Testing Speaker - Infinity CC-3 Owner's Manual

Figure 5. This wiring diagram shows
polarity connections for a center
channel connection (also see the
owner's manual that came with your
amplifier, receiver, or television).
V T
ERIFY
A V M
DJUST OICE
Figure 6. The CC-3 includes VOICE
MATCHING controls (on the rear) to
help match the sound coming from
the front left and right speakers.
NOTE: The normal
position is typically the best match
when using other Infinity speakers in
your home theater system.
Receiver or Amplifier
T
ESTING
After placing and wiring the speakers, turn on audio system power.
Follow the instructions (packed with your A/V preamplifier or receiver)
to calibrate the Dolby
built-in test tone to help you balance the sound levels to all speakers in
your system.
T ...
During calibration, verify that the CC-3 center-channel speaker
EST ONE
reproduces the test tone. If not, check the wiring connections and see
the Troubleshooting chart (on the next page) for help.
...
Once calibration is complete, audition a variety of home theater
ATCHING
selections and listen to the sound quality of the dialogue reproduced by
the CC-3. If you feel the CC-3 is too bright, you can reduce it by
adjusting the HIGH control (see Figure 6) from the normal "
position towards the "–" setting. Conversely, if you want more
brightness, rotate the level control towards the "+" setting.
In a similar way, adjust the MID control to increase or decrease
midrange frequencies.
" "
center
°
(rear view)
Center Out
+
–
T S
HE PEAKER
®
Pro Logic channels. Most components include a
CC-3
(rear view)
Infinity CC-3 Center-Channel Speaker Owner's Manual 5
CC-3
(rear view)
red terminal = +
black terminal = –
" center
°
CC-3
VOICE MATCHING
CONTROLS
VOICE MATCHING
+
– –
MID HIGH
+
