LARDER FRIDGE - MODELS RLA51, RLA53, RLA61, RLM51, RLM53, RLM61
GETTING STARTED:
STEP 1
Choose a location for your
fridge, away from any heat
sources and
allow adequate ventilation
- 30mm
(1
/
inch) gap above.
1
4
STEP 3
Level the fridge by
adjusting the front feet.
This will stop rocking or
vibration and keep the
door aligned.
NB. The spanner is for illustration
only and is not supplied with the
fridge.
STEP 5
Plug in and switch on.
Allow the fridge to cool
before placing food
inside.
All food in the fridge
should be covered.
Read the rest of these instructions to get the best from your appliance
and remember to fill in your guarantee registration.
INSTRUCTIONS FOR INSTALLATION & USE
To ensure that your fridge runs reliably and efficiently follow these steps.
Keep this Book in a safe place for quick reference.
STEP 2
Move the fridge into
position, using the sides
of the cabinet. Take care
to avoid damaging the
refrigerant circuit pipe
work on the rear.
STEP 4
Before plugging in and
switching on, leave the
fridge in its final
location for at least 15
minutes to allow it to
settle.
STEP 6
Your fridge is now
working.
If after 24 hours your
fridge is not operating as
you want, refer to the
Troubleshooting section.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RLA51 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hotpoint RLA51

Summary of Contents for Hotpoint RLA51

  • Page 1 LARDER FRIDGE - MODELS RLA51, RLA53, RLA61, RLM51, RLM53, RLM61 INSTRUCTIONS FOR INSTALLATION & USE GETTING STARTED: To ensure that your fridge runs reliably and efficiently follow these steps. STEP 1 Choose a location for your fridge, away from any heat...

  • Page 2: For Your Safety

    For your safety, read the following advice: The fridge cooling system contains a small amount of gas which is environmentally friendly but flammable. To avoid any risk :- Install the fridge following the installation instructions and ensure that ventilation openings are kept clear of obstruction. Take care when installing or moving the fridge to avoid damaging the pipes on the rear.

  • Page 3: Installation

    Location & Air Circulation Locate your fridge away from sources of heat e.g. cookers, radiators, direct sunlight as extreme temperature will affect its performance. Allow a minimum 100mm (4 inches) between the top of the fridge and the ceiling or the underside of a wall cupboard.
  • Page 4 Joining: Equal height Hotpoint fridges and freezers can be joined together to look like one unit by using a Filler Kit available from Hotpoint Genuine Parts & Accessories Mail Order Hotline (see KEY CONTACTS, back page).
  • Page 5 This fridge is fitted with a special mains lead. If you need to replace the mains lead due to damage, one can be bought from Hotpoint Service (see KEY CONTACTS, back page). It is strongly advised that this work is carried out by a qualified electrician.
  • Page 6 Anti-clockwise (lower number) - Warmer You can check the temperature of the fridge compartment by using a Fridge Freezer Thermometer available from Hotpoint Genuine Parts and Accessories Mail Order Hotline (see KEY CONTACTS back page). WARNING: Do not use a mercury filled thermometer, as breakage would cause a health hazard.

  • Page 7: Useful Advice

    Useful Advice Note: The Rating Plate, which lists the appliance Model Number and Serial Number can be found near the bottom of the interior wall. STORAGE ZONES Zone Type Food Storage Cool Dairy products, Cheese, butter, margarine, Low fat spreads, cooking fats / lards Preserves - Jam, curd, marmalade, spread, salad dressing or sauces.
  • Page 8 Microban® technology has been proven safe, durable and effective over many years of use in personal care and household consumer products. In addition, Hotpoint operate a rigorous antibacterial testing programme through approved independent testing laboratories.
  • Page 9 Commodity and Bottle Racks Commodity racks can be repositioned in the door to suit your storage requirements. The lidded commodity rack is recommended for the storage of dairy items, such as butter, margarine and cheese. To remove, lift rack vertically to release from fixing supports. To replace, align grooves on either side of the rack above fixing supports and push down until secure.
  • Page 10 Salad Bins For the storage of fruit, vegetables and salad items. When storing vegetables, remove unusable leaves and soil and leave lettuce, cabbage and cauliflower on the stem. It is advisable to clean the salad bin regularly, it can be removed by sliding it out from position.
  • Page 11 Defrosting No manual defrosting required The fridge compartment will defrost automatically. During defrost periods water droplets form on the interior back wall of your Larder Fridge and refreeze afterwards. WARNING: Ensure that stored food does not come into contact with the interior back wall of your Larder Fridge.
  • Page 12 Cleaning WARNING: Switch off electrical supply and pull out mains plug before cleaning. Interior Note : We recommend you use a straw to keep the defrost gutter drain hole clear of any blockage. DO NOT use sharp metal tools which could cause damage beyond repair.

  • Page 13: Maintenance

    Changing the Light Bulb WARNING: Switch off electricity supply and pull out the mains plug Obtain a replacement SES 15 watt bulb from the Hotpoint Genuine Parts and Accessories Mail Order Hotline (see KEY CONTACTS back page) and fit as follows : Remove any shelves from directly below the interior light, to make access easier.

  • Page 14: Door Reversal

    You will need a selection of small hand tools, screwdrivers, spanners etc. to carry out this procedure. Our Service Department can arrange for an Engineer to do the conversion for you but a charge will be made. Door Reversal WARNING: Switch off electrical supply and pull out the mains plug. Remove loose items/fittings from inside the fridge and place food into insulated containers whilst carrying out this operation.
  • Page 15 Door Handle Reversal: Remove the hole plugs from the right hand side of the door. Unscrew the handle fixing screws and carefully remove the handle from the door. Turn the handle vertically, top to bottom and place against the right hand side.

  • Page 16: Troubleshooting

    Automatic defrosting will return to normal operation when the kitchen temperature cools. If there is still a problem contact Hotpoint Service (See KEY CONTACTS, back page, for contact details). OPERATING SOUNDS OF A FRIDGE These are the normal types of sound that...
  • Page 17 Notes...

  • Page 18: Hotpoint Guarantee

    All Hotpoint appliances carry a fully inclusive 12 month parts and labour guarantee as well as free replacement parts for the first 5 years (except microwaves, selected integrated appliances and cooker hoods, which have a one year guarantee) provided that they are fitted by a Hotpoint engineer.

  • Page 19: After Sales Service

    Hotpoint appliance than us - the manufacturer” As part of our commitment to you, all Hotpoint appliances have the added benefit of a fully inclusive parts and labour guarantee for the first 12 months. In addition to this you also have the advantage of free replacement parts for the first 5 years when fitted by a Hotpoint engineer.

  • Page 20: Key Contacts

    Monday to Sunday, 8am to 8pm www.hotpointservice.co.uk Republic of Ireland: 1850 502 200 Genuine Parts and Accessories UK: 08709 077 077 Monday to Friday, 8.30am to 5pm Saturday, 8.30am to 12noon www.hotpointservice.co.uk Republic of Ireland: (01) 842 6836 www.hotpoint.co.uk 01/2005 195044141.01...
