Black Box IC159A Specifications

USB 3.0 4-Port Hub
Connect up to four USB 3.0 devices,
such as MP3 players, digital cameras,
or printers, to your computer.

1. Specifications

Compliance — FCC Class A, Part 15, Subpart B, CE, RoHS
Connectors — (1) USB Type B upstream port,
(4) USB Type A downstream ports
Power — Self-powered: 5-V, 4-A;
With power adapter: Input: 100–240 V. 50-60 Hz;
Output: 5-V, 4-A
Temperature Tolerance — Operating: +32 to +104° F
(0 to +40° C);
Storage: +14 to +185° F (-10 to +85° C)
Humidity — Up to 95%, noncondensing
Size — 0.9"H x 3.75"W x 2.36"D (2.28 x 9.5 x 5.9 cm)
Weight — Hub only: 2.5 oz. (70.9 g)

2. Overview

Use the USB 3.0 4-Port Hub to connect up to four USB 3.0
devices to your computer at speeds up to 4.8 Gbps.

2.1 Features

• Compatible with the USB 3.0 specification.
Customer
Support
Information
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com

BLACK BOX

• Maintains optimal speeds when using multiple USB devices.
• Automatic self-powered status monitoring
• Plug-and-play
• Has (1) upstream and (4) downstream ports
2.2 What's Included
Your package should contain the following items. If anything is
missing or damaged, contact Black Box Technical Support at
724-746-5500 or info@blackbox.com.
• (1) USB 3.0 4-Port Hub
• (1) power adapter
• (1) USB 3.0 cable
• This user's manual
for verify the installation instructions, turn this page over...
February 2010
MT1000A-85-R4
®
For a typical application diagram and
IC159A
