Toa WT-4820 Specifications

W T- 4 8 2 0
M D
ODULAR UAL
C W
HANNEL IRELESS
M R
ICROPHONE
THE TOA WT-4820 MODULAR DUAL CHANNEL
WIRELESS RECEIVER combines cutting-edge
wireless technology with user benefits such as
fast setup, simple operation, and reliable per-
formance. The WT-4820 accepts up to two
WTU-4800 Diversity Modules with sixteen user-
selectable channels in the uncrowded UHF
band (692 - 722 MHz) with simultaneous opera-
tion of up to sixteen channels.
Features include individual channel outputs,
mix output and antenna cascade for sharing
antennas between two units. A convenient
Mix-in jack allows the connection of the audio
output of a second WT-4820 or other source.
Handheld transmitters include the WM-4210
Dynamic for vocals and the WM-4220 Condenser
for speech. Bodypack transmitters include the
WM-4310 Lapel, WM-4310A Aerobics/Fitness
Headset and the WM-4310H Speech Headset.
All transmitters offer ten hours of operation
from one nine volt battery with low battery
indication. The bodypack transmitters also
have a recessed on/off switch to prevent acci-
dental shut-off and a rotatable bodypack clip
for versatile mounting.
All TOA wireless systems are FCC and UL listed
and are backed by a five year warranty.
A P P L I C AT I O N S
A/V Rentals
Auditoriums / Theatres
Bars / Lounges / Nightclubs
Bingo Halls
Boardrooms
Community Centers
Conference Facilities
Educational Facilities
Fitness Clubs / Gymnasiums
Hotels / Hospitality
Houses of Worship
Presenters
Restaurants
Schools
Theatres
Theme Parks
Training Rooms
ECEIVER
H
I G H L I G H T S
Modular Dual Channel Wireless Microphone Receiver
Compact — Up to Two Wireless Channels in a Half-Rack Space
Two Module Slots for WTU-4800 Diversity Receiver Modules
Sixteen Channel Frequency-Agile, UHF Band (692 - 722 MHz)
Up to Sixteen Simultaneous Channels in Only Four Rack Spaces!
Two Detachable Antennas and Power Supply Included
Front Panel:
Individual Output Volume Control for Each Channel
Frequency Adjustment Access
Antenna A/B and Peak LED's
Rear Panel:
Individual Channel Outputs plus Mix Output
Antenna Outputs With Support for Optional Remote Powered Antenna
Mixing Input for Audio Output of Second WT-4820 or Other Source
Antenna Cascade Output for Linking Two WT-4820 Units
FCC and UL Listed
Five Year Warranty
P
R O D U C T S
WTU-4800
WM-4210
WM-4220
WM-4310
WM-4310-OMNI
WM-4310A
WM-4310H
WM-4310B
WD-4800
YW-4500
MB-WT3
MB-WT4
S
Y S T E M S
WT-4820-H
WT-4820-L
WT-4820-2H (1) WT-4820, (2) WTU-4800, (2) WM-4220, (1) MB-WT3
WT-4820-2L (1) WT-4820, (2) WTU-4800, (2) WM-4310, (1) MB-WT3
WT-4820-HL (1) WT-4820, (2) WTU-4800, (1) WM-4220, (1) WM-4310, (1) MB-WT3
& A
C C E S S O R I E S
Wireless Receiver Module (minimum one required)
Wireless Dynamic Handheld Microphone
Wireless Condenser Handheld Microphone
Wireless Lapel Microphone with Bodypack
Wireless Omnidirectional Lapel Microphone with Bodypack
Headset Microphone with Bodypack for Aerobics/Fitness
Wireless Headset Microphone with Bodypack
Wireless Bodypack
Antenna Distributor
Remote Antenna
Rack-mount Kit (for 1 WT-4820 unit) (1U)
Rack-mount Kit (for 2 WT-4820 units) (1U)
(1) WT-4820, (1) WTU-4800, (1) WM-4220, (1) MB-WT3
(1) WT-4820, (1) WTU-4800, (1) WM-4310, (1) MB-WT3
