear,Ceiling,Table Top;Projection Image support horizontal and vertical flip
Weight
12 kg
I/O Connectors
Inputs:
HDMI:
Outputs:
Network Control: Wired LAN monitor & control and system management with optional module by RJ45
Control:
Maximum Resolution
4K via HDMI Terminal
Computer Compatibility
Standard 1080P(1920x1080),WSXGA+,WXGA+,WXGA(1280x800/1280x768),UXGA, SXGA, XGA, SVGA, VGA, Mac...
Video Compatibility
PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080P, 720p)
Displayable Colours
1.07 Billion
Projection Lens
Standard lens:
Power Lens Shift: U/D 50%; L/R 10%
Lens Optional:
Throw Ratio
1.31:1
Projection Screen Size
30" - 500"/ Diagonal 4:3
Projection Distance
1.025-24.48m(Standard Power Lens )
Horizontal Scan Rate
15.3 - 91.1kHz
Vertical Scan Rate
24 - 85Hz
Lamp Type/Lamp Life
450W single lamp, 6000/5000 hours (ECO/BRIGHT mode)
Keystone Correction *
± 40° Vertical
Dimensions (W x D x H)
535mm x 390mm x 190mm
Remote Control
Full function remote with direct source selecting
Power Supply
100-240V, 50-60Hz
Power Consumption
500W BRIGHT mode <5W Standby mode, 480W STD mode < 1W Standby mode
Operating Conditions
5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m
Uniformity
90%
Security
Kensington Lock, Password Protection
Standard Accessories
AC Power Cord,VGA Cable, Remote Control,Quick Start Card,CD User Manual, Warranty Card
Ceiling Mount Kit, Additional Ultra long Cable
Warranty
Projector 1-Years,lamp six months or 500Hrs
©Copyright2012 VIVIBright Corporation.BrightEra® &BrightEra logo are registered trademarks of SONY,All specifications are subject to change at any time.
ViviBright Corporation | www.Vivibright.com | Email: rex@vivibright.com
Phone: , 0086-755-8393 8394 | M/P:0086-1892 7474740
PC/Video: 15 Pin D-sub (RGB/YPbPr/SCART), S-Video, Composite/VGA in x 2,RGBHV,DVI...
HDMI Terminal output Support HD 1.1~1.4
VGA Out x 1,Audio output x 1,RCA...
RS232 x 1
Power zoom and focus lens, 1:1.6X, F=1.7~2.2, f=22~35mm, 1/2x1/2~4x4
See another file for lens catalog
